How to replace a muffler on Cadillac Seville?

Begin by raising your vehicle then support both the Exhaust Pipe and the Muffler whenever possible. A suitable cut-off tool should be used to cut the Exhaust Pipe right next to where it connects to the welded section on the Muffler. Lift the rear Exhaust Hanger out first by removing its securing nut from the rear Exhaust Hanger bracket and its attachment to the vehicle. Put sufficient lubricant on the tail pipe hanger rod to make the hanger easy to remove before pulling the rear Exhaust Hanger off the rod. After joining the Muffler with the Exhaust Pipe keep the Muffler clamp loose during installation. Before fitting the rear Exhaust Hanger, apply soapy solution to the tail pipe hanger rod and the inner diameter of the hanger. Next, slide the hanger onto the rod and position it to fit the rear Exhaust Hanger bracket. Tighten the rear Exhaust Hanger nut to 30 nm (22 ft. Lbs.) during installation onto the rear Exhaust Hanger bracket. Secure the Muffler on the vehicle by making the rear tail pipe opening level and tighten both clamp nuts to a torque of 40 nm (30 ft. Lbs.) before the vehicle descent.

OEM Cadillac Seville Muffler

Exhaust Muffler

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

32 Mufflers found

View related parts
Cadillac Seville Muffler, Passenger Side
Part Number: 25640095
Product Specifications
- Other Name: Muffler, Exhaust
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1996-1997 Cadillac Seville | SLS, STS | 8 Cyl 4.6 L GAS
View related parts
Cadillac Seville Muffler & Pipe
Part Number: 25748929
Product Specifications
- Other Name: Muffler Assembly-Exhaust (W/Exhaust & Tail Pipe & 3W; Exhaust Pipe; Muffler, Exhaust; Muffler
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2004 Cadillac Seville | SLS | 8 Cyl 4.6 L GAS
View related parts
Cadillac Seville Muffler & Pipe
Part Number: 88959334
Product Specifications
- Other Name: Muffler Assembly, Exhaust (W/Exhaust & Tail Pipe & 3Way Catalytic Converter; Exhaust Pipe; Muffler, Exhaust; Muffler
- Replaces: 25727008, 25727009, 88959333
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2002-2003 Cadillac Seville | SLS, STS | 8 Cyl 4.6 L GAS
View related parts
Cadillac Seville Muffler
Part Number: 1628406
Product Specifications
- Other Name: Muffler, Exhaust
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1984-1985 Cadillac Seville | Base, Elegante | 8 Cyl 4.1 L GAS
View related parts
Cadillac Seville Muffler & Pipe
Part Number: 25632778
Product Specifications
- Other Name: Muffler, Exhaust; Exhaust Pipe; Muffler
- Replaced by: 25644674
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1995 Cadillac Seville | SLS, STS | 8 Cyl 4.6 L GAS
View related parts
Cadillac Seville Muffler, Driver Side
Part Number: 25644674
Product Specifications
- Other Name: Muffler Assembly-Exhaust W/Tail Pipe Left-Hand; Muffler, Exhaust Tail Pipe; Muffler, Exhaust
- Position: Driver Side
- Replaces: 25632778, 25641774
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1995-1997 Cadillac Seville | SLS, STS | 8 Cyl 4.6 L GAS
View related parts
Cadillac Seville Muffler, Driver Side
Part Number: 25663806
Product Specifications
- Other Name: Muffler Assembly-Exhaust (W/Tail Pipe) Left-Hand; Muffler, Exhaust Tail Pipe; Muffler, Exhaust
- Position: Driver Side
- Replaces: 25650061
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1997 Cadillac Seville | SLS, STS | 8 Cyl 4.6 L GAS
View related parts
Cadillac Seville Muffler & Pipe, Passenger Side
Part Number: 3531055
Product Specifications
- Other Name: Muffler Assembly-Exhaust (W/Tail Pipe); Exhaust Pipe; Muffler; Muffler, Exhaust
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1993 Cadillac Seville | Base | 8 Cyl 4.9 L GAS
View related parts
Cadillac Seville Rear Muffler, Driver Side
Part Number: 3529188
Product Specifications
- Other Name: Muffler Assembly-Exhaust (W/Exhaust Pipe & Tail Pipe); Muffler & Pipe; Muffler; Muffler, Exhaust; Exhaust Pipe
- Position: Driver Side
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1993-1995 Cadillac Seville | SLS, STS | 8 Cyl 4.6 L GAS
View related parts
Cadillac Seville Intermed Pipe
Part Number: 3537025
Product Specifications
- Other Name: Muffler Assembly-Exhaust (W/ Exhaust Pipe & Tail Pipe); Muffler; Muffler, Exhaust
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1993-1995 Cadillac Seville | SLS, STS | 8 Cyl 4.6 L GAS
View related parts
Cadillac Seville Muffler & Pipe, Driver Side
Part Number: 3522853
Product Specifications
- Other Name: Muffler Assembly- Exhaust (W/Tail Pipe); Exhaust Pipe; Case; Muffler; Muffler, Exhaust
- Position: Driver Side
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1992 Cadillac Seville | Base, STS | 8 Cyl 4.9 L GAS
View related parts
Cadillac Seville Muffler & Pipe, Passenger Side
Part Number: 25663812
Product Specifications
- Other Name: Muffler Assembly-Exhaust (W/Resonator, Exhaust & Tail Pipe) Right-Hand; Exhaust Pipe; Muffler, Exhaust Tail Pipe; Muffler, Exhaust; Muffler
- Position: Passenger Side
- Replaces: 25642877
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1997 Cadillac Seville | SLS, STS | 8 Cyl 4.6 L GAS
View related parts
Cadillac Seville Intermediate Pipe
Part Number: 25644677
Product Specifications
- Other Name: Muffler, Exhaust; Exhaust Pipe; Muffler & Pipe; Muffler, Exhaust Tail Pipe; Muffler
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1996-1997 Cadillac Seville | SLS, STS | 8 Cyl 4.6 L GAS
View related parts
Cadillac Seville Intermediate Pipe
Part Number: 3537027
Product Specifications
- Other Name: Muffler Assembly-Exhaust (W/Exhaust Pipe & Tail Pipe); Intermed Pipe; Muffler, Exhaust; Exhaust Pipe
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1993 Cadillac Seville | Base | 8 Cyl 4.9 L GAS
View related parts
Cadillac Seville Intermediate Pipe
Part Number: 3537026
Product Specifications
- Other Name: Muffler Assembly-Exhaust (W/Exhaust Pipe & Tail Pipe); Intermed Pipe; Muffler, Exhaust; Exhaust Pipe
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1993-1995 Cadillac Seville | SLS, STS | 8 Cyl 4.6 L GAS
View related parts
Cadillac Seville Muffler W/Tpipe, Passenger Side
Part Number: 25670398
Product Specifications
- Other Name: Muffler, Exhaust; Exhaust Pipe; Muffler; Muffler, Exhaust Tail Pipe
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1998-2002 Cadillac Seville | STS | 8 Cyl 4.6 L GAS
View related parts
Cadillac Seville Muffler W/Tpipe, Driver Side
Part Number: 25670399
Product Specifications
- Other Name: Muffler, Exhaust (W/Tail Pipe); Exhaust Pipe; Muffler
- Position: Driver Side
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1998-2002 Cadillac Seville | STS | 8 Cyl 4.6 L GAS
View related parts
Cadillac Seville Intermed Pipe
Part Number: 25641855
Product Specifications
- Other Name: Muffler, Exhaust; Exhaust Pipe; Muffler, Exhaust Tail Pipe
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1995 Cadillac Seville | SLS, STS | 8 Cyl 4.6 L GAS
View related parts
Cadillac Seville Muffler W/Tpipe, Passenger Side
Part Number: 25670396
Product Specifications
- Other Name: Muffler, Exhaust; Exhaust Pipe; Muffler; Muffler, Exhaust Tail Pipe
- Position: Passenger Side
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1998-2002 Cadillac Seville | SLS | 8 Cyl 4.6 L GAS
View related parts
Cadillac Seville Catalytic Converter
Part Number: 25727006
Product Specifications
- Other Name: Muffler Assembly-Exhaust (W/Exhaust & Tail Pipe & 3W; Exhaust Pipe; Muffler; Muffler Assembly; Converter & Pipe
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2002-2003 Cadillac Seville | STS | 8 Cyl 4.6 L GAS

