How to Service and Repair a Control Arm Bushing on the Rear Axle of a Chevrolet Equinox?

To remove the rear axle lower Control Arm Bushing, one should remove the lower Control Arm first. Use the rear Control Arm Bushing remover (J 45097) to pull out the indicated bushing. Position the push out socket to the flanged side of the Control Arm attaching it to the bushing, and further install the through bolt and bearing in the washer to the push out socket. Then, position a backing socket to the Control Arm on the other side of flange, and put the stabilizer between the Control Arm ears. Secure with a flat washer and nut, and make sure over high pressure lube is put on the thread of the tool before the nut is tightened to remove the bushing. For initial fitting apply high pressure lube to the threads of the tool and fit the tool from the opposite direction now. Reverse the tool layout using rear Control Arm Bushing remover (J 45097) while you tighten the nut up until the bushing is fully installed then install back the lower Control Arm.

OEM Chevrolet Equinox Control Arm Bushing

Suspension Arm Bushing

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

9 Control Arm Bushings found

View related parts
Chevrolet Equinox Lower Control Arm Front Bushing Part Number: 25851984
$16.15 MSRP: $26.60
You Save: $10.45 (40%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Bushing, Front Lower Control Arm; Suspension Control Arm Bushing; Control Arm Bushing; Axle Pivot Bushing; Bushings; Bushing, Steering Knuckle Lower Control Arm
- Position: Front Lower
- Replaces: 22735945
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2010-2017 Chevrolet Equinox | L, LS, LT, LTZ, Premier | 4 Cyl 2.4 L FLEX, 4 Cyl 2.4 L GAS, 6 Cyl 3.0 L FLEX, 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
View related parts
Chevrolet Equinox Lower Control Arm Rear Bushing, Front Part Number: 25848403
$51.14 MSRP: $84.24
You Save: $33.10 (40%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Bushing, Front Lower Control Arm; Suspension Control Arm Bushing; Control Arm Bushing; Axle Pivot Bushing; Bushings; Bushing, Steering Knuckle Lower Control Arm
- Position: Front Lower
- Replaces: 21990368
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2005-2009 Chevrolet Equinox | LS, LT, LTZ, Sport | 6 Cyl 3.4 L GAS, 6 Cyl 3.6 L GAS
View related parts
Chevrolet Equinox Differential Assy Rear Bushing Part Number: 20914916
$40.85 MSRP: $69.56
You Save: $28.71 (42%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Bushing, Rear Axle Control Arm; Differential Mount; Bushing; Bushing, Differential Carrier
- Position: Rear
- Replaces: 22734323
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2010-2017 Chevrolet Equinox | L, LS, LT, LTZ, Premier | 4 Cyl 2.4 L FLEX, 4 Cyl 2.4 L GAS, 6 Cyl 3.0 L FLEX, 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
View related parts
Chevrolet Equinox Bushing, Lower Part Number: 84110416
$49.27 MSRP: $84.60
You Save: $35.33 (42%)
ADD TO CART
Product Specifications
- Other Name: Bushing-Front Lower Control Arm Rear; Control Arm Bushing; Axle Pivot Bushing; Bushings
- Position: Lower
- Replaced by: 84910670
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018-2022 Chevrolet Equinox | L, LS, LT, Premier, RS | 4 Cyl 1.5 L GAS, 4 Cyl 1.6 L DIESEL, 4 Cyl 2.0 L GAS
View related parts
Chevrolet Equinox Upper Control Arm Bushing, Rear Part Number: 22689678
$4.66 MSRP: $71.47
You Save: $66.81 (94%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Bushing, Rear Axle Control Arm; Control Arm Bushing; Axle Beam Mount; Bushings
- Position: Rear
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2005-2006 Chevrolet Equinox | LS, LT | 6 Cyl 3.4 L GAS
View related parts
Chevrolet Equinox Bushing, Lower Part Number: 84910670
$49.27 MSRP: $84.60
You Save: $35.33 (42%)
ADD TO CART
Product Specifications
- Other Name: Bushing-Front Lower Control Arm Rear; Bushings; Bushing, Steering Knuckle Lower Control Arm
- Position: Lower
- Replaces: 84110416
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018-2024 Chevrolet Equinox | L, LS, LT, Premier, RS | 4 Cyl 1.5 L GAS, 4 Cyl 1.6 L DIESEL, 4 Cyl 2.0 L GAS
View related parts
Chevrolet Equinox Lower Control Arm Rear Bushing, Front Part Number: 25919637
$124.23 MSRP: $211.51
You Save: $87.28 (42%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Bushing, Front Lower Control Arm; Suspension Control Arm Bushing; Control Arm Bushing; Axle Pivot Bushing; Lower Control Arm Front Bushing; Bushings; Bushing, Steering Knuckle Lower Control Arm
- Position: Front Lower
- Replaces: 25823014
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2008-2017 Chevrolet Equinox | L, LS, LT, LTZ, Premier, Sport | 4 Cyl 2.4 L FLEX, 4 Cyl 2.4 L GAS, 6 Cyl 3.0 L FLEX, 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
View related parts
Chevrolet Equinox Lower Control Arm Front Bushing Part Number: 21990364
Product Specifications
- Other Name: Bushing, Steering Knuckle Lower Control Arm; Control Arm Bushing; Axle Pivot Bushing; Bushings
- Position: Lower
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2005-2009 Chevrolet Equinox | LS, LT, LTZ, Sport | 6 Cyl 3.4 L GAS, 6 Cyl 3.6 L GAS
View related parts
Chevrolet Equinox Lower Control Arm Bushing Part Number: 22715879
Product Specifications
- Other Name: Bushing; Axle Support Bushing; Control Arm Bushing; Axle Beam Mount; Bushing, Rear Axle Control Arm
- Position: Rear Lower
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2005-2006 Chevrolet Equinox | LS, LT | 6 Cyl 3.4 L GAS

