Make sure this part fits

GM 15259668
Emblem, Rear

2005-2007 Buick Terraza

Customer Questions & Expert Answers (6)
GM 15259668 Emblem, Rear
GM 15259668 Emblem, Rear
  • Part Description
    Emblem, Rear End Panel And Tailgate
  • Position
    Rear
  • Replaces
    15102870
  • Manufacturer
    General Motors
Make sure this part fits
$32.76
Ships in 1-2 Business Days
1
ADD TO CART
  • Vehicle Fitment

    Year Make Model Trim Engine
    2005-2007 Buick TerrazaCX, CXL6 Cyl 3.5 L GAS, 6 Cyl 3.9 L FLEX, 6 Cyl 3.9 L GAS
    Warning: California's Proposition 65
  • Customer Questions & Expert Answers

    Q:
    Is this 15259668 designed for my car? Posted by ChevyPartsGiant Specialist
    A:
    Please Select Your Vehicle model to see if part number 15259668 is suitable before ordering.
    Posted by ChevyPartsGiant Specialist
    Q:
    How to Remove and Replace a Liftgate Emblem on Buick Terraza? Posted by Customer
    A:
    When working on Buick liftgate emblems/nameplates begin by covering the body panel with tape. Then establish alignment marks for installation with tape. Use a Heat Gun (J 25070) to apply heat by moving it in circles over the emblem/nameplate for 30 seconds at a distance of 152 mm (6 in) from the surface. You should remove the emblem/nameplate from the surface by using a flat plastic tool. To remove adhesives from body and plastic panels professionals can use a 3M(TM) Scotch Brite molding adhesive remover disk (3M(TM) P/N 07501) or a lint-free cloth treated with varnish makers and painters (VMP) naphtha or a solution of isopropyl alcohol and water at 50:50 concentration ratio. Apply the same solution to clean the area then let it dry completely. Apply tape to mark the location if no existing marks are present. Measure the TERRAZA emblem/nameplate placement starting from the liftgate's left side at 31mm (1.30in) and bottom edge at 209 mm (8.23in). The CXL emblem/nameplate should be placed with dimension (c) at 31 mm (1.30 in) right from the liftgate edge and dimension (d) at 209 mm (8.23 in) down from the liftgate bottom. The right edge of the VERSATRAK emblem/nameplate measures 37 mm (1.46 in) from the liftgate while its bottom edge spans 53 mm (2.09 in) from the liftgate. Position the Buick emblem at the exact center point above the liftgate license plate pocket. Utilize Heat Gun (J 25070) to raise the mounting surface temperature to 27-41°C (80-105°F) before mounting the emblem/nameplate. The final product must achieve a temperature level of 29-32°C (85-90°F). After removing the protecting film from the adhesive backing users must line up the emblem/nameplate according to the location marks while applying firm pressure until it sticks to the mounting surface. Press evenly across the emblem/nameplate to maintain uniform sticking then remove the protective tape from the body panel.
    Posted by ChevyPartsGiant Specialist
    Q:
    What are the positioning specifications for the CXL emblem/nameplate for the 2005 Buick Terraza? Posted by Customer
    A:
    Position it 31 mm (1.30 in) from the right edge of the liftgate and 209 mm (8.23 in) from the bottom edge.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Emblem
    Q:
    What is the first step to replace or repair an emblem/nameplate for the 2005 Buick Terraza? Posted by Customer
    A:
    Protect the mounting surface with tape and use tape for alignment marks during installation.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Emblem
    Q:
    How do you mark the location for the emblem/nameplate for the 2006 Buick Terraza? Posted by Customer
    A:
    Mark the location with tape.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Emblem
    Q:
    What temperature should the mounting surface be heated to for the 2007 Buick Terraza? Posted by Customer
    A:
    Approximately 27-41°C (80-105°F).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Emblem
    If you have any questions about this product, please don't hesitate to ask us. We will be happy to help you!

OEM GM Emblem, Rear 15259668 Designed for Proper Fit and Performance

Original OEM GM parts deliver superior quality and meet all performance standards needed for optimal automotive operation. The authentic part identified by 15259668 Emblem, Rear is available in the market under the name GM Emblem. This genuine product has a full warranty coverage from the manufacturer available at all authorized GM dealers throughout the United States. This part 15259668 Emblem, Rear fits certain Buick Terraza models.
The original GM component designated by manufacturer part number 15259668 maintains top performance when functioning as the Emblem, Rear End Panel And Tailgate unit at its Rear. The component 15259668 is constructed from durable material and its dimensions span 4.1 x 4.2 x 2.1 inches while weighing 0.40 Pounds. The Direct Replacement component is ready in New condition to ensure full compatibility with your vehicle system. This component receives the designation of Emblem, End Gate And Rear Door Decoration. The part 15259668 has available replacement options 15102870. GM manufacturer provides a warranty that ensures reliable operation of this product. The Shipping Policy and Return Policy pages outline complete details regarding shipping procedures and return processes.
