How to replace the oil pan on Chevrolet Traverse?

Engine oil must drain completely before removing the Oil Filter to proceed with Oil Pan replacement. The first step requires removing the exhaust flexible pipe along with the engine and subsequently removing the engine front cover. Begin by unstucking the rtv sealant along the edge of the Oil Pan using pry points. Then remove the bolts holding the Oil Pan in place before you can pull the pan away from the block. The Oil Pan requires cleaning in addition to cleaning the engine block gasket surface. Before pan installation use the 8 mm (0.315 in) guides found in (EN 46109) to insert them into the engine block's center Oil Pan rail bolt hole on each side. The installation requires applying a 3 mm (0.118 in) bead of rtv sealant gm p/n 12378521 (Canadian P/N 88901148) or equivalent between the block pan rail and crankshaft rear oil seal housing. Spot the Oil Pan onto the block while removing the (EN 46109) guides. Knock the Oil Pan bolts loosely into place before applying proper torque to them using this precise sequence: tighten 8 mm bolts (1-11) to 23 nm (17 lb ft) while tightening 6 mm bolts (12, 13) to 10 nm (89 lb in). 8 mm bolts (1-11) to 23 nm (17 lb ft) and 6 mm bolts (12, 13) to 10 nm (89 lb in). Reinstall the front engine cover followed by the engine block before installing the flexible part of the exhaust system and completing engine oil refilling.

OEM Chevrolet Traverse Oil Pan

Oil Drain Pan

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

6 Oil Pans found

View related parts
Chevrolet Traverse Oil Pan Part Number: 12676340
$28.47 MSRP: $46.87
You Save: $18.40 (40%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Pan, Engine Oil; Engine Oil Pan; Lower Oil Pan
- Position: Lower
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018-2019 Chevrolet Traverse | RS | 4 Cyl 2.0 L GAS
View related parts
Chevrolet Traverse Oil Pan Part Number: 28289985
$116.56 MSRP: $183.36
You Save: $66.80 (37%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Upper Oil Pan; Pan, Engine Oil
- Replaces: 25202733, 25201776, 12692501, 12692498
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018-2019 Chevrolet Traverse | RS | 4 Cyl 2.0 L GAS
View related parts
Chevrolet Traverse Oil Pan Part Number: 12716568
$1040.91 MSRP: $1645.19
You Save: $604.28 (37%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Pan, Engine Oil; Oil Pan Baffle
- Replaces: 12693238, 12692482, 12680279
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018-2023 Chevrolet Traverse | High Country, L, LS, LT, Premier, RS | 6 Cyl 3.6 L GAS
View related parts
Chevrolet Traverse Oil Pan Part Number: 12666371
$188.95 MSRP: $297.31
You Save: $108.36 (37%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Pan, Engine Oil
- Replaces: 12648946
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2013-2017 Chevrolet Traverse | LS, LT, LTZ, Premier | 6 Cyl 3.6 L GAS
View related parts
Chevrolet Traverse Oil Pan Part Number: 12666374
$179.01 MSRP: $281.67
You Save: $102.66 (37%)
Product Specifications
- Other Name: Pan, Engine Oil; Engine Oil Pan
- Replaces: 12609875, 12575368, 12636673, 12638371
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2009-2012 Chevrolet Traverse | LS, LT, LTZ | 6 Cyl 3.6 L GAS
View related parts
Chevrolet Traverse Oil Pan Part Number: 12676336
Product Specifications
- Other Name: Pan, Engine Oil; Upper Oil Pan
- Replaces: 12662938, 12673395
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2018 Chevrolet Traverse | RS | 4 Cyl 2.0 L GAS

Chevrolet Traverse Oil Pan

Want to cut long-term maintenance and repair costs? Choose OEM Oil Pan. Those parts deliver top durability you can trust. On our site, you'll find a huge catalog of genuine Chevrolet Traverse parts. Prices are unbeatable, so you can keep more in your pocket. Every OEM Chevrolet Traverse Oil Pan includes a manufacturer's warranty. You can also get an easy return policy that keeps buying risk free. Fast delivery, get your car on the road quickly. It's simple to search, compare, and order. Stop guessing about quality or fit. Order today and save with parts that last.

Chevrolet Traverse Oil Pan is one of the components that are used in engineering the Lubrication System of the vehicle; it holds the required oil for efficient operation of the vehicle's engine. Located below the engine the oil pan holds oil and makes certain that all moving parts in the engine are adequately lubricated. Almost all Chevrolet Traverse cars have wet sump lubrication system whereby the oil pump pulls oil from the pan with the help of a pickup tube. Former engines used stamped steel as their oil pan but today's engines use cast aluminum to contain the reservoir. In summary, the oil pan as a critical component of the car, it ensures appropriate functioning and functionality of the engine and it also eliminates oil leakage.

Chevrolet Traverse Oil Pan Parts Questions & Experts Answers

Oil Pan
12666374
Q: How to replace the oil pan on Chevrolet Traverse?
A:
Engine oil must drain completely before removing the Oil Filter to proceed with Oil Pan replacement. The first step requires removing the exhaust flexible pipe along with the engine and subsequently removing the engine front cover. Begin by unstucking the rtv sealant along the edge of the Oil Pan using pry points. Then remove the bolts holding the Oil Pan in place before you can pull the pan away from the block. The Oil Pan requires cleaning in addition to cleaning the engine block gasket surface. Before pan installation use the 8 mm (0.315 in) guides found in (EN 46109) to insert them into the engine block's center Oil Pan rail bolt hole on each side. The installation requires applying a 3 mm (0.118 in) bead of rtv sealant gm p/n 12378521 (Canadian P/N 88901148) or equivalent between the block pan rail and crankshaft rear oil seal housing. Spot the Oil Pan onto the block while removing the (EN 46109) guides. Knock the Oil Pan bolts loosely into place before applying proper torque to them using this precise sequence: tighten 8 mm bolts (1-11) to 23 nm (17 lb ft) while tightening 6 mm bolts (12, 13) to 10 nm (89 lb in). 8 mm bolts (1-11) to 23 nm (17 lb ft) and 6 mm bolts (12, 13) to 10 nm (89 lb in). Reinstall the front engine cover followed by the engine block before installing the flexible part of the exhaust system and completing engine oil refilling.