Chevrolet Equinox Control Arm Bushing

Want to cut long-term maintenance and repair costs? Choose OEM Control Arm Bushing. Those parts deliver top durability you can trust. On our site, you'll find a huge catalog of genuine Chevrolet Equinox parts. Prices are unbeatable, so you can keep more in your pocket. Every OEM Chevrolet Equinox Control Arm Bushing includes a manufacturer's warranty. You can also get an easy return policy that keeps buying risk free. Fast delivery, get your car on the road quickly. It's simple to search, compare, and order. Stop guessing about quality or fit. Order today and save with parts that last.

The Chevrolet Equinox Control Arm Bushing is part of the suspension which is widely known among the fans of the Chevrolet Equinox cars of different years. Intended to dampen the vibrations between the control arm and the vehicle's structure while reducing the overall friction, this Control Arm Bushing allows for seamless shifting presumably due to the road surface and the steering system, especially increasing both the performance and the durability of the car. The Chevrolet Equinox, which has changed through three generations since its origination in the year 2004, employs different material types in assembling its Control Arm Bushings; rubber, polyurethane, synthetic elastomers are used in specific manners depending on requirement of drive kinds. Such flexibility of material selection enables the Chevrolet Equinox to perform well in average operations, as well as intense ones. Functioning as the Horizontal locator, the Control Arm Bushing ensures that the wheels cannot move independently of the car's main structure, which improves the car's stability and ride. In addition, other unique characteristics of the Chevrolet Equinox including the over and above all-wheel-drive system and several engines are also a plus in taking effective enhancements of the Control Arm Bushing making it special in the general automobile market. Being one of the bestselling models with a sales volume of more than 2 million units, Chevrolet Equinox is now as the most-loved model due to the superb operation of the Control Arm Bushing.

Chevrolet Equinox Control Arm Bushing Parts Questions & Experts Answers

Lower Control Arm Rear Bushing, Front
25848403
Q: How to Service and Repair a Control Arm Bushing on the Rear Axle of a Chevrolet Equinox?
A:
To remove the rear axle lower Control Arm Bushing, one should remove the lower Control Arm first. Use the rear Control Arm Bushing remover (J 45097) to pull out the indicated bushing. Position the push out socket to the flanged side of the Control Arm attaching it to the bushing, and further install the through bolt and bearing in the washer to the push out socket. Then, position a backing socket to the Control Arm on the other side of flange, and put the stabilizer between the Control Arm ears. Secure with a flat washer and nut, and make sure over high pressure lube is put on the thread of the tool before the nut is tightened to remove the bushing. For initial fitting apply high pressure lube to the threads of the tool and fit the tool from the opposite direction now. Reverse the tool layout using rear Control Arm Bushing remover (J 45097) while you tighten the nut up until the bushing is fully installed then install back the lower Control Arm.
