How to replace the ABS Control Module on Buick Enclave?

Begin the Brake Pressure Modulator Valve replacement procedure by switching the ignition to OFF position because it protects against EBCM/EBTCM damage. The first step requires removal of the air cleaner assembly and then removal of the electronic brake control module (EBCM) electrical connector by lifting its locking tabs. Uncouple the master cylinder inlet brake pipe fittings while using caps to close them and fitting plugs to each inlet port of the brake pressure modulator valve (BPMV) to avoid fluid leakage and contamination. The next step requires disconnecting the front and rear brake pipe fittings from the BPMV outlet port and applying capping and plugging procedures to both fittings. Start by taking out the BPMV from the vehicle after removing its 2 bracket nuts then disconnect its 2 insulator nuts with washers. The BPMV should be carefully extracted from the bracket after removing its 2 insulators for inspection before necessary replacements including the lower insulator. To install the 2 BPMV insulators you should put them onto the BPMV while supporting their assembly with denatured alcohol. The lower BPMV insulator requires installation onto the bracket before carefully installing the BPMV to the bracket while using denatured alcohol as needed. The BPMV assembly needs the installation of its 2 washers before securing to the frame rail with 2 bracket nuts using a torque of 20 Nm (15 lb ft). Install the washers by tightening them to 8 Nm (71 lb in). Attach both outlet ports on the BPMV to rear brake and front brake fittings then tighten them to 17 Nm (13 lb ft) and master cylinder inlet fittings to 25 Nm (18 lb ft). Reconnect the EBCM electrical connector. The brake fluid contained within new BPMV units enables base brake bleeding to occur unless the ignition key has undergone cycling. Complete the bleed of the hydraulic brake system and conduct the Diagnostic System Check - Vehicle. The diagnosis check should be followed by a brake pedal feel inspection; perform an Antilock Brake System Automated Bleed Procedure in case the pedal display signs of sponginess. After completing the task reinstall the air cleaner assembly.

OEM Buick Enclave ABS Control Module

Anti Lock Brake Control Module

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

13 ABS Control Modules found

View related parts
Buick Enclave Control Module Part Number: 25840308
$1100.51 MSRP: $3024.84
You Save: $1924.33 (64%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Module Kit-Electronic Brake & Traction Control; ABS Control Module; ABS Control Unit; Module Kit, Electronic Brake Control
- Replaces: 25829830, 25812789
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2008-2011 Buick Enclave | CX, CXL | 6 Cyl 3.6 L GAS
View related parts
Buick Enclave Control Module Part Number: 20761340
$1355.36 MSRP: $3725.28
You Save: $2369.92 (64%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Module, Electronic Brake Control; ABS Control Module
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2012-2017 Buick Enclave | Base, Convenience, Leather, Premium | 6 Cyl 3.6 L GAS
View related parts
Buick Enclave Control Module Part Number: 20761339
$1264.81 MSRP: $2550.60
You Save: $1285.79 (51%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Module, Electronic Brake Control; ABS Control Module
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2012-2017 Buick Enclave | Base, Convenience, Leather, Premium | 6 Cyl 3.6 L GAS
View related parts
Buick Enclave Modulator Valve Part Number: 86804636
$382.52 MSRP: $742.40
You Save: $359.88 (49%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Module Assembly-Electronic Brake Control (W/Brake Pressure Mode; ABS Control Unit; Modulator
- Replaced by: 85009018
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018-2024 Buick Enclave | Avenir, Base, Essence, Preferred, Premium | 6 Cyl 3.6 L GAS
View related parts
Buick Enclave Control Module Part Number: 85138517
$231.01 MSRP: $414.36
You Save: $183.35 (45%)
ADD TO CART
Product Specifications
- Other Name: Module, Electronic Brake Control
- Replaced by: 86514988
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018-2024 Buick Enclave | Avenir, Base, Essence, Preferred, Premium | 6 Cyl 3.6 L GAS
View related parts
Buick Enclave Modulator Valve Part Number: 85138499
$374.37 MSRP: $671.52
You Save: $297.15 (45%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Module Assembly-Electronic Brake Control (W/Brake Pressure Mode; ABS Control Unit; Modulator
- Replaced by: 85009019
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018-2024 Buick Enclave | Avenir, Base, Essence, Preferred, Premium | 6 Cyl 3.6 L GAS
View related parts
Buick Enclave Control Module Part Number: 86514989
$176.91 MSRP: $343.36
You Save: $166.45 (49%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Module Kit-Electronic Brake Control; Module Kit, Electronic Brake Control; Module, Electronic Brake Control
- Replaces: 84401913, 86804660, 85138518, 84329996
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018-2024 Buick Enclave | Avenir, Base, Essence, Preferred, Premium | 6 Cyl 3.6 L GAS
View related parts
Buick Enclave Modulator Valve Part Number: 84718722
$1474.37 MSRP: $2886.66
You Save: $1412.29 (49%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Valve Kit, Electronic Brake Control; ABS Control Module; ABS Control Unit
- Replaces: 20761343
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2012-2017 Buick Enclave | Base, Convenience, Leather, Premium | 6 Cyl 3.6 L GAS
View related parts
Buick Enclave Control Module Part Number: 25840309
$777.07 MSRP: $1415.42
You Save: $638.35 (46%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Module Kit-Electronic Brake & Traction Control; ABS Control Module; ABS Control Unit; Module Kit, Electronic Brake Control
- Replaces: 25812790
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2008-2011 Buick Enclave | CX, CXL | 6 Cyl 3.6 L GAS
View related parts
Buick Enclave Modulator Valve Part Number: 19418698
$509.81 MSRP: $918.59
You Save: $408.78 (45%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Valve Kit, Electronic Traction Control Brake Pressure Mode; ABS Control Module; ABS Control Unit; Valve Kit, Electronic Brake Control
- Replaces: 25840322, 25895782
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2009-2011 Buick Enclave | CX, CXL | 6 Cyl 3.6 L GAS
View related parts
Buick Enclave Control Module Part Number: 25895780
Product Specifications
- Other Name: Module Kit-Electronic Brake & Traction Control; ABS Control Module; Module Kit, Electronic Brake Control
- Replaces: 25812791
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2008 Buick Enclave | CX, CXL | 6 Cyl 3.6 L GAS
View related parts
Buick Enclave Modulator Valve Part Number: 19416851
Product Specifications
- Other Name: Valve Kit, Electronic Traction Control Brake Pressure Mode; ABS Control Module; ABS Control Unit; Valve Kit, Electronic Brake Control
- Replaces: 25812786, 25829828
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2008 Buick Enclave | CX, CXL | 6 Cyl 3.6 L GAS
View related parts
Buick Enclave Modulator Valve Part Number: 19417205
Product Specifications
- Other Name: Valve Kit, Electronic Traction Control Brake Pressure Mode; ABS Control Module; ABS Control Unit; Valve Kit, Electronic Brake Control
- Replaces: 25840323, 19416850, 25895784
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2009-2011 Buick Enclave | CX, CXL | 6 Cyl 3.6 L GAS

