How to remove and reinstall the A/C Condenser in an HVAC system for different engine types on Chevrolet Camaro?

To take the condenser hva off, take the refrigerant first. For the 3.8 l engine, remove the intake air temperature (IAT) sensor connector form the air intake duct, and for the 5.7 l engine, remove the iat sensor and mass air flow (MAF) sensor connectors from the air intake duct. Displace the air intake duct for both engine types afterward displace our Radiator support and heave up the vehicle. Unscrew the air conditioning (A/C) compressor and condenser hose nut, and throw away the o-ring, then unscrew the a/c evaporator tube bolt at the condenser, and throw away its o-ring, also. Secondly, you should take off the Radiator air upper baffle from condenser and remove the condenser from Radiator. To install it, mount back the condenser onto the Radiator and mount the Radiator air upper baffle back. Change a new o-ring and apply a 16 n.m (12 lb ft) torque to the a/c evaporator tube bolt at the condenser. Install another new o-ring and connect the A/C Compressor and condenser hose nut at the condenser, while tightening this nut to 16 n.m (12 lb ft). Lower the vehicle, put Radiator support back in, air intake duct 5.7 and after that the air intake duct 3.8 l one. Join the connectors of the iat sensors and maf sensors for the 5.7 l engine, and iat sensor for the 3.8 l engine. Finally, recharge the a/c system and proceed with a leak test.

OEM Chevrolet Camaro A/C Condenser

Air Conditioning Condenser

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

13 A/C Condensers found

View related parts
Chevrolet Camaro Condenser
Part Number: 23485898
$179.41 MSRP: $307.23
You Save: $127.82 (42%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser, A/C Condenser
- Replaces: 22927741, 22886745
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2013-2015 Chevrolet Camaro | SS, Z/28 | 8 Cyl 6.2 L GAS, 8 Cyl 7.0 L GAS
View related parts
Chevrolet Camaro Condenser
Part Number: 23456530
$212.94 MSRP: $364.65
You Save: $151.71 (42%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser, A/C Condenser
- Replaces: 22786866, 22850822, 22886747
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2012-2015 Chevrolet Camaro | LS, LT, SS | 6 Cyl 3.6 L GAS, 8 Cyl 6.2 L GAS
View related parts
Chevrolet Camaro Condenser
Part Number: 22886747
$212.94 MSRP: $364.65
You Save: $151.71 (42%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Condenser, A/C; A/C Condenser
- Replaced by: 23456530
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2012-2015 Chevrolet Camaro | LS, LT, SS | 6 Cyl 3.6 L GAS, 8 Cyl 6.2 L GAS
View related parts
Chevrolet Camaro Condenser
Part Number: 84947859
$147.13 MSRP: $251.97
You Save: $104.84 (42%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser, A/C Condenser
- Replaced by: 86551898
- Replaces: 23455461
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2016-2024 Chevrolet Camaro | LT1, SS, ZL1 | 8 Cyl 6.2 L GAS
View related parts
Chevrolet Camaro Oil Cooler
Part Number: 84947858
$183.74 MSRP: $331.88
You Save: $148.14 (45%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Condenser Assembly-A/C; Condenser; Condenser, A/C Condenser
- Replaced by: 86551897
- Replaces: 22966151, 22799449
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2016-2024 Chevrolet Camaro | LS, LT | 4 Cyl 2.0 L GAS, 6 Cyl 3.6 L GAS
View related parts
Chevrolet Camaro Oil Cooler
Part Number: 84947857
$134.89 MSRP: $201.63
You Save: $66.74 (34%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Condenser Assembly-A/C; Condenser; Condenser, A/C Condenser
- Replaced by: 86551896
- Replaces: 23452331
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2016-2024 Chevrolet Camaro | LS, LT | 4 Cyl 2.0 L GAS, 6 Cyl 3.6 L GAS
View related parts
Chevrolet Camaro Condenser
Part Number: 19418868
$228.33 MSRP: $338.26
You Save: $109.93 (33%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Condenser Assembly, A/C; A/C Condenser; Condenser A/C; Condenser, A/C Condenser
- Replaces: 20966055, 92239774, 92218348
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2010-2015 Chevrolet Camaro | LS, LT, SS, Z/28, ZL1 | 6 Cyl 3.6 L GAS, 8 Cyl 6.2 L GAS, 8 Cyl 7.0 L GAS
View related parts
Chevrolet Camaro Condenser
Part Number: 23456531
$249.99 MSRP: $373.69
You Save: $123.70 (34%)
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser, A/C Condenser
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2014-2015 Chevrolet Camaro | Z/28 | 8 Cyl 7.0 L GAS
View related parts
Chevrolet Camaro Condenser
Part Number: 52472662
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser, A/C Condenser
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1998-2002 Chevrolet Camaro | Base, Z28, Z28 SS | 6 Cyl 3.8 L GAS, 8 Cyl 5.7 L GAS
View related parts
Chevrolet Camaro Condenser
Part Number: 52460894
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser, A/C Condenser
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1993-1997 Chevrolet Camaro | Base, Indianapolis 500 Pace Car, RS, Z28 | 6 Cyl 3.4 L GAS, 6 Cyl 3.8 L GAS, 8 Cyl 5.7 L GAS
View related parts
Chevrolet Camaro Condenser
Part Number: 52460637
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser, A/C Condenser
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1992 Chevrolet Camaro | RS, RS Heritage Edition, Z28, Z28 Heritage Edition | 6 Cyl 3.1 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS
View related parts
Chevrolet Camaro Condenser
Part Number: 52451266
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser, A/C Condenser
- Replaces: 03057627, 03050628, 3057627, 3050628
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1984-1991 Chevrolet Camaro | Base, Berlinetta, Iroc-Z, LT, RS, Sport, Z28 | 4 Cyl 2.5 L GAS, 6 Cyl 2.8 L GAS, 6 Cyl 3.1 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS
View related parts
Chevrolet Camaro Condenser
Part Number: 22879422
$180.41 MSRP: $269.66
You Save: $89.25 (34%)
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser, A/C Condenser
- Replaces: 22762594
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2012-2015 Chevrolet Camaro | ZL1 | 8 Cyl 6.2 L GAS

