How to service and repair the coolant reservoir on Cadillac DeVille?

Start Coolant Reservoir service and repair by draining part of the engine coolant. You need to disconnect both the surge tank inlet hose from its surge tank location and the connector from its Coolant Level Sensor connection point. Remove the secondary air relay bracket mounting nuts before you uninstall the secondary air relay bracket . The hose clamp remover/installer tool (J 37097-A) will remove the surge tank outlet hose during this process. Begin surge tank installation by removing the surge tank mounting screws followed by its nuts to extract the tank. To perform installation put the surge tank above the wheelhouse's two studs before tightening surge tank bolts to 6 nm (53 inch lbs.). After installing the surge tank nuts follow the same torque procedure. Avatel j 37097-a enables you to join the surge tank outlet hose to the surge tank using its tool once again. Place the secondary air relay bracket over locomotive studs while securing it through its two secondary air relay bracket nuts to a torque of 6 nm (53 inch lbs.). Finish up by connecting the sensor connector and hooking back the surge tank inlet hose to the tank. Once complete, fill the cooling system.

OEM Cadillac DeVille Coolant Reservoir

Coolant Tank Reservoir

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

8 Coolant Reservoirs found

View related parts
Cadillac DeVille Reservoir Tank
Part Number: 19129961
$113.75 MSRP: $168.52
You Save: $54.77 (33%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Tank, Radiator Surge; Coolant Reservoir; Recovery Tank; Tank, Engine Coolant Recovery
- Replaces: 03540041, 3540041
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1994-1999 Cadillac DeVille | Base, Concours, d'Elegance | 8 Cyl 4.6 L GAS
View related parts
Cadillac DeVille Reservoir Tank
Part Number: 25774005
Product Specifications
- Other Name: Container, Heater Coolant Tank; Coolant Reservoir; Recovery Tank; Tank, Engine Coolant Recovery
- Replaces: 25748905, 25741919, 25654619
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2000-2005 Cadillac DeVille | Base, DHS, DTS, Protection Series | 8 Cyl 4.6 L GAS
View related parts
Cadillac DeVille Recovery Tank
Part Number: 25636828
Product Specifications
- Other Name: Reservoir, Coolant Recovery; Coolant Reservoir; Reservoir, Engine Coolant Recovery
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1991-1993 Cadillac DeVille | Base, Spring Edition, Touring | 8 Cyl 4.9 L GAS
View related parts
Cadillac DeVille Recovery Tank
Part Number: 25529265
Product Specifications
- Other Name: Reservoir, Engine Coolant Recovery; Coolant Reservoir
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1987-1990 Cadillac DeVille | Base, d'Elegance, Touring | 8 Cyl 4.1 L GAS, 8 Cyl 4.5 L GAS
View related parts
Cadillac DeVille Recovery Tank
Part Number: 3543028
Product Specifications
- Other Name: Reservoir Assembly-Coolant Recovery; Serpentine Belt Drive Kit; Coolant Reservoir; Serpentine Tensioner; Reservoir, Engine Coolant Recovery
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1994-1995 Cadillac DeVille | Base | 8 Cyl 4.9 L GAS
View related parts
Cadillac DeVille Recovery Tank
Part Number: 25528889
Product Specifications
- Other Name: Reservoir, Engine Coolant Recovery; Coolant Reservoir
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1986 Cadillac DeVille | d'Elegance, Touring | 8 Cyl 4.1 L GAS
View related parts
Cadillac DeVille Recovery Tank
Part Number: 25523627
Product Specifications
- Other Name: Reservoir, Engine Coolant Recovery; Coolant Reservoir
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1985 Cadillac DeVille | Base, Cabriolet, d'Elegance | 6 Cyl 4.3 L DIESEL, 8 Cyl 4.1 L GAS
View related parts
Cadillac DeVille Reservoir Tank
Part Number: 1617643
Product Specifications
- Other Name: Reservoir; Coolant Reservoir; Recovery Tank; Reservoir, Engine Coolant Recovery
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1984-1987 Cadillac DeVille | Base, Cabriolet, d'Elegance, Touring | 8 Cyl 4.1 L GAS, 8 Cyl 5.7 L DIESEL

Cadillac DeVille Coolant Reservoir

Our website offers an extensive catalog of genuine Cadillac DeVille Coolant Reservoir at unbeatable prices. Every OEM Cadillac DeVille Coolant Reservoir comes with a manufacturer's warranty, an easy return policy, and rapid delivery service. Don't miss out on this great opportunity!

Cadillac DeVille Coolant Reservoir Parts Questions & Experts Answers

Reservoir Tank
25774005
Q: How to service and repair the coolant reservoir on Cadillac DeVille?
A: Start Coolant Reservoir service and repair by draining part of the engine coolant. You need to disconnect both the surge tank inlet hose from its surge tank location and the connector from its Coolant Level Sensor connection point. Remove the secondary air relay bracket mounting nuts before you uninstall the secondary air relay bracket . The hose clamp remover/installer tool (J 37097-A) will remove the surge tank outlet hose during this process. Begin surge tank installation by removing the surge tank mounting screws followed by its nuts to extract the tank. To perform installation put the surge tank above the wheelhouse's two studs before tightening surge tank bolts to 6 nm (53 inch lbs.). After installing the surge tank nuts follow the same torque procedure. Avatel j 37097-a enables you to join the surge tank outlet hose to the surge tank using its tool once again. Place the secondary air relay bracket over locomotive studs while securing it through its two secondary air relay bracket nuts to a torque of 6 nm (53 inch lbs.). Finish up by connecting the sensor connector and hooking back the surge tank inlet hose to the tank. Once complete, fill the cooling system.
