Rear Cable

The procedure to replace a Left Rear Park Brake Cable (without RPO NYS) starts by releasing the park brake followed by raising and supporting the vehicle. You should first loosen the equalizer nut which reduces tension on the cables before disconnecting the cable from the equalizer. The mounting bracket locking tabs must be depressed to extract the cable before removing the bolt at the shock absorber bracket. Users should detach cables from both the lever and the backing plate through the locking tabs for cables of all types except 15 series utilities. To detach the cable from the lever and backing plate of 15 series utilities follow the same procedure. You should first validate the new cable placement through guides and body mounts before it enters the backing plate locking tabs for 15 series utilities and finally connecting it to the lever. Follow the previous procedure twice for all except 15 series utilities before linking the cable to its lever. Place the cable at the shock absorber bracket and fasten it through a 25 Nm (18 ft. lbs.) tight bolt installation. The mounting bracket allows cable attachment when locking tabs snap into position before the cable end reaches the equalizer where it requires tightening to 3.5 Nm (31 inch lbs.). Take away safety stands afterward lowering the vehicle and adjust the park brake cable.

You must start cable replacement of the right rear parking brake (without/RPO NYS) by first releasing the brake function and then lifting the vehicle properly. Before unosigning the cable from the equalizer you must first reduce cable tension through a nut installed at the equalizer. The installation of the new right rear parking brake cable starts by removing the bolt from the rear axle clip followed by removing the cable from both the differential clip and the mounting bracket through releasing its locking tabs. Start by removing the cable through the left and right side cable guides and from track bar clips as well as from 15 series utilities. The cable should detach from the lever except in 15 series utilities to continue the installation process. The procedure must be repeated during the cable removal process from the backing plate and lever on 15 series utilities. The installation of the new cable requires proper fitting through the guides and body mounts before pressing it into the backing plate until the locking tabs snap for 15 series utilities. Complete the process by linking the cable to the lever followed by correct guide and body mount routing checks for all Except 15 series utilities before cable-point attachment at the backing plate. Install the track bar cable securities using clips at the proper track bar locales for 15 series utilities. Follow this order to install the cable first to both lateral guides and afterward to the mounting bracket until the locking tabs securely snap into place. Screw the cable onto the differential clips and tighten the bolt to 25 Nm (18 ft. lbs.). Check the rear axle holding clip secured its position by hand crimping it if needed before moving ahead. The cable needs connecting first to differential clips before moving to the equalizer while the nut securing it at the equalizer needs to be tightened to 3.5 Nm (31 inch lbs.). The last step includes lowering the vehicle and removing safety stands before adjusting the park brake cable.

The first step to switch out the left rear park brake cable (without RPO NYS) requires the user to release the park brake while supporting the vehicle with elevators. You must lower the pressure on the park brake cable through front cable manipulation before removing it from the equalizer bar. The mounting bracket locking tabs need to be depressed to remove the cable before removing the bolt connecting it to the shock absorber bracket. After that remove the cable from the lever (25 series) by pressing its locking tabs and eliminate it from the backing plate. The procedure needs to be repeated for both the 15 series lever cable and backing plate cable before taking out the bindings again. To install the cable you should first guide it smoothly through its designated guides and body mount channels before inserting it at the backing plate (15 series) where it will lock into place when you press until the tabs click. Pair the cable with the lever after performing correct routing and apply the connection to both the lever and the backing plate (25 series). When attaching the cable to the shock absorber bracket secure it with a bolt that reaches 25 Nm (18 ft. lbs. torque). Trim the cable onto the mounting bracket by letting the locking tabs snap into place before you connect it to the equalizer bar and pull down the vehicle after safety stand removal and finish by adjusting the park brake cable.

Remove the nut from the threaded end of the intermediate cable and disconnect the equalizer from the rear park brake cables.

Remove the safety stands and lower the vehicle.