| Page 1 of 2 |Next >

1-20 of 32 Results

Cadillac Seville Muffler

Our website offers an extensive catalog of genuine Cadillac Seville Muffler at unbeatable prices. Every OEM Cadillac Seville Muffler comes with a manufacturer's warranty, an easy return policy, and rapid delivery service. Don't miss out on this great opportunity!

Cadillac Seville Muffler Parts Questions & Experts Answers

Muffler W/Tpipe, Driver Side
25670397
Q: How to replace a muffler on Cadillac Seville?
A: Begin by raising your vehicle then support both the Exhaust Pipe and the Muffler whenever possible. A suitable cut-off tool should be used to cut the Exhaust Pipe right next to where it connects to the welded section on the Muffler. Lift the rear Exhaust Hanger out first by removing its securing nut from the rear Exhaust Hanger bracket and its attachment to the vehicle. Put sufficient lubricant on the tail pipe hanger rod to make the hanger easy to remove before pulling the rear Exhaust Hanger off the rod. After joining the Muffler with the Exhaust Pipe keep the Muffler clamp loose during installation. Before fitting the rear Exhaust Hanger, apply soapy solution to the tail pipe hanger rod and the inner diameter of the hanger. Next, slide the hanger onto the rod and position it to fit the rear Exhaust Hanger bracket. Tighten the rear Exhaust Hanger nut to 30 nm (22 ft. Lbs.) during installation onto the rear Exhaust Hanger bracket. Secure the Muffler on the vehicle by making the rear tail pipe opening level and tighten both clamp nuts to a torque of 40 nm (30 ft. Lbs.) before the vehicle descent.
