Diagram (1 of 1): Fuel System Components

1996 Chevy Monte Carlo Fuel System Components Diagram

Enlarge Diagram

Sort by:

Ref No.

Ref No.

Part No. & Part Description

Price & Qty.

Part No. &
Part Description

1
12531681
Fuel Tank
Tank, Fuel
Part Notes: 3.1 Liter
1
25164143
Fuel Tank
Tank Assembly Fuel
- Part Notes: 3.4 Liter

2
10221248
Strap
Strap, Fuel Tank
- Location: Driver Side;Passenger Side

3
10217442
Insulator
Insulator, Fuel Tank

4

22591476
Cap
Cap, Fuel Tank Filler
MSRP: $35.31 Your Price: $19.77
1
Add To Cart

5

10216311
Filler Pipe
Pipe Assembly-Fuel Tank Filler

6
10199272
Vent Hose
Hose, Evaporation Emission System (Fuel Tank End)

7
10405865
Connector Hose
Hose, Fuel Tank Filler

8

19111403
Sending Unit
Sender Kit, Fuel

10
14088124
Retainer Ring
Cam, Fuel Tank Meter/Pump

11

10152293
Gasket
Gasket, Fuel Gage To Tank
MSRP: $5.14 Your Price: $2.74
1
Add To Cart

12

25121580
Strainer
Strainer, Fuel Sender Fuel

13
25163468
Fuel Pump
Pump, Fuel
Part Notes: 3.1 Liter
MSRP: $173.16 Your Price: $84.26
1
Add To Cart
13
25163463
Fuel Pump
Pump Assembly, Fuel
- Part Notes: 3.4 Liter

14

25094266
Pulse Air Feeder
Dampener, Fuel Tank Meter/Pump
MSRP: $97.90 Your Price: $54.81

15

25121293
Filter
Filter, Fuel

16
10152235
Filter Bracket
Bracket, Engine Fuel Filter

25121637
STRAINER,FUEL SENDER FUEL(REQUIRED WHEN SERVICING PUMP 25163468/EP378)
- Fitting Vehicle Options: W
MSRP: $36.00 Your Price: $19.16
View Details

17077609
SEAL,FUEL FEED PIPE(O RING)(PART OF ENGINE)
- Fitting Vehicle Options: W(L82,M13)
MSRP: $16.35 Your Price: $8.75
View Details

9438257
HOSE,13MMX25',ROLL
- Fitting Vehicle Options: W
MSRP: $93.30 Your Price: $59.56

22514722
SEAL,FUEL FEED PIPE(O RING)(PART OF PIPE,FEED & RETURN ASM BUNDLE)(7.35MM INSIDE DIAMETER X 1.66MM THICK)
- Fitting Vehicle Options: W
MSRP: $3.16 Your Price: $1.77
View Details
