Make sure this part fits

GM 25767170
Mount Bracket, Driver Side

2004-2007 Cadillac CTS

Customer Questions & Expert Answers (14)
GM 25767170 Mount Bracket, Driver Side
  • Part Description
    Bracket, Engine Mounting; Engine Mount Bracket; Motor Mount
  • Position
    Driver Side
  • Manufacturer
    General Motors
  • Manufacturer's Notes
    This part is discontinued.
Make sure this part fits
  • Related Parts
  • Product Specifications
  • Vehicle Fitment
  • Customer Questions & Expert Answers
  • Product Specifications

    BrandGenuine GM
    Manufacturer Part Number25767170
    Part DescriptionBracket, Engine Mounting; Engine Mount Bracket; Motor Mount
    Item Dimensions7.3 x 7.3 x 4.6 inches
    Item Weight3.00 Pounds
    PositionDriver Side
    ConditionNew
    Fitment TypeDirect Replacement
    ManufacturerGeneral Motors
    SKU25767170
    WarrantyThis genuine GM part is guaranteed by GM's factory warranty.
    Shipping & ReturnShipping Policy Return Policy
    Warning: California's Proposition 65
  • Vehicle Fitment

    Year Make Model Trim Engine
    2004-2007 Cadillac CTSV8 Cyl 5.7 L GAS, 8 Cyl 6.0 L GAS
  • Customer Questions & Expert Answers

    Q:
    Can you help me check if this 25767170 is the right part for my car? Posted by ChevyPartsGiant Specialist
    A:
    Please Select Your Vehicle model to see if part number 25767170 is suitable before ordering.
    Posted by ChevyPartsGiant Specialist
    Q:
    What should be done after installing the new left engine mount bracket for the 2004 Cadillac CTS? Posted by Customer
    A:
    Install the upper engine mount retaining nut and tighten it to 80 Nm (59 ft. lbs.).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Engine Mount
    Q:
    What should be done after raising the 2005 Cadillac CTS? Posted by Customer
    A:
    Remove the lower engine mount retaining nut and raise the engine using the screw jack until the weight is off the mount.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Engine Mount
    Q:
    What should you do if there is movement between the metal plate of the transmission/transaxle mount and its attaching points for the 2004 Cadillac CTS? Posted by Customer
    A:
    Lower the transmission/transaxle and tighten the bolts or nuts securing the transmission/transaxle mount to the frame or transmission/transaxle mount bracket.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Motor And Transmission Mount
    Q:
    What should be followed during installation for the 2004 Cadillac CTS? Posted by Customer
    A:
    Follow the Fastener Notice in Service Precautions.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Motor And Transmission Mount
    Q:
    How do you install the new transmission mount for the 2005 Cadillac CTS? Posted by Customer
    A:
    Position the new transmission mount in place and install the transmission mount bolts, tightening them to 60 Nm (44 ft. lbs.).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Motor And Transmission Mount
    Q:
    What is the next step after raising the engine for the 2006 Cadillac CTS? Posted by Customer
    A:
    Remove the upper engine mount retaining nut and take out the engine mount from the vehicle, followed by the starter, ensuring not to distort or bend the engine mount heat shield.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Engine Mount Bracket
    Q:
    What is the next step after installing the left engine mount bracket for the 2007 Cadillac CTS? Posted by Customer
    A:
    Install the engine mount back into the vehicle, followed by the upper engine mount retaining nut, which should be tightened to 80 N.m (59 lb ft).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Engine Mount Bracket
    Q:
    What is the torque specification for the transmission to support mounting bolts for the 2007 Cadillac CTS? Posted by Customer
    A:
    Tighten them to 60 N.m (44 lb ft).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Motor And Transmission Mount
    Q:
    What should be removed after raising for the 2006 Cadillac CTS? Posted by Customer
    A:
    The exhaust system.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Motor And Transmission Mount
    Q:
    What is the first step to replace the right engine mount for the 2005 Cadillac CTS? Posted by Customer
    A:
    Raise and support the vehicle.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Engine Mount
    Q:
    What is the final step after completing the installation for the 2007 Cadillac CTS? Posted by Customer
    A:
    Remove the screw jack and block of wood from under the oil pan and lower the vehicle.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Engine Mount
    Q:
    What is the final step after securing the engine mount for the 2006 Cadillac CTS? Posted by Customer
    A:
    Remove the screw jack and block of wood from under the oil pan and lower the vehicle.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Engine Mount
    Q:
    What should be done after tightening the bolts for the 2007 Cadillac CTS? Posted by Customer
    A:
    Remove the transmission support, reinstall the exhaust system, and lower the vehicle.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Motor And Transmission Mount
