OEM Cadillac Oil Cooler Hose
Oil Cooler Line- Select Vehicle by Model
- Select Vehicle by VIN
Select Vehicle by Model
orMake
Model
Year
Select Vehicle by VIN
For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).
177 Oil Cooler Hoses found
Product Specifications- Other Name: Pipe, Transmission Oil Cooler; Transmission Oil Cooler Line
- Replaces: 22887255, 22962315
Cadillac Connector Pipe
Part Number: 84318909$34.81 MSRP: $59.25You Save: $24.44 (42%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Pipe Assembly-Transmission Fluid Cooler; Transmission Oil Cooler Line; Oil Cooler Tube; Line; Pipe, Transmission Oil Cooler
- Replaces: 23159471
Cadillac Oil Cooler Pipe
Part Number: 23100571$7.67 MSRP: $12.62You Save: $4.95 (40%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Pipe Assembly-Transmission Fluid Cooler Inlet; Line; Pipe, Transmission Oil Cooler
Cadillac Line
Part Number: 23151062$94.88 MSRP: $156.28You Save: $61.40 (40%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Pipe, Transmission Oil Cooler; Transmission Oil Cooler Line
Cadillac Rear Pipe
Part Number: 84624735$156.50 MSRP: $246.19You Save: $89.69 (37%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Pipe, Transmission Oil Cooler; Line
- Replaced by: 84873596
Cadillac Inlet Hose
Part Number: 12698551$61.76 MSRP: $98.03You Save: $36.27 (37%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Pipe, Engine Oil Cooler; Oil Cooler Hose
- Replaces: 12695805
Cadillac Line
Part Number: 23104594$79.60 MSRP: $136.66You Save: $57.06 (42%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Pipe, Transmission Oil Cooler; Transmission Oil Cooler Line
Cadillac Hose & Tube Assembly
Part Number: 20977540$73.42 MSRP: $120.94You Save: $47.52 (40%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Hose Assembly-Transmission Fluid Cooler; Hose, Transmission Oil Cooler
- Replaces: 25829902
Cadillac Inlet Hose
Part Number: 12703149$29.25 MSRP: $45.81You Save: $16.56 (37%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Hose Assembly-Engine Oil Cooler Coolant Inlet; Oil Cooler Hose; Hose, Engine Oil Cooler
- Product Specifications
- Other Name: Pipe, Transmission Oil Cooler; Transmission Oil Cooler Line
Cadillac Outlet Hose
Part Number: 55487348$45.82 MSRP: $81.82You Save: $36.00 (44%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Hose Assembly-Thermostat Bypass; By-Pass Hose; Hose, Engine Coolant By - Pass; Hose, Engine Oil Cooler
Cadillac Hose & Tube Assembly
Part Number: 84887318$222.36 MSRP: $349.80You Save: $127.44 (37%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Pipe, Transmission Oil Cooler
Cadillac Hose & Tube Assembly
Part Number: 84202021$212.18 MSRP: $349.45You Save: $137.27 (40%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Pipe, Transmission Oil Cooler
Cadillac Upper Hose
Part Number: 55508979$26.58 MSRP: $41.63You Save: $15.05 (37%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Hose-Engine Oil Cooler Coolant Inlet; Cooling Hose; Hose, Engine Oil Cooler
Cadillac Inlet Hose
Part Number: 84211765$53.79 MSRP: $85.40You Save: $31.61 (38%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Pipe, Transmission Oil Cooler; Transmission Oil Cooler Hose; Transmission Oil Cooler Line; Outlet Hose; Hose & Tube Assembly; Oil Outlet Tube; Line
- Replaced by: 86584620
Cadillac Outlet Hose
Part Number: 12697176$26.88 MSRP: $42.10You Save: $15.22 (37%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Hose Assembly-Engine Oil Cooler Coolant Outlet; Oil Cooler Hose; Hose, Engine Oil Cooler
Cadillac Hose & Tube Assembly
Part Number: 84013047$213.00 MSRP: $350.84You Save: $137.84 (40%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Pipe, Transmission Oil Cooler
Cadillac Outlet Pipe
Part Number: 84065782$17.27 MSRP: $27.05You Save: $9.78 (37%)Ships in 1-3 Business DaysProduct Specifications- Other Name: Hose-Engine Oil Cooler Coolant Outlet; Oil Cooler Tube; Hose, Engine Oil Cooler
