How to replace the rear Fender Splash Shield on 2002 Chevrolet Monte Carlo?

Vehicle elevation followed by support is needed before tire removal enables access to the rear wheelhouse splash shield panel. Pull out the three securing screws: one from the rocker panel to rear wheelhouse splash shield section and two from the quarter panel to rear wheelhouse splash shield region along with the single screw from the lower quarter panel to rear wheelhouse splash shield. The J 38778 Door Trim Pad Clip Remover (J 38778) helps uninstall the lower quarter panel to rear wheelhouse splash shield push-in retainer and afterwards enables the removal of the rear wheelhouse splash shield to rear wheelhouse palnuts followed by the removal of the rear wheelhouse splash shield from the vehicle. Chose a proper position for the rear wheelhouse splash shield relative to the wheelhouse then install it on the wheelhouse palnuts while tightening to 2 N.m (18 lb in). You should install the lower quarter panel to rear wheelhouse splash shield push-in retainer followed by lower quarter panel to rear wheelhouse splash shield screw while torquing both components to 2 N.m (18 lb in). Screw and tighten rear wheelhouse splash shield screws of the quarter panel to 2 N.m (18 lb in) before installing the rocker panel to rear wheelhouse splash shield screw which requires a torque of 2 N.m (18 lb in). Reposition the rear tires together with wheels after lowering the vehicle.

OEM 2002 Chevrolet Monte Carlo Fender Splash Shield

Wheelhouse Liner

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

8 Fender Splash Shields found

View related parts
2002 Chevrolet Monte Carlo Splash Shield, Passenger Side
Part Number: 10349808
$14.30 MSRP: $21.29
You Save: $6.99 (33%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Shield-Engine Splash; Fender Splash Shield; Shield, Front Fender Inner Wheel House
- Position: Passenger Side
- Replaces: 10298111
- Item Weight: 0.60 Pounds
- Item Dimensions: 25.0 x 13.4 x 6.9 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 10349808
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2002 Chevrolet Monte Carlo Submodels:
- LS, LS Competition, LS Sport, LT, LTZ, SS, SS 35th Anniversary Edition, SS Dale Earnhardt Signature Edition, SS High Sport, SS Pace Car | 6 Cyl 3.4 L GAS, 6 Cyl 3.5 L FLEX, 6 Cyl 3.5 L GAS, 6 Cyl 3.8 L GAS, 6 Cyl 3.9 L GAS
View related parts
2002 Chevrolet Monte Carlo Fender Liner, Front Passenger Side
Part Number: 19120191
$30.59 MSRP: $45.53
You Save: $14.94 (33%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Liner Assembly, Front Wheelhouse (Right-Hand); Fender Splash Shield; Liner, Front Fender Inner Wheel House
- Position: Front Passenger Side
- Replaces: 10290448, 10440209
- Item Weight: 2.30 Pounds
- Item Dimensions: 56.2 x 16.8 x 20.2 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 19120191
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2002 Chevrolet Monte Carlo Submodels:
- LS, LS Competition, LS Sport, LT, SS, SS 35th Anniversary Edition, SS Dale Earnhardt Signature Edition, SS High Sport, SS Pace Car | 6 Cyl 3.4 L GAS, 6 Cyl 3.8 L GAS
View related parts
2002 Chevrolet Monte Carlo Splash Shield, Driver Side
Part Number: 10349809
$5.47 MSRP: $8.13
You Save: $2.66 (33%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Shield-Engine Splash; Fender Splash Shield; Shield, Front Fender Inner Wheel House
- Position: Driver Side
- Replaces: 10298112
- Item Weight: 0.70 Pounds
- Item Dimensions: 7.7 x 5.4 x 18.7 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 10349809
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2002 Chevrolet Monte Carlo Submodels:
- LS, LS Competition, LS Sport, LT, LTZ, SS, SS 35th Anniversary Edition, SS Dale Earnhardt Signature Edition, SS High Sport, SS Pace Car | 6 Cyl 3.4 L GAS, 6 Cyl 3.5 L FLEX, 6 Cyl 3.5 L GAS, 6 Cyl 3.8 L GAS, 6 Cyl 3.9 L GAS
View related parts
2002 Chevrolet Monte Carlo Front Panel, Inner Driver Side
Part Number: 10241007
Product Specifications
- Other Name: Extension, Front Fender Inner Wheel House
- Position: Front Inner Driver Side
- Item Weight: 1.60 Pounds
- Item Dimensions: 6.6 x 6.7 x 15.1 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 10241007
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2002 Chevrolet Monte Carlo Submodels:
- LS, LS Competition, LS Sport, LT, SS, SS 35th Anniversary Edition, SS Dale Earnhardt Signature Edition, SS High Sport, SS Pace Car | 6 Cyl 3.4 L GAS, 6 Cyl 3.8 L GAS
View related parts
2002 Chevrolet Monte Carlo Liner, Rear Driver Side
Part Number: 19120196
Product Specifications
- Other Name: Liner, Rear Wheelhouse
- Position: Rear Driver Side
- Replaces: 10439812
- Item Weight: 3.00 Pounds
- Item Dimensions: 40.8 x 13.3 x 26.4 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 19120196
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2002 Chevrolet Monte Carlo Submodels:
- LS, LS Competition, LS Sport, LT, SS, SS 35th Anniversary Edition, SS Dale Earnhardt Signature Edition, SS High Sport, SS Pace Car | 6 Cyl 3.4 L GAS, 6 Cyl 3.8 L GAS
View related parts
2002 Chevrolet Monte Carlo Fender Liner, Front Inner Driver Side
Part Number: 19120192
Product Specifications
- Other Name: Liner, Front Fender Inner Wheel House; Fender Splash Shield
- Position: Front Inner Driver Side
- Replaces: 10290449, 10440210
- Item Weight: 6.30 Pounds
- Item Dimensions: 30.6 x 27.2 x 14.0 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 19120192
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2002 Chevrolet Monte Carlo Submodels:
- LS, LS Competition, LS Sport, LT, SS, SS 35th Anniversary Edition, SS Dale Earnhardt Signature Edition, SS High Sport, SS Pace Car | 6 Cyl 3.4 L GAS, 6 Cyl 3.8 L GAS
View related parts
2002 Chevrolet Monte Carlo Front Panel, Inner Passenger Side
Part Number: 10299383
Product Specifications
- Other Name: Extension, Front Fender Inner Wheel House
- Position: Front Inner Passenger Side
- Replaces: 10241006
- Item Weight: 1.60 Pounds
- Item Dimensions: 14.6 x 6.2 x 6.0 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 10299383
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2002 Chevrolet Monte Carlo Submodels:
- LS, LS Competition, LS Sport, LT, SS, SS 35th Anniversary Edition, SS Dale Earnhardt Signature Edition, SS High Sport, SS Pace Car | 6 Cyl 3.4 L GAS, 6 Cyl 3.8 L GAS
View related parts
2002 Chevrolet Monte Carlo Liner, Rear Passenger Side
Part Number: 19120195
Product Specifications
- Other Name: Liner, Rear Wheelhouse
- Position: Rear Passenger Side
- Replaces: 10439811
- Item Weight: 6.30 Pounds
- Item Dimensions: 34.7 x 24.5 x 11.1 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 19120195
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2002 Chevrolet Monte Carlo Submodels:
- LS, LS Competition, LS Sport, LT, SS, SS 35th Anniversary Edition, SS Dale Earnhardt Signature Edition, SS High Sport, SS Pace Car | 6 Cyl 3.4 L GAS, 6 Cyl 3.8 L GAS

