Make sure this part fits

GM 10456194
Vehicle Speed Sensor

1996-2002 GM

Customer Questions & Expert Answers (25)
GM 10456194 Vehicle Speed Sensor
  • Part Description
    Sensor-Sp; Speed Sensor
  • Replaced By
    24225896
  • Manufacturer
    General Motors
Make sure this part fits
$30.84 MSRP: $50.80
You Save: $19.96 (40%)
Ships in 1-2 Business Days
1
ADD TO CART
  • Vehicle Fitment

    Year Make Model Trim Engine
    2002 Cadillac EscaladeBase8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
    2002 Cadillac Escalade EXTBase8 Cyl 6.0 L GAS
    2002 Chevrolet Avalanche 1500Base, North Face, On Road Edition, Z718 Cyl 5.3 L GAS
    2002 Chevrolet Avalanche 2500Base8 Cyl 8.1 L GAS
    1996-2001 Chevrolet BlazerBase, LS, LT, Trailblazer, Xtreme6 Cyl 4.3 L GAS
    1997-1999 Chevrolet C1500Base, Cheyenne, LS, Silverado, WT6 Cyl 4.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.5 L DIESEL
    1997-1999 Chevrolet C1500 SuburbanBase, LS, LT8 Cyl 5.7 L GAS, 8 Cyl 6.5 L DIESEL
    1997-2000 Chevrolet C2500Base, Cheyenne, LS, Silverado, WT8 Cyl 5.0 L GAS, 8 Cyl 5.7 L CNG, 8 Cyl 5.7 L GAS, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
    1997-1999 Chevrolet C2500 SuburbanBase, LS, LT8 Cyl 5.7 L GAS, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
    1997-2000 Chevrolet C3500Base, Cheyenne, LS, Silverado8 Cyl 5.7 L CNG, 8 Cyl 5.7 L GAS, 8 Cyl 6.5 L DIESEL, 8 Cyl 7.4 L GAS
    View More
    Warning: California's Proposition 65
  • Customer Questions & Expert Answers

