Diagram (1 of 1): Cooling - Radiator & Components

1993 GMC C2500 Suburban Radiator & Components Diagram

Enlarge Diagram

Sort by:

Ref No.

Part No. & Part Description

Price & Qty.

Part No. &
Part Description

1
52463932
Radiator
Radiator Assembly
Part Notes: Aluminum, W/Oil Cooler
1
52481749
Radiator
Radiator Assembly
- Part Notes: Copper
1
52491623
Radiator
Radiator Assembly
- Part Notes: Aluminum, W/O Oil Cooler

2

10409635
Radiator Cap
Cap, Radiator Filler *Black
MSRP: $21.17 Your Price: $11.85
1
Add To Cart

3
15574276
Radiator Mount Bracket
Bracket, Radiator
Location: Passenger Side
MSRP: $18.99 Your Price: $12.76
3
15574275
Radiator Mount Bracket
Bracket, Radiator
- Location: Driver Side

4
15553987
Radiator Insulator
Insulator, Radiator
Part Notes: Upper
Location: Driver Side;Passenger Side
4
15591853
Radiator Insulator
Insulator, Radiator
- Part Notes: Lower
- Location: Driver Side;Passenger Side

5
15973073
Radiator Crossbrace
Brace, Front End Sheet Metal Radiator Opening
- Location: Driver Side;Passenger Side

6

15650373
Recovery Tank
Reservoir, Coolant Recovery

7

15989074
Recovery Tank Cap
Cap, Engine Coolant Recovery
MSRP: $22.38 Your Price: $11.92
1
Add To Cart

8
15149285
Radiator Support
Support, Radiator
Part Notes: W/O Lock Support
8
15149286
Radiator Support
Support, Radiator
- Part Notes: W/Lock Support

9
15714368
Lower Baffle
Baffle, Radiator Air
- Part Notes: Gas

10
15603614
Side Baffle
Baffle, Radiator Air

11
15552389
Upper Deflector
Deflector, Radiator Air

12

15030678
Lock Support
Support, Hood Primary Latch

13
15659490
Upper Hose
Hose-Radiator Inlet
Part Notes: 5.7 Liter
MSRP: $54.56 Your Price: $36.67
1
Add To Cart
13
15659486
Upper Hose
Hose-Radiator Inlet
- Part Notes: 7.4 Liter
MSRP: $42.43 Your Price: $22.25
1
Add To Cart

14
15671937
Lower Hose
Hose, Radiator Outlet (Lower)
Part Notes: 7.4 Liter
MSRP: $54.17 Your Price: $28.16
1
Add To Cart
14
15659618
Lower Hose
Hose, Radiator Outlet (Lower)
- Part Notes: 5.7 Liter

15597629
Radiator Support Lower Insulator
Cushion, Body To Frame Mounting
Location: Driver Side;Passenger Side
15548600
Radiator Support Upper Insulator
Cushion, Body To Frame Mounting
- Location: Driver Side;Passenger Side
MSRP: $75.43 Your Price: $50.68

25661994
CAP,RADIATOR FILLER(PINK LABEL)(W/O TURNING EARS)(1.240)
- Fitting Vehicle Options: CK1,2(06-16)
MSRP: $16.51 Your Price: $9.24
View Details

11609754
CLAMP,WORM GEAR,SIZE 36, 64.26 MIN DIAMETER 51.56 MAX DIAMETER, STAINLESS STEEL.(RADIATOR OUTLET HOSE)
- Replaced By: 12338017
MSRP: $9.26 Your Price: $5.91
View Details

12076298
CONDUIT,CONVOLUTED,1 1/2 X 15'
MSRP: $45.45 Your Price: $29.03
View Details

11513914
BOLT,HEX WASHER HEAD,M8X1.25X12,6.2THD,17.2 O.D.,HEADER POINT,PHOSPHATE ORGANIC
MSRP: $2.95 Your Price: $1.88
View Details

15799131
RETAINER,BODY BOLT LOWER CUSHION
- Fitting Vehicle Options: CK1,2,3
- Require Quantity: 06
- Package Quantity: 1
MSRP: $10.22 Your Price: $6.52
View Details

88927326
PLUG,RADIATOR DRAIN(QTY 10 OF PLUG 52484010 IN PACKAGE)
- Fitting Vehicle Options: CK1,2,3
MSRP: $5.55 Your Price: $3.55
View Details

10108249
CLAMP,SPRING(43.5MM TO 53.0MM) NOMINAL SIZE 50MM,STAMPED "U"(RADIATOR OUTLET HOSE)
- Fitting Vehicle Options: CK1,2,3
- Replaced By: 15024903
MSRP: $16.99 Your Price: $11.42
View Details

12487371
HOSE KIT,RADIATOR OVERFLOW(FOR ALUMINUM RADIATOR REPAIR)
- Fitting Vehicle Options: CK1,2,3
MSRP: $231.72 Your Price: $70.25
View Details

11561509
BOLT,RADIATOR UPPER MOUNT BRACKET(M6X1X30,21)(8.130)
- Fitting Vehicle Options: CK2,3(L65)
- Require Quantity: 02
- Package Quantity: 1
MSRP: $5.58 Your Price: $3.56

9438382
HOSE, 1/2 INSIDE DIAMETER X 15/16 OUTSIDE DIAMETER 25' ROLL CENTRAL
MSRP: $57.24 Your Price: $36.53
View Details

52460884
TANK,RADIATOR INLET(CODE BT)
- Fitting Vehicle Options: CK1,2,309(LB4,L03,L05,KC4)
MSRP: $52.23 Your Price: $15.42
View Details