2002 Chevrolet Monte Carlo Fender Splash Shield

With a comprehensive array of OEM 2002 Chevrolet Monte Carlo Fender Splash Shield, from fuel pumps to door handles, our website is a one-stop-shop for your needs. All our genuine 2002 Chevrolet Monte Carlo Fender Splash Shield are backed by the manufacturer's warranty and are offered at competitive prices in the market. Rest assured, you can shop with complete confidence.

2002 Chevrolet Monte Carlo Parts Questions & Experts Answers

Q: How to replace the rear Fender Splash Shield on 2002 Chevrolet Monte Carlo?
A: Vehicle elevation followed by support is needed before tire removal enables access to the rear wheelhouse splash shield panel. Pull out the three securing screws: one from the rocker panel to rear wheelhouse splash shield section and two from the quarter panel to rear wheelhouse splash shield region along with the single screw from the lower quarter panel to rear wheelhouse splash shield. The J 38778 Door Trim Pad Clip Remover (J 38778) helps uninstall the lower quarter panel to rear wheelhouse splash shield push-in retainer and afterwards enables the removal of the rear wheelhouse splash shield to rear wheelhouse palnuts followed by the removal of the rear wheelhouse splash shield from the vehicle. Chose a proper position for the rear wheelhouse splash shield relative to the wheelhouse then install it on the wheelhouse palnuts while tightening to 2 N.m (18 lb in). You should install the lower quarter panel to rear wheelhouse splash shield push-in retainer followed by lower quarter panel to rear wheelhouse splash shield screw while torquing both components to 2 N.m (18 lb in). Screw and tighten rear wheelhouse splash shield screws of the quarter panel to 2 N.m (18 lb in) before installing the rocker panel to rear wheelhouse splash shield screw which requires a torque of 2 N.m (18 lb in). Reposition the rear tires together with wheels after lowering the vehicle.