Buick Enclave ABS Control Module

Want to cut long-term maintenance and repair costs? Choose OEM ABS Control Module. Those parts deliver top durability you can trust. On our site, you'll find a huge catalog of genuine Buick Enclave parts. Prices are unbeatable, so you can keep more in your pocket. Every OEM Buick Enclave ABS Control Module includes a manufacturer's warranty. You can also get an easy return policy that keeps buying risk free. Fast delivery, get your car on the road quickly. It's simple to search, compare, and order. Stop guessing about quality or fit. Order today and save with parts that last.

ABS Control Module is a special unit that contributes to the improved dependability and efficiency of the Buick Enclave along with providing secure and correct briskness of a car. This module has a critically important function in preventing the wheel lock up when doing very hard braking on the roads which in turn cause skidding and loss of traction on the different surface. The ABS Control Module involves the usage of wheel speed sensors, valves, a pump as well as a controller to regulate the pressure of the brakes relative to the existing data from the sensors. This high technology enhances the braking system and also safety gadgets such as the electronic stability control and the traction control of the Buick Enclave. for the different generations of Buick Enclave, this type of ABS Control Module will fit perfectly, from the first generation model of 2007 to the latest models. Thus, the consumers can trust in the reliability of the ABS Control Module to run specific diagnostics and ensure the tractive control stays connected with the road surface. Antilock Braking system Control Module coupled with safety and performance adorns Buick Enclave and has a cutting edge in the automotive market leaving all other gadgets and add-ons as mere enhancements to basic issues of safety and efficiency on the Buick Enclave.

Buick Enclave ABS Control Module Parts Questions & Experts Answers

Control Module
25840308
Q: How to replace the ABS Control Module on Buick Enclave?
A:
Begin the Brake Pressure Modulator Valve replacement procedure by switching the ignition to OFF position because it protects against EBCM/EBTCM damage. The first step requires removal of the air cleaner assembly and then removal of the electronic brake control module (EBCM) electrical connector by lifting its locking tabs. Uncouple the master cylinder inlet brake pipe fittings while using caps to close them and fitting plugs to each inlet port of the brake pressure modulator valve (BPMV) to avoid fluid leakage and contamination. The next step requires disconnecting the front and rear brake pipe fittings from the BPMV outlet port and applying capping and plugging procedures to both fittings. Start by taking out the BPMV from the vehicle after removing its 2 bracket nuts then disconnect its 2 insulator nuts with washers. The BPMV should be carefully extracted from the bracket after removing its 2 insulators for inspection before necessary replacements including the lower insulator. To install the 2 BPMV insulators you should put them onto the BPMV while supporting their assembly with denatured alcohol. The lower BPMV insulator requires installation onto the bracket before carefully installing the BPMV to the bracket while using denatured alcohol as needed. The BPMV assembly needs the installation of its 2 washers before securing to the frame rail with 2 bracket nuts using a torque of 20 Nm (15 lb ft). Install the washers by tightening them to 8 Nm (71 lb in). Attach both outlet ports on the BPMV to rear brake and front brake fittings then tighten them to 17 Nm (13 lb ft) and master cylinder inlet fittings to 25 Nm (18 lb ft). Reconnect the EBCM electrical connector. The brake fluid contained within new BPMV units enables base brake bleeding to occur unless the ignition key has undergone cycling. Complete the bleed of the hydraulic brake system and conduct the Diagnostic System Check - Vehicle. The diagnosis check should be followed by a brake pedal feel inspection; perform an Antilock Brake System Automated Bleed Procedure in case the pedal display signs of sponginess. After completing the task reinstall the air cleaner assembly.
