GM 89060201
Stoplamp Switch

Begin replacement of the brake pedal position sensor by removing the instrument panel insulator. Without removing the connector, push the position assurance hook aside then disconnect the wiring connection. Take out the brake pedal position sensor by unscrewing its fixture first. Use GM approved part 12345493 adhesive to stick the screw while placing the sensor fork on the pin and rotating the sensor until the locator hits the extension bracket hole. Tighten the brake pedal position sensor screw to 2 N.m (18 lb in) while positioning it correctly. Plug the electrical connection into the port while aligning the CPA accessory with its designated contact point. Complete the sensor adjustment then replace the I/P insulator.

Start the brake pedal position sensor replacement by taking out the instrument panel insulator. Press the connector position assurance without taking it out before removing the electrical cable. Unscrew the sensor and pull out the brake pedal position sensor. Apply adhesive GM P/N 12345493 on the screw before you position the sensor fork on the pin and rotate the sensor to match its locator to the extension bracket hole. Tighten the brake pedal position sensor screw to a torque value of 18 lbs inch with 2 N.m. Secure the CPA connector correctly and test the electrical connection. After installing the new I/P insulator attach the sensor then test and activate the new sensor function.

A scan tool (J-45095) is required to calibrate the BPPS.

Via the class 2 communication bus to the vehicle subsystems.
