How to Service and Repair a Rear Quarter Window Motor on GMC Envoy?

Start by removing the electrical connector and the rear interior trim panel which hides the actuator before proceeding to remove the actuator. To remove the actuator start by taking off the actuator retaining nuts and removing the actuator arm from the window hinge screw followed by taking out the actuator from the vehicle. A 2.0 mm (0.08 in) pin should be used to fasten the window bracket to the window frame. Position the actuator over the mounting studs before installing retaining nuts which need to be tightened to 7 n.m (2 lb in). Connect the electrical connector . The factory sets a proper timing on new actuators during their manufacturing stage. The window latch bracket of an old actuator requires attachment to the window frame using a 2.0 mm (0.08 in) pin while the bellcrank needs a 45-degree placement in relation to the vertical edge of the window side sheet metal. The body side power window switches (1 or 2) located at the overhead console can be used to set the bellcrank to its correct angular position. The bellcrank arm requires alignment at a 45-degree position that runs parallel to the sheet metal flange until the actuator arm screw can be installed. Fasten and tighten the actuator arm screw at 5 n.m (44 lb in) when attaching the window bracket to the actuator arm. After verifying the body side window function complete the installation by putting back the rear interior trim panel.

OEM GMC Envoy Window Motor

Window Lift Motor

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

6 Window Motors found

View related parts
GMC Envoy Window Motor Part Number: 88980706
$61.01 MSRP: $185.29
You Save: $124.28 (68%)
ADD TO CART
Product Specifications
- Other Name: Motor, Front Door Window Regulator; Motor; Motor, Door And End Gate Electrical
- Position: Rear
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2002-2009 GMC Envoy | Denali, SLE, SLT | 6 Cyl 4.2 L GAS, 8 Cyl 5.3 L GAS
View related parts
GMC Envoy Window Motor Part Number: 88980704
$109.44 MSRP: $204.22
You Save: $94.78 (47%)
ADD TO CART
Product Specifications
- Other Name: Motor, Front Side Door Window Regulator; Motor, Door And End Gate Electrical
- Position: Front
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2002-2007 GMC Envoy | Denali, SLE, SLT | 6 Cyl 4.2 L GAS, 8 Cyl 5.3 L GAS
View related parts
GMC Envoy Window Motor Part Number: 88980703
$115.06 MSRP: $208.26
You Save: $93.20 (45%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Motor, Front Side Door Window Regulator; Motor, Door And End Gate Electrical
- Position: Front
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2002-2007 GMC Envoy | Denali, SLE, SLT | 6 Cyl 4.2 L GAS, 8 Cyl 5.3 L GAS
View related parts
GMC Envoy Window Motor, Front Part Number: 19257036
$124.11 MSRP: $220.66
You Save: $96.55 (44%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Motor Assembly, Front Side Door Window Regulator; Motor, Door And End Gate Electrical
- Position: Front
- Replaces: 89046086, 19167174
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2008-2009 GMC Envoy | Denali, SLE, SLT | 6 Cyl 4.2 L GAS, 8 Cyl 5.3 L GAS
View related parts
GMC Envoy Window Motor Part Number: 88980705
Product Specifications
- Other Name: Motor Assembly, Rear Side Door Window Regulator; Motor; Motor, Door And End Gate Electrical; Window Regulator
- Position: Rear
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2002-2009 GMC Envoy | Denali, SLE, SLT | 6 Cyl 4.2 L GAS, 8 Cyl 5.3 L GAS
View related parts
GMC Envoy Window Motor, Front Part Number: 19257037
Product Specifications
- Other Name: Motor Assembly, Front Side Door Window Regulator; Motor, Door And End Gate Electrical
- Position: Front
- Replaces: 19167173, 89046087
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2006-2009 GMC Envoy | Denali, SLE, SLT | 6 Cyl 4.2 L GAS, 8 Cyl 5.3 L GAS

GMC Envoy Window Motor

Want to cut long-term maintenance and repair costs? Choose OEM Window Motor. Those parts deliver top durability you can trust. On our site, you'll find a huge catalog of genuine GMC Envoy parts. Prices are unbeatable, so you can keep more in your pocket. Every OEM GMC Envoy Window Motor includes a manufacturer's warranty. You can also get an easy return policy that keeps buying risk free. Fast delivery, get your car on the road quickly. It's simple to search, compare, and order. Stop guessing about quality or fit. Order today and save with parts that last.

The GMC Envoy Window Motor part is a critical system that greatly boosts the stability of the GMC Envoy series vehicles, which were manufactured between 1998 and 2009. This Window Motor is used in coordination with window regulator to enable window to move up and down whenever the switch is pressed. The GMC Envoy Window Motor must be in optimum condition so that the cabin of the car will not be affected, the signs of a bad motor includes slow operation, wrong direction or no operation at all. GMC Envoy has a distinct strength in every engineering and functional performance that has been applauded by many car publications, including Motor Trend's Sport Utility of the Year in 2002, therefore underlining the significance of a reliable part like the Window Motor. Forward compatibility across different models of Envoy such as the first generation and the second generation enables the owners to continue servicing the cars to optimize on efficiency and safety. However, one has to be keen and considerate of certain aspects when choosing automobile spare parts in the market most especially the GMC Envoy Window Motor in that it is stronger and easier to fix than any other spare part that is why any automaker will love to add it on his or her vehicle. Thus, the function of the GMC Envoy Window Motor is to guarantee that all the windows open and close without any problems helping to create a safe driving environment as well as safeguarding passengers from existing extreme conditions and contribute to the efficient functioning of the GMC Envoy.

GMC Envoy Window Motor Parts Questions & Experts Answers

Window Motor
88980703
Q: How to Service and Repair a Rear Quarter Window Motor on GMC Envoy?
A:
Start by removing the electrical connector and the rear interior trim panel which hides the actuator before proceeding to remove the actuator. To remove the actuator start by taking off the actuator retaining nuts and removing the actuator arm from the window hinge screw followed by taking out the actuator from the vehicle. A 2.0 mm (0.08 in) pin should be used to fasten the window bracket to the window frame. Position the actuator over the mounting studs before installing retaining nuts which need to be tightened to 7 n.m (2 lb in). Connect the electrical connector . The factory sets a proper timing on new actuators during their manufacturing stage. The window latch bracket of an old actuator requires attachment to the window frame using a 2.0 mm (0.08 in) pin while the bellcrank needs a 45-degree placement in relation to the vertical edge of the window side sheet metal. The body side Power Window Switches (1 or 2) located at the overhead console can be used to set the bellcrank to its correct angular position. The bellcrank arm requires alignment at a 45-degree position that runs parallel to the sheet metal flange until the actuator arm screw can be installed. Fasten and tighten the actuator arm screw at 5 n.m (44 lb in) when attaching the window bracket to the actuator arm. After verifying the body side window function complete the installation by putting back the rear interior trim panel.
