How to replace the rear Motor and Transmission Mount on an AWD on 2010 Cadillac SRX?

To replace the transmission rear mount on awd vehicle first lift and support vehicle. Take out the propeller shaft, and if there is an lf1, remove the right Catalytic Converter. Use an appropriate jack to hold the transaxle and relieve the weight off the mount and remove the transaxle mount to frame fasteners (3, 4). Finally, come out with the transaxle mount through bolt and take the transaxle mount from vehicle. Unfasten the transaxle bracket to Transfer Case fasteners, and, removing the bracket from the vehicle. In the case of installation, suspend the transaxle bracket to the transaxle and hand start the transaxle mount bracket to Transfer Case bolts. Tighten the Transfer Case bracket bolts to 100 nm (74 lb ft). Mount the transaxle mount to the frame, and appropriate mounting of the longer transaxle mount to the frame contact bolt and tighten to 62nm (46lbft) followed by shorter transaxle mount to frame contact providing 100 nm (74lb ft). Install the through bolt and torque to 100 nm (74 lb ft), then remove the support of the transaxle. Install the propeller shaft and on its removal, the right Catalytic Converter. Finally, lower the vehicle.

OEM 2010 Cadillac SRX Motor And Transmission Mount

Motor and Trans Mount

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

10 Motor And Transmission Mounts found

View related parts
2010 Cadillac SRX Transmission Mount Part Number: 22801992
$47.24 MSRP: $80.43
You Save: $33.19 (42%)
ADD TO CART
Product Specifications
- Other Name: Mount, Transmission Mounting; Transfer Case Mount; Front Trans Mount
- Position: Front
- Item Weight: 2.30 Pounds
- Item Dimensions: 11.5 x 8.5 x 5.5 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 22801992
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2010 Cadillac SRX Submodels:
- Base, Luxury, Performance, Premium | 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
View related parts
2010 Cadillac SRX Transmission Mount Part Number: 20847582
$94.92 MSRP: $148.68
You Save: $53.76 (37%)
ADD TO CART
Product Specifications
- Other Name: Mount, Transmission Mounting; Transfer Case Mount; Side Transmission Mount
- Item Weight: 3.70 Pounds
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 20847582
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following 2010 Cadillac SRX Submodels:
- Base, Luxury, Performance, Premium | 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
View related parts
2010 Cadillac SRX Transmission Mount, Rear Part Number: 13228303
$40.67 MSRP: $69.25
You Save: $28.58 (42%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Mount Assembly-Engine Rear; Transfer Case Mount; Rear Trans Mount; Mount, Transmission Mounting
- Position: Rear
- Item Weight: 3.80 Pounds
- Item Dimensions: 9.6 x 8.9 x 6.7 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 13228303
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2010 Cadillac SRX Submodels:
- Base, Luxury, Performance, Premium | 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
View related parts
2010 Cadillac SRX Motor Mount Part Number: 25778693
$86.46 MSRP: $148.49
You Save: $62.03 (42%)
ADD TO CART
Product Specifications
- Other Name: Mount Assembly-Engine; Engine Mount Bracket; Front Mount; Mount; Mount, Engine Mount Dampening
- Item Weight: 5.10 Pounds
- Item Dimensions: 9.4 x 9.2 x 7.3 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 25778693
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2010 Cadillac SRX Submodels:
- Base, Luxury, Performance, Premium | 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
View related parts
2010 Cadillac SRX Transmission Mount, Rear Part Number: 13228306
$39.73 MSRP: $67.65
You Save: $27.92 (42%)
ADD TO CART
Product Specifications
- Other Name: Mount Assembly-Engine Rear; Transfer Case Mount; Rear Trans Mount; Mount, Transmission Mounting
- Position: Rear
- Item Weight: 6.50 Pounds
- Item Dimensions: 12.2 x 12.2 x 8.1 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 13228306
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2010 Cadillac SRX Submodels:
- Base, Luxury, Performance, Premium | 6 Cyl 2.8 L GAS, 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
View related parts
2010 Cadillac SRX Transmission Mount Part Number: 13227766
$274.15 MSRP: $394.22
You Save: $120.07 (31%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Mount, Transmission Mounting; Engine Mount Bracket; Transfer Case Mount; Motor Mount; Front Mount; Front Trans Mount
- Position: Front
- Item Weight: 3.70 Pounds
- Item Dimensions: 8.6 x 6.6 x 3.5 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 13227766
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2010 Cadillac SRX Submodels:
- Performance, Premium | 6 Cyl 2.8 L GAS
View related parts
2010 Cadillac SRX Motor Mount Part Number: 25778691
$136.86 MSRP: $230.16
You Save: $93.30 (41%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Mount Assembly-Engine; Engine Mount Bracket; Front Mount; Mount; Mount, Engine Mount Dampening
- Item Weight: 4.60 Pounds
- Item Dimensions: 9.2 x 9.3 x 7.6 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 25778691
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2010 Cadillac SRX Submodels:
- Base, Luxury, Performance, Premium | 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
View related parts
2010 Cadillac SRX Transmission Mount Part Number: 20847581
$115.92 MSRP: $182.40
You Save: $66.48 (37%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Mount, Transmission Mounting; Transfer Case Mount; Side Transmission Mount
- Item Weight: 3.80 Pounds
- Item Dimensions: 12.7 x 9.5 x 7.5 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 20847581
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2010 Cadillac SRX Submodels:
- Base, Luxury, Performance, Premium | 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
View related parts
2010 Cadillac SRX Transmission Mount Part Number: 20847583
$48.34 MSRP: $75.72
You Save: $27.38 (37%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Mount, Transmission Mounting; Transfer Case Mount; Side Transmission Mount
- Item Weight: 3.90 Pounds
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 20847583
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following 2010 Cadillac SRX Submodels:
- Performance, Premium | 6 Cyl 2.8 L GAS
View related parts
2010 Cadillac SRX Motor Mount Part Number: 25778692
$119.63 MSRP: $188.22
You Save: $68.59 (37%)
Product Specifications
- Other Name: Mount Assembly-Engine; Engine Mount Bracket; Rear Mount; Mount, Engine Mount Dampening
- Item Weight: 4.00 Pounds
- Item Dimensions: 9.3 x 9.1 x 7.1 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 25778692
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2010 Cadillac SRX Submodels:
- Performance, Premium | 6 Cyl 2.8 L GAS

