GM 91174981
Seat Cushion Pad

The first step for replacing front seat cushions requires removing the front seating element. If the seat cushion supports a front seat belt buckle electrical connector it requires plastic retainers to be detached before proceeding. You need to remove four bolts which hold the seat cushion in place to the seat adjusters at positions 2 and 4. After flipping the front seat you must remove its seat cushion from the seat adjusters. The seat cushion assembly should be fitted by first placing it back onto the seat adjusters. Read and apply all procedures presented in the Fastener Notice section of Cautions and Notices. It is now time to reposition and fasten the 4 bolts (2, 4) which join the seat cushion to the seat adjusters through torquing them to 35 N.m (25 lb ft). The front seat belt buckle electrical connector needs to be connected to the seat cushion after which plastic retainers will protect this connection before the front seat is reinstalled.

While raising the back of the rear seat cushion, pull the rear seat pull strap to detach the seat cushion from the vehicle.

Reattach the rear seat stopper rod nut to each support pin and then install the rear seat hinge support cover onto each rear seat hinge support before lowering the seat cushion.

Connect the front seat belt buckle electrical connector to the seat cushion and secure it with the plastic retainers.

Remove the 4 bolts that secure the seat cushion to the seat adjusters, then turn the front seat over and take out the seat cushion.

Reinstall the rear seat stopper rod nut onto each support pin and attach the rear seat hinge support cover to each rear seat hinge support before lowering the seat cushion.
