How to service and repair the pitman arm on GMC C3500?

Start the Pitman Arm servicing and repair procedure by first elevating the vehicle and implementing jack stands for support. The service requires using proper equipment to detach ball joints before removing the Drag Link from the Pitman Arm ball stud and the Pitman Arm nut from the steering gear shaft. Keep track of the alignment points between the Pitman Arm and pitman shaft that will help during assembly. The j 6632-01 Pitman Arm puller or the j 29107-a universal Pitman Arm puller eliminate the Pitman Arm from the truck. First inspect the ball stud thread for damage and the ball stud seals for excessive wear before cleaning the ball stud threads. A clamp-type Pitman Arm requires spreading to slip onto the pitman shaft with a wedge but without hammering to prevent steering gear damage. Secure the Pitman Arm onto its shaft by using the installation marks initially established during disassembly. No damage will arise from using the 250 nm (184 ft. Lbs.) torque value during this Pitman Arm nut tightening procedure. Install the Drag Link onto the Pitman Arm ball stud making sure the ball stud seal faces the ball stud before tightening the j 29193 to 62 nm (48 ft. Lbs.) thus seating the tapers. Place the Pitman Arm nut onto the Pitman Arm ball stud after removing j 29193 before tightening it to 47 nm (35 ft. Lbs.). Finally, lower the vehicle. The necessary tools for this work are the j 24319-01 universal steering linkage puller, j 29107-a universal Pitman Arm puller, j 6632-01 Pitman Arm puller and j 29194 steering linkage installer (14 mm).