- Product Specifications
- Other Name: Hose Assembly-Transmission Fluid Cooler; Hose, Transmission Oil Cooler
- Replaces: 25840028
Product Specifications- Other Name: Hose Assembly-Transmission Fluid Cooler; Hose, Transmission Oil Cooler
- Replaces: 25840026
| Page 1 of 9 |Next >
1-20 of 177 Results
Cadillac Oil Cooler Hose Parts Questions & Experts Answers
- Q: How to replace the Engine Oil Cooler Hose/Pipe on Cadillac XLR?A: Replacement of the engine Oil Cooler Hose/pipe starts with raising and supporting the vehicle. Start by removing the wheelhouse panel and place an oil drain pan under the vehicle. Detach the engine Oil Cooler Hose/pipe from the external oil cooler before disconnecting the hose/pipe clip between the Fan Shroud and engine. Finally remove the external engine Oil Cooler Hose/pipe from its position between engine and vehicle. Every engine Oil Cooler Hose and pipe seal should be discarded. First install new engine Oil Cooler Hose/pipe seals before attaching the external engine Oil Cooler Hose/pipe to the vehicle ensuring that both components achieve proper fitment by pushing the quick connect fitting and verifying its engagement. Start by fitting the hose/pipe to the engine then attach the clips to the engine while maintaining engagement of the quick connect fitting. Complete installation by placing the engine Oil Cooler Hose/pipe next to the external cooler then remove the oil drain pan to reinstall the wheelhouse panel and check for oil leaks during the refill process.
- Q: How to replace the Engine Oil Cooler Hose/Pipe on Cadillac STS?A: Vehicle service begins with vehicle elevation for support followed by front air deflector replacement removal and positioning a catch pan beneath the vehicle. First separate the external oil cooler from the engine Oil Cooler Hose/pipe before disconnecting its clip from both the engine and Fan Shroud and finally removing the hose/pipe from all components. Discard the seals at this time. To install, begin by adding new seals onto the engine Oil Cooler Hose/pipe before you attach the external hose/pipe to the vehicle and check the quick connect fitting to verify proper attachment. After attaching the external hose/pipe to the engine you must install the clips onto the engine and Fan Shroud before checking the quick connect fitting operation. After fitting the engine Oil Cooler Hose/pipes to the external oil cooler you should remove the oil drain pan then reinstall the front air deflector replacement before refilling the engine oil while inspecting for any leaks.
- Q: How to Change the Oil Cooler Hose on a Cadillac CTS?A: Start by draining coolant before commencing replacement of the engine Oil Cooler Hose/pipe. Next raise the vehicle before providing support. The front compartment lower noise shield requires complete removal. J 38185 hose clamp pliers can be used to move the engine Oil Cooler Hose clamp off the Radiator Hose before extracting the engine Oil Cooler Hose from this connection. Start by moving the hose clamp at the engine position then extract the hose from the engine's location. Before extracting the engine oil cooler hoses from the vehicle remove the engine oil cooler bolt from the engine and disconnect engine oil cooler hoses from the engine. Begin installation by attaching engine oil cooler hoses to the vehicle then connecting the engine oil cooler hoses to the engine. Use j 38185 - hose clamp pliers to clamp the engine Oil Cooler Hose at the engine and install the engine oil cooler bolt into the engine. Use j 38185 - hose clamp pliers to reposition the engine Oil Cooler Hose clamp at the Radiator Hose. Install the engine Oil Cooler Hose to the engine for the second time before using j 38185 - hose clamp pliers to position the clamp again. Toward the end of the procedure you need to reinstall the front compartment lower noise shield and lower the vehicle before completing the coolant filling.
