Make sure this part fits

GM 15829134
Axle Beam Bushing, Rear

1997-2008 GM

Customer Questions & Expert Answers (12)
GM 15829134 Axle Beam Bushing, Rear
GM 15829134 Axle Beam Bushing, Rear
  • Part Description
    Bushing, Rear Axle Control Arm; Axle Support Bushing; Crossmember Bushing; Axle Pivot Bushing
  • Position
    Rear
  • Replaces
    10239185, 10341351, 15219518
  • Manufacturer
    General Motors
Make sure this part fits
$15.84 MSRP: $26.09
You Save: $10.25 (40%)
1
ADD TO CART
  • Related Parts
  • Product Specifications
  • Vehicle Fitment
  • Customer Questions & Expert Answers
  • Product Specifications

    BrandGenuine GM
    Manufacturer Part Number15829134
    Part DescriptionBushing, Rear Axle Control Arm; Axle Support Bushing; Crossmember Bushing; Axle Pivot Bushing
    Other NamesBushing, Rear Axle Support And Control Arm
    Item Dimensions3.2 x 3.2 x 2.7 inches
    Item Weight1.20 Pounds
    PositionRear
    ConditionNew
    Fitment TypeDirect Replacement
    Replaces10239185, 10341351, 15219518
    ManufacturerGeneral Motors
    SKU15829134
    WarrantyThis genuine GM part is guaranteed by GM's factory warranty.
    Shipping & ReturnShipping Policy Return Policy
    Warning: California's Proposition 65
  • Vehicle Fitment

    Year Make Model Trim Engine
    2005-2008 Chevrolet UplanderBase, LS, LT6 Cyl 3.5 L GAS, 6 Cyl 3.9 L FLEX, 6 Cyl 3.9 L GAS
    1997-2005 Chevrolet VentureBase, LS, LT, Plus, Value, Warner Bros.6 Cyl 3.4 L GAS
    1997-2004 Oldsmobile SilhouetteBase, GL, GLS, GS, Premiere6 Cyl 3.4 L GAS
    2001-2005 Pontiac AztekBase, GT, Rally6 Cyl 3.4 L GAS
    1999-2006 Pontiac MontanaBase, SV66 Cyl 3.4 L GAS, 6 Cyl 3.5 L GAS, 6 Cyl 3.9 L GAS
    1997-1998 Pontiac Trans SportBase, Montana6 Cyl 3.4 L GAS
    2005-2007 Saturn Relay1, 2, 36 Cyl 3.5 L GAS, 6 Cyl 3.9 L FLEX, 6 Cyl 3.9 L GAS
  • Customer Questions & Expert Answers