2010 Cadillac SRX Motor And Transmission Mount

With a comprehensive array of OEM 2010 Cadillac SRX Motor And Transmission Mount, from fuel pumps to door handles, our website is a one-stop-shop for your needs. All our genuine 2010 Cadillac SRX Motor And Transmission Mount are backed by the manufacturer's warranty and are offered at competitive prices in the market. Rest assured, you can shop with complete confidence.

2010 Cadillac SRX Motor And Transmission Mount Parts and Q&A

Q: How to replace the rear Motor and Transmission Mount on an AWD on 2010 Cadillac SRX?
A: To replace the transmission rear mount on awd vehicle first lift and support vehicle. Take out the propeller shaft, and if there is an lf1, remove the right Catalytic Converter. Use an appropriate jack to hold the transaxle and relieve the weight off the mount and remove the transaxle mount to frame fasteners (3, 4). Finally, come out with the transaxle mount through bolt and take the transaxle mount from vehicle. Unfasten the transaxle bracket to Transfer Case fasteners, and, removing the bracket from the vehicle. In the case of installation, suspend the transaxle bracket to the transaxle and hand start the transaxle mount bracket to Transfer Case bolts. Tighten the Transfer Case bracket bolts to 100 nm (74 lb ft). Mount the transaxle mount to the frame, and appropriate mounting of the longer transaxle mount to the frame contact bolt and tighten to 62nm (46lbft) followed by shorter transaxle mount to frame contact providing 100 nm (74lb ft). Install the through bolt and torque to 100 nm (74 lb ft), then remove the support of the transaxle. Install the propeller shaft and on its removal, the right Catalytic Converter. Finally, lower the vehicle.
