GM 25758220
TPMS Sensor

2004-2009 GM

Customer Questions & Expert Answers (11)
GM 25758220 TPMS Sensor
GM 25758220 TPMS Sensor
GM 25758220 TPMS Sensor
  • Part Description
    Sensor Assembly-Tire Pressure Indicator; Tire Pressure Monitoring System (TPMS) Sensor
  • Replaces
    10306573, 10354988
  • Manufacturer
    General Motors
Make sure this part fits
$137.32 MSRP: $266.52
You Save: $129.20 (49%)
Ships in 1-2 Business Days
1
ADD TO CART

  • 25758220 TPMS Sensor is Ref No. 2 in the diagram below

    2008 Cadillac XLR TPMS Sensor Diagram for 25758220
    The diagram listed above is for your reference. View diagram for your vehicle

    Related Parts for 25758220

  • Vehicle Fitment

    Year Make Model Trim Engine
    2005-2008 Cadillac STSBase, Platinum, V6 Cyl 3.6 L GAS, 8 Cyl 4.4 L GAS, 8 Cyl 4.6 L GAS
    2004-2009 Cadillac XLRBase, Platinum, V8 Cyl 4.4 L GAS, 8 Cyl 4.6 L GAS
    2005-2009 Chevrolet Corvette427 Limited Edition Z06, Base, Z06, ZR18 Cyl 6.0 L GAS, 8 Cyl 6.2 L GAS, 8 Cyl 7.0 L GAS
    Warning: California's Proposition 65

  • Customer Questions & Expert Answers

    Q:
    Can you help me check if this 25758220 is the right part for my car? Posted by ChevyPartsGiant Specialist
    A:
    Please Select Your Vehicle model to see if part number 25758220 is suitable before ordering.
    Posted by ChevyPartsGiant Specialist
    Q:
    How to replace the TPMS Sensor on Cadillac XLR? Posted by Customer
    A:
    When replacing the Tire Pressure Indicator Sensor start by lifting your vehicle onto proper support equipment. Move the tire/wheel assembly away from the vehicle. Then place the valve cap and nickel-plated valve onto a clean dry surface where you will set them before tire extraction. Make sure the aluminum cap is present. The tire machine fixture should be placed at a 90-degree angle from the valve stem and the removal process demands a precise tolerance among the tire machine fixture or irons, tire bead, and sensor. Remove all tire sealant residue that remains inside the tire and wheel surfaces. Start by taking off the tire pressure sensor nut followed by the tire pressure sensor itself. To install the sensor first clean all debris from around the wheel's sensor grommet sealing section then place the sensor in the valve stem opening with the airflow channel facing opposite the wheel surface and last tight the sensor nut to 7 N.m (62 lb in) while positioning the sensor body straight against the wheel wall. Leave a gap between the tire machine and tire bead along with sensor that will fit when you reunite the tire with the wheel. Start by installing the tire onto the wheel before placing the tire/wheel combination on the vehicle and lowering the vehicle to the ground. The last step involves mastering tire pressure sensor operation.
    Posted by ChevyPartsGiant Specialist
    Q:
    What is the first step to replace the Tire Pressure Sensor for the 2007 Cadillac STS? Posted by Customer
    A:
    Raise the vehicle on a suitable support and remove the tire/wheel assembly.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar TPMS Sensor
    Q:
    What should be done if tire sealant is present for the 2006 Cadillac STS? Posted by Customer
    A:
    Remove all residual liquid sealant from the tire and wheel surfaces.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar TPMS Sensor
    Q:
    What is the first step to replace the Tire Pressure Sensor for the 2004 Cadillac XLR? Posted by Customer
    A:
    Raise the vehicle on a suitable support and remove the tire/wheel assembly.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar TPMS Sensor
    Q:
    What should be done after removing the tire from the wheel for the 2008 Cadillac STS? Posted by Customer
    A:
    Ensure to eliminate any residual tire sealant from the inside surfaces.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar TPMS Sensor
    Q:
    What should be done to the sensor grommet sealing area before installation for the 2009 Cadillac XLR? Posted by Customer
    A:
    Clean any dirt or debris from the sensor grommet sealing area of the wheel.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar TPMS Sensor
    Q:
    What is the final step after installing the tire/wheel assembly for the 2005 Cadillac STS? Posted by Customer
    A:
    Lower the vehicle and learn the tire pressure sensors.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar TPMS Sensor
    Q:
    What should be done before dismounting the tire for the 2007 Cadillac XLR? Posted by Customer
    A:
    Place the aluminum cap and nickel-plated valve on a dry, clean surface to prevent corrosion.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar TPMS Sensor
    Q:
    What is the first step to replace the Tire Pressure Indicator Sensor for the 2008 Chevrolet Corvette? Posted by Customer
    A:
    First, raise the vehicle on a suitable support.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar TPMS Sensor
    Q:
    What should be maintained during the removal of the tire for the 2007 Chevrolet Corvette? Posted by Customer
    A:
    A tolerance between the tire machine fixture or irons, tire bead, and the sensor.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar TPMS Sensor
    If you have any questions about this product, please don't hesitate to ask us. We will be happy to help you!

OEM GM TPMS Sensor 25758220 Designed for Proper Fit and Performance

Original OEM GM parts deliver superior quality and meet all performance standards needed for optimal automotive operation. The authentic part identified by 25758220 TPMS Sensor is available in the market under the name GM TPMS Sensor. This genuine product has a full warranty coverage from the manufacturer available at all authorized GM dealers throughout the United States. This part 25758220 TPMS Sensor fits certain Chevrolet Corvette models, as well as Cadillac XLR, STS models.
The original GM component designated by manufacturer part number 25758220 maintains top performance when functioning as the Sensor Assembly-Tire Pressure Indicator; Tire Pressure Monitoring System (TPMS) Sensor unit. The component 25758220 is constructed from durable material and its dimensions span 3.8 x 3.1 x 1.5 inches while weighing 0.40 Pounds. The Direct Replacement component is ready in New condition to ensure full compatibility with your vehicle system. This component receives the designation of Tire Pressure Sensor; Pressure Sensor; Sensor, Tire Pressure. The part 25758220 has available replacement options 10306573, 10354988. GM manufacturer provides a warranty that ensures reliable operation of this product. The Shipping Policy and Return Policy pages outline complete details regarding shipping procedures and return processes.