    Q:
    Is this 15829134 designed for my car? Posted by ChevyPartsGiant Specialist
    A:
    Please Select Your Vehicle model to see if part number 15829134 is suitable before ordering.
    Posted by ChevyPartsGiant Specialist
    Q:
    How to replace the control arm bushing in the rear suspension on Chevrolet Uplander? Posted by Customer
    A:
    The replacement process for Control Arm bushings in the rear suspension begins with car elevation and support installation. A utility stand must support the Control Arm by resting in front of the coil spring. Before you can access the Control Arm Bushing you must first detach the rear axle bolts holding the Control Arm and lower the axle. Tag down the correct direction of the Control Arm Bushing when installed in the lower Control Arm. To properly remove and install the Control Arm Bushing use the j 28685 rear suspension bushing remover/installer (J 28685) together with the j 9519-e ball joint remover/installer kit (J 9519-E). During installation position the flat bushing edge at a 90-degree angle toward the fluid axis located 9 degrees off the Control Arm center line. Install the Control Arm Bushing using the j 28685 (J 28685) and j 9519-e (J 9519-E) tools, ensuring it reaches a position 30 mm (1.18 in) beyond the Control Arm. The j 28685 (J 28685) shows proper bushing installation because its end matches the indicator line. Raise the rear axle using a utility stand before installing the Control Arm Bolt to the rear axle and dropping the vehicle.
    Posted by ChevyPartsGiant Specialist
    Q:
    How to service and repair the control arm bushing in the rear suspension on Chevrolet Venture? Posted by Customer
    A:
    To service and repair the Control Arm bushing on the rear suspension, begin by raising and supporting the vehicle. Attach a utility stand to carry the Control Arm in front of the coil spring. Take out the rear axle Control Arm bolts from the rear axle and bring down the rear axle to expose the Control Arm bushing. Mark the Control Arm bushing at the Control Arm on the bottom Control Arm. Use the j 28685 rear suspension bushing remover/installer (J 28685) and the j 9519-e ball joint remover/installer kit (J 9519-E) in removing the Control Arm bushing. For installing, bring the flat edge of the bushing to the mark on the Control Arm to place it on a 45-degree angle, using the j 28685 (J 28685) and j 9519-e (J 9519-E). Ensure that the bushing extends 9.8 mm (0.39 inch) from the Control Arm, check the proper depth when the end of the bushing lines up with the indicator line on the j 28685 (J 28685). It is necessary to lift the rear axle using the utility stand, to connect the Control Arm bolt to the rear axle, to take out the utility stand and then to drop the vehicle.
    Posted by ChevyPartsGiant Specialist
    Q:
    How should the new bushing be positioned during installation for the 2006 Chevrolet Uplander? Posted by Customer
    A:
    Ensure the new bushing is positioned in the same orientation as the old bushing, paying attention to the voids.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Control Arm Bushing
    Q:
    How should the bushing be installed for the 2005 Chevrolet Venture? Posted by Customer
    A:
    Align the flat edge of the bushing with the mark on the control arm and install it at a 45-degree angle.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Control Arm Bushing
    Q:
    Why is it important to mark the control arm bushing for the 2001 Chevrolet Venture? Posted by Customer
    A:
    Mark the orientation of the control arm bushing in the lower control arm for proper installation.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Control Arm Bushing
    Q:
    What should be used to install the new bushing for the 2005 Chevrolet Uplander? Posted by Customer
    A:
    Utilize the Control Arm Bushing Set (J 21474-01) to install the bushing.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Control Arm Bushing
    Q:
    What should be applied to the threads of the Puller Bolt for the 2000 Chevrolet Venture? Posted by Customer
    A:
    Apply high-pressure lubricant (J 23444-A or equivalent) to the threads of the Puller Bolt (J 21474-27).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Control Arm Bushing
    Q:
    What needs to be removed to access the control arm bushing for the 2002 Chevrolet Venture? Posted by Customer
    A:
    The control arm bolts from the rear axle need to be removed.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Control Arm Bushing
    Q:
    What should be done before inserting the bushing into the control arm for the 2003 Chevrolet Venture? Posted by Customer
    A:
    Apply high pressure lubricant (J 23444-A or equivalent) to the threads of the Puller Bolt (J 21474-27) again.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Control Arm Bushing
    Q:
    How should the new bushing be positioned during installation for the 2004 Chevrolet Venture? Posted by Customer
    A:
    Ensure the new bushing is positioned in the same manner as the old bushing, paying attention to the voids.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Control Arm Bushing
    Q:
    What is the final step after tightening the 1/2 Inch Nut during installation for the 2008 Chevrolet Uplander? Posted by Customer
    A:
    Disassemble the tools and install the lower control arm.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Control Arm Bushing
    If you have any questions about this product, please don't hesitate to ask us. We will be happy to help you!

OEM GM 15829134, Excellent Performance and Perfect Fitment

To ensure reliability, purchase GM part # 15829134 Axle Beam Bushing, Rear. It is sometimes referred to as GM Control Arm Bushing, GM Trailing Arm Bushing, GM Axle Beam Mount, GM Axle Pivot Bushing, GM Axle Support Bushings. Choosing OEM parts is the optimal decision for guaranteeing superior quality and perfect performance. These components undergo stringent quality checks and are carefully constructed to comply with GM's factory specifications, ensuring a smooth installation process.

ChevyPartsGiant.com is a leading supplier of genuine GM parts such as GM 15829134 Axle Beam Bushing, Rear. Our website boasts an extensive inventory of OEM GM parts, available at highly competitive prices in the market. Should you require any new genuine GM parts, rest assured we will deliver them swiftly and efficiently to your doorstep. Furthermore, all our parts come with the assurance of a manufacturer's warranty. For detailed Chevy parts information, click here.
Choose ChevyPartsGiant for discounted prices, exceptional service and fast delivery
