GM 88972974
Pressure Plate

Disconnection of the negative Battery Cable should be the first step to service and repair the Flywheel. The service demands removal of transaxle assembly in both manual and automatic transmission setups. Operators of automobiles with manual transmissions should detach the clutch and Pressure Plate. Begin by taking off the Flywheel from the Crankshaft while removing its eight retaining bolts. Apply suitable solvent to eliminate surface grease and dirt from the Crankshaft flange. The installation process starts by mounting the Flywheel onto the Crankshaft but you must avoid applying too much sealant to the Flywheel retaining bolt threads. Use gm p/n 12345493 or its equivalent product to treat the Flywheel retaining bolts' threads. Install the automatic transmission Flywheel retaining bolts (1-8) according to this sequence while tightening them to 83 nm (61 ft. Lbs.). To install the Flywheel retaining bolts on manual transmission vehicles follow a sequence of tightening the first set to 49 nm (36 ft. Lbs.) and then complete the installation by using j 36660-a torque angle meter (J 36660-A) to reach an additional 90 degrees of torque. Reinstall the manual transmission clutch together with the Pressure Plate after installation. To finish the repair you need to reinstall the transaxle assembly according to requirements before reconnecting the negative Battery Cable while torquing the Battery Cable bolt to 15 nm (11 ft. Lbs.).

Remove the clutch and pressure plate, then take out the eight flywheel retaining bolts and remove the flywheel from the crankshaft.

Place the flywheel onto the crankshaft, ensuring not to apply an excessive amount of sealant to the flywheel retaining bolt threads.