Chevrolet Camaro A/C Condenser

Our website offers an extensive catalog of genuine Chevrolet Camaro A/C Condenser at unbeatable prices. Every OEM Chevrolet Camaro A/C Condenser comes with a manufacturer's warranty, an easy return policy, and rapid delivery service. Don't miss out on this great opportunity!

Chevrolet Camaro A/C Condenser Parts Questions & Experts Answers

Condenser
52472662
Q: How to remove and reinstall the A/C Condenser in an HVAC system for different engine types on Chevrolet Camaro?
A: To take the condenser hva off, take the refrigerant first. For the 3.8 l engine, remove the intake air temperature (IAT) sensor connector form the air intake duct, and for the 5.7 l engine, remove the iat sensor and mass air flow (MAF) sensor connectors from the air intake duct. Displace the air intake duct for both engine types afterward displace our Radiator support and heave up the vehicle. Unscrew the air conditioning (A/C) compressor and condenser hose nut, and throw away the o-ring, then unscrew the a/c evaporator tube bolt at the condenser, and throw away its o-ring, also. Secondly, you should take off the Radiator air upper baffle from condenser and remove the condenser from Radiator. To install it, mount back the condenser onto the Radiator and mount the Radiator air upper baffle back. Change a new o-ring and apply a 16 n.m (12 lb ft) torque to the a/c evaporator tube bolt at the condenser. Install another new o-ring and connect the A/C Compressor and condenser hose nut at the condenser, while tightening this nut to 16 n.m (12 lb ft). Lower the vehicle, put Radiator support back in, air intake duct 5.7 and after that the air intake duct 3.8 l one. Join the connectors of the iat sensors and maf sensors for the 5.7 l engine, and iat sensor for the 3.8 l engine. Finally, recharge the a/c system and proceed with a leak test.
