How to replace the A/C Hose in the HVAC system on Buick Rendezvous?

The replacement of the suction hose in hvac systems requires Battery Cable disconnection followed by refrigerant recovery from the a/c system. Place the vehicle on a support stand and eliminate the air baffle bolts while taking away the entire air baffle. The next step involves removing the suction hose to evaporator outlet tube bolt followed by disconnecting the suction hose from the evaporator outlet tube. System contamination should be prevented by immediately capping or taping the open A/C Hose before you cap or tape off the evaporator outlet tube. Before taking apart the suction hose from the compressor, remove its nut then disconnect and cap the suction hose from the compressor suction port. Discard the sealing washers. Before seating a new compressor-end suction hose sealing washer users must clean both components and suction hose sealing surfaces with a lint-free dry-cloth before pressing the washer into position. Connect the suction hose to the compressor after you remove the cap or tape from the compressor suction port and tighten the hose to compressor nut to 16 n.m (12 lb ft). The service technician needs to install a new sealing washer at the suction hose to evaporator outlet tube fitting and remove any caps or tape before connecting the suction hose. After which the fitting bolt should be tightened to 16 n.m (12 lb ft). Construct the air baffle and its bolts by torquing them to 20 n.m (15 lb ft). After lowering the vehicle remove any air in the a/c system. Perform a leak test on component fittings through utilization of the halogen leak detector (J 39400-A) after which reconnect the negative Battery Cable.

OEM Buick Rendezvous A/C Hose

Air Conditioning Hose

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

7 A/C Hoses found

View related parts
Buick Rendezvous A/C Hose Part Number: 10315021
Product Specifications
- Other Name: Hose Assembly-A/C Compressor; A/C Refrigerant Liquid Hose; Compressor Hose; Pressure Hose; Hose, A/C Compressor
- Replaces: 10413313
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2002-2007 Buick Rendezvous | CX, CX Plus, CXL, CXL Plus | 6 Cyl 3.4 L GAS, 6 Cyl 3.5 L GAS
View related parts
Buick Rendezvous A/C Tube Part Number: 89023448
Product Specifications
- Other Name: Tube, Air Conditioner Refrigerant (All Metal); A/C Refrigerant Liquid Hose; A/C Hose; Evaporator Tube; Tube, A/C Refrigerant (All Metal)
- Replaces: 10306427, 10378921, 10321971, 10321972
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2002-2007 Buick Rendezvous | CX, CX Plus, CXL, CXL Plus | 6 Cyl 3.4 L GAS, 6 Cyl 3.5 L GAS
View related parts
Buick Rendezvous A/C Tube Part Number: 10378922
Product Specifications
- Other Name: Tube, Air Conditioner Refrigerant (All Metal); A/C Refrigerant Liquid Hose; A/C Hose; Tube, A/C Refrigerant (All Metal)
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2004-2006 Buick Rendezvous | CX, CXL, CXL Plus, Ultra | 6 Cyl 3.6 L GAS
View related parts
Buick Rendezvous A/C Hose Part Number: 10357768
Product Specifications
- Other Name: Hose, Air Conditioner Compressor; A/C Refrigerant Liquid Hose; Compressor & Condenser Hose; Hose, A/C Compressor
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2004-2006 Buick Rendezvous | CX, CXL, CXL Plus, Ultra | 6 Cyl 3.6 L GAS
View related parts
Buick Rendezvous A/C Line Part Number: 10317080
Product Specifications
- Other Name: Tube Assembly-A/C Evaporator; A/C Refrigerant Liquid Hose; A/C Hose; Tube, A/C Refrigerant (All Metal)
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2002-2007 Buick Rendezvous | CX, CX Plus, CXL, CXL Plus, Ultra | 6 Cyl 3.4 L GAS, 6 Cyl 3.5 L GAS, 6 Cyl 3.6 L GAS
View related parts
Buick Rendezvous A/C Hose Part Number: 10314343
Product Specifications
- Other Name: Hose Assembly-A/C Compressor; A/C Refrigerant Liquid Hose; Compressor Hose; Hose, A/C Compressor
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2004-2006 Buick Rendezvous | CX, CXL, CXL Plus, Ultra | 6 Cyl 3.6 L GAS
View related parts
Buick Rendezvous A/C Hose Part Number: 10307411
Product Specifications
- Other Name: Hose, Air Conditioner Compressor; A/C Refrigerant Liquid Hose; Suction Hose; Compressor & Condenser Hose; Hose, A/C Compressor
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2002-2007 Buick Rendezvous | CX, CX Plus, CXL, CXL Plus | 6 Cyl 3.4 L GAS, 6 Cyl 3.5 L GAS