    Q:
    Is this 10456194 designed for my car? Posted by ChevyPartsGiant Specialist
    A:
    Please Select Your Vehicle model to see if part number 10456194 is suitable before ordering.
    Posted by ChevyPartsGiant Specialist
    Q:
    How to service and repair the Vehicle Speed Sensor on a 4L60-E Transmission on GMC C3500? Posted by Customer
    A:
    You should first take out the bolt and then disconnect the harness before you service the Vehicle Speed Sensor on a 4L60-E Transmission. Removing the speed sensor requires the J38417 and make certain to have a suitable container because the tool might release fluid. After that, take out the O-ring seal. With the J38417 tool, replace the speed sensor and O-ring seal on your truck and apply a thin covering of transmission fluid to the O-ring. Put in the bolt and turn it until it reaches 11 Nm (97 inch lbs.), link up the harness and put more fluid whenever required.
    Posted by ChevyPartsGiant Specialist
    Q:
    How should the O-ring seal be prepared for installation for the 2002 Cadillac Escalade? Posted by Customer
    A:
    Place the O-ring seal onto the vehicle speed sensor and coat it with a thin film of transmission fluid.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What is the next step after removing the electrical connector for the 2002 Cadillac Escalade? Posted by Customer
    A:
    Remove the speed sensor itself.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What should be ensured during installation for the 2002 Chevrolet Avalanche 2500? Posted by Customer
    A:
    Follow the fastener notice in service precautions.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What is the next step after disconnecting the electrical connector for the 2000 Chevrolet Camaro? Posted by Customer
    A:
    Remove the speed sensor bolt and the vehicle speed sensor.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What should be followed during the installation for the 2002 Chevrolet Camaro? Posted by Customer
    A:
    The Fastener Notice in Service Precautions.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What is the first step to service and repair the Vehicle Speed Sensor for the Automatic Transmission 4L60-E for the 2000 Chevrolet Camaro? Posted by Customer
    A:
    First, raise and suitably support the vehicle.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What should be done after raising the 2002 Chevrolet Express 2500? Posted by Customer
    A:
    Disconnect the electrical connector from the speed sensor, then remove the bolt securing it.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What is the first step to replace the Vehicle Speed Sensor (VSS) in the 4L80-E automatic transmission for the 2001 Chevrolet Express 3500? Posted by Customer
    A:
    First, disconnect the speed sensor connectors and remove the vehicle speed sensor bolts.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What should be done after removing the bolts for the 2001 Chevrolet Suburban 1500? Posted by Customer
    A:
    Take out the vehicle speed sensors along with the bracket assemblies from the case and inspect the vehicle speed sensor assemblies for any signs of damage.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What should be inspected after removing the output speed sensor for the 2002 Chevrolet Suburban 2500? Posted by Customer
    A:
    Inspect the output speed sensor assembly for any signs of damage.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What is the next step after inserting the new speed sensor for the 2001 Chevrolet Suburban 1500? Posted by Customer
    A:
    Install the speed sensor bolt and tighten it to 12 Nm (108 inch lbs.).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What should be done after raising the 2002 Chevrolet Tahoe? Posted by Customer
    A:
    Disconnect the transfer case right rear electrical connector and remove the transfer case right rear speed sensor.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What should be done after installing the input speed sensor for the 2002 Chevrolet Tahoe? Posted by Customer
    A:
    Install the bolt and tighten it to 11 Nm (96 inch lbs.).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What should be done after raising for the 2001 GMC Savana 2500? Posted by Customer
    A:
    Disconnect the electrical connector from the speed sensor, then remove the bolt securing it.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    How should the new O-ring seal be prepared for installation for the 2000 GMC Jimmy? Posted by Customer
    A:
    Coat the new O-ring seal with a thin film of transmission fluid.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What is the torque specification for tightening the bolt for the 2000 GMC Jimmy? Posted by Customer
    A:
    Tighten the bolt to 22 Nm (16 ft. lbs.).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What is the procedure for installing the output speed sensor for the 2002 GMC Savana 3500? Posted by Customer
    A:
    Install the output speed sensor and the bracket assembly, then install the bolt and tighten it to 11 Nm (96 inch lbs.).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    How should the input speed sensor seal be prepared for installation for the 2002 GMC Savana 3500? Posted by Customer
    A:
    Lubricate the input speed sensor seal with automatic transmission fluid.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What is the first step to service and repair the Vehicle Speed Sensor for the 2000 GMC Savana 3500? Posted by Customer
    A:
    First, disconnect the speed sensor connectors and remove the vehicle speed sensor bolts.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What is the next step after preparing the O-ring seal for the 2001 GMC Yukon XL 1500? Posted by Customer
    A:
    Insert the sensor back into the transmission case.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What is the first step to service the Vehicle Speed Sensor (VSS) on the NV 3500 with a manual transmission for the 2001 GMC Yukon XL 1500? Posted by Customer
    A:
    First, raise the vehicle and disconnect the electrical connector from the VSS.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What is the first step to replace the transfer case speed sensor for the 2002 Chevrolet Suburban 2500? Posted by Customer
    A:
    The first step is to raise the vehicle.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    Q:
    What is the first step to replace the transfer case speed sensor on the NVG 233-NP1 for the 2001 GMC Jimmy? Posted by Customer
    A:
    First, raise the vehicle and remove the transfer case shield.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Vehicle Speed Sensor
    If you have any questions about this product, please don't hesitate to ask us. We will be happy to help you!

OEM GM Vehicle Speed Sensor 10456194 Designed for Proper Fit and Performance

Original OEM GM parts deliver superior quality and meet all performance standards needed for optimal automotive operation. The authentic part identified by 10456194 Vehicle Speed Sensor is available in the market under the name GM Vehicle Speed Sensor. This genuine product has a full warranty coverage from the manufacturer available at all authorized GM dealers throughout the United States. This part 10456194 Vehicle Speed Sensor fits certain Chevrolet S10, Tahoe, Camaro models, as well as GMC Sierra 1500, Yukon, Sierra 2500 HD. Additionally, it is compatible with Cadillac Escalade, Escalade EXT and Pontiac Firebird models.
The original GM component designated by manufacturer part number 10456194 maintains top performance when functioning as the Sensor-Sp; Speed Sensor unit. The component 10456194 is constructed from durable material and its dimensions span 4.5 x 2.9 x 3.0 inches while weighing 0.60 Pounds. The component is ready in New condition to ensure full compatibility with your vehicle system. The part 10456194 has available replacement options listed under 24225896. GM manufacturer provides a warranty that ensures reliable operation of this product. The Shipping Policy and Return Policy pages outline complete details regarding shipping procedures and return processes.
If you want to save money in the long run on maintenance and repairs, you should choose OEM products because they're of the top level of durability. Are you on the quest of finding GM parts, our site is worth a visit. We stock an endless selection of high-quality GM components including things like ignition coils all the way through to fan shrouds and all at prices that can not be matched. You have nothing to worry about because all our OEM parts are covered with a manufacturer warranty, which guarantees superior quality and value.