Buick Rendezvous A/C Hose

Want to cut long-term maintenance and repair costs? Choose OEM A/C Hose. Those parts deliver top durability you can trust. On our site, you'll find a huge catalog of genuine Buick Rendezvous parts. Prices are unbeatable, so you can keep more in your pocket. Every OEM Buick Rendezvous A/C Hose includes a manufacturer's warranty. You can also get an easy return policy that keeps buying risk free. Fast delivery, get your car on the road quickly. It's simple to search, compare, and order. Stop guessing about quality or fit. Order today and save with parts that last.

Buick Rendezvous A/C Hose is one of the most crucial parts that play a major role in boosting the functionality and efficiency of the car's A/C system. This A/C Hose is for Buick Rendezvous 2002 to 2007 usable in economic conveyancers to effectively transfer the refrigerant recommended from the A/C compressor to other parts and coolants for the car cabin. A/C Hose construction include aluminum fittings that are crimped at both ends; this is due to the knowledge that the working pressure of refrigerant gas is extremely high; thereby preventing leakage of the refrigerant gas and improving its durability. This reliability is very important to keep drivers comfortable and safely on the roads especially in adverse weather conditions. There are no specific models of the Buick Rendezvous A/C Hose because it is easy to install and offered in the market for all models of this car. It is therefore critical to understand that the A/C Hose provides a significant function in relation to heat transfer as a determinant of the Buick Rendezvous's general performance for a comfortable and great driving experience. Further, the specially strong A/C Hose is notable in the automotive market to offer a strong emphasis on the quality of automotive products with reference to Buick's focus on the context of supplying the vehicles to meet the demand of today's drivers. This Buick Rendezvous A/C Hose bearing attributes of reliability, performance and compatibility represents a vital part of this prestigious auto maker's strength that laid a strong foundation of solidity and luxury in this mid-size crossover SUV market category.

Buick Rendezvous A/C Hose Parts Questions & Experts Answers

A/C Hose
10315021
Q: How to replace the A/C Hose in the HVAC system on Buick Rendezvous?
A:
The replacement of the suction hose in hvac systems requires Battery Cable disconnection followed by refrigerant recovery from the a/c system. Place the vehicle on a support stand and eliminate the air baffle bolts while taking away the entire air baffle. The next step involves removing the suction hose to evaporator outlet tube bolt followed by disconnecting the suction hose from the evaporator outlet tube. System contamination should be prevented by immediately capping or taping the open A/C Hose before you cap or tape off the evaporator outlet tube. Before taking apart the suction hose from the compressor, remove its nut then disconnect and cap the suction hose from the compressor suction port. Discard the sealing washers. Before seating a new compressor-end suction hose sealing washer users must clean both components and suction hose sealing surfaces with a lint-free dry-cloth before pressing the washer into position. Connect the suction hose to the compressor after you remove the cap or tape from the compressor suction port and tighten the hose to compressor nut to 16 n.m (12 lb ft). The service technician needs to install a new sealing washer at the suction hose to evaporator outlet tube fitting and remove any caps or tape before connecting the suction hose. After which the fitting bolt should be tightened to 16 n.m (12 lb ft). Construct the air baffle and its bolts by torquing them to 20 n.m (15 lb ft). After lowering the vehicle remove any air in the a/c system. Perform a leak test on component fittings through utilization of the halogen leak detector (J 39400-A) after which reconnect the negative Battery Cable.
