How to replace the shock absorber (W/F55) on 2008 Cadillac XLR?

The first step for Shock Absorber (W/F55) replacement involves vehicle elevation followed by support. The procedure begins by removing the tire and wheel assembly together with the elimination of the rear shock electronic suspension control (ESC) harness connector and its pigtail from the upper shock tower clip. The process begins by taking off the lower Shock Absorber to lower control arm retaining bolt and continuing with removal of upper Shock Absorber mounting bolts. Safely extract the Shock Absorber from the vehicle while following correct routing patterns of esc connector and pigtail through the upper shock tower. First separate the insulator retainer along with insulator from the Shock Absorber. Install the Shock Absorber by connecting its upper insulator retainer to its insulator while orienting the esc connector to face inwards and the white bottom bracket paint mark to face outwards at 180 degrees from the bracket to esc connector axis. The Shock Absorber installation requires placing it on both the shock tower and lower control arm while securing the upper Shock Absorber bolts to 30 n.m (22 lb ft) torque value but leave the lower control arm nut untorqued. Attach the lower Shock Absorber mounting bolt then tighten the lower Shock Absorber retaining nut to 145 n.m (107 lb ft). Return the suspension knuckle to the outer tie rod then fasten the upper shock tower clip to the harness pigtail and the rear shock esc harness connecter. After completing the tire-wheeled installation process, lower the vehicle.

OEM 2008 Cadillac XLR Shock Absorber

Suspension Shock Absorber

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

7 Shock Absorbers found

View related parts
2008 Cadillac XLR Shock Absorber Part Number: 19302775
$561.63 MSRP: $1099.62
You Save: $537.99 (49%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Strut Kit, Shock; Shock
- Position: Front
- Replaces: 19178739, 19259307
- Item Weight: 5.80 Pounds
- Item Dimensions: 22.2 x 3.5 x 3.3 inches
- Condition: New
- Fitment Type: Direct Replacement
- Require Quantity: 2
- SKU: 19302775
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2008 Cadillac XLR Submodels:
- Base, Platinum, V | 8 Cyl 4.4 L GAS, 8 Cyl 4.6 L GAS
View related parts
2008 Cadillac XLR Shock Absorber Part Number: 19302774
$561.63 MSRP: $1099.62
You Save: $537.99 (49%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Strut Kit, Shock; Shock
- Position: Front
- Replaces: 19259306, 19207674
- Item Weight: 5.20 Pounds
- Item Dimensions: 3.0 x 3.2 x 22.2 inches
- Condition: New
- Fitment Type: Direct Replacement
- Require Quantity: 2
- SKU: 19302774
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2008 Cadillac XLR Submodels:
- Platinum, V | 8 Cyl 4.4 L GAS, 8 Cyl 4.6 L GAS
View related parts
2008 Cadillac XLR Shock Absorber, Passenger Side Part Number: 19431687
$578.09 MSRP: $1121.96
You Save: $543.87 (49%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Absorber, Shock; Shock; Absorber, Front And Rear Suspension
- Position: Passenger Side
- Replaces: 22784741, 19177205, 19302779
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 19431687
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2008 Cadillac XLR Submodels:
- Base, Platinum, V | 8 Cyl 4.4 L GAS, 8 Cyl 4.6 L GAS
View related parts
2008 Cadillac XLR Shock Absorber Part Number: 19302772
$533.06 MSRP: $1043.68
You Save: $510.62 (49%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Absorber Kit, Front And Rear Suspension; Shock
- Position: Front
- Replaces: 19181113
- Item Weight: 10.20 Pounds
- Item Dimensions: 3.1 x 3.2 x 22.7 inches
- Condition: New
- Fitment Type: Direct Replacement
- Require Quantity: 2
- SKU: 19302772
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2008 Cadillac XLR Submodels:
- Base, Platinum, V | 8 Cyl 4.4 L GAS, 8 Cyl 4.6 L GAS
View related parts
2008 Cadillac XLR Shock Absorber, Rear Driver Side Part Number: 19431688
$508.65 MSRP: $995.88
You Save: $487.23 (49%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Absorber Assembly, Rear Shock; Shock; Absorber, Front And Rear Suspension; Absorber, Shock
- Position: Rear Driver Side
- Replaces: 19302781, 22784743, 19177206
- Item Weight: 6.60 Pounds
- Item Dimensions: 24.2 x 7.3 x 4.2 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 19431688
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2008 Cadillac XLR Submodels:
- Base, Platinum | 8 Cyl 4.6 L GAS
View related parts
2008 Cadillac XLR Shock Absorber, Rear Passenger Side Part Number: 19302770
Product Specifications
- Other Name: Absorber Kit, Rear Shock; Shock; Absorber Kit, Front And Rear Suspension
- Position: Rear Passenger Side
- Replaces: 19177203
- Item Weight: 7.60 Pounds
- Item Dimensions: 7.4 x 4.2 x 24.5 inches
- Condition: New
- Fitment Type: Direct Replacement
- SKU: 19302770
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2008 Cadillac XLR Submodels:
- Base, Platinum, V | 8 Cyl 4.4 L GAS, 8 Cyl 4.6 L GAS
View related parts
2008 Cadillac XLR Shock Absorber, Rear Driver Side Part Number: 19177204
Product Specifications
- Other Name: Absorber Kit, Rear Shock; Shock
- Position: Rear Driver Side
- Replaced by: 19302771
- Item Weight: 7.60 Pounds
- Item Dimensions: 7.4 x 4.2 x 24.7 inches
- Condition: New
- SKU: 19177204
- Warranty: This genuine part is guaranteed by GM's factory warranty.
More Info
Fits the following 2008 Cadillac XLR Submodels:
- V | 8 Cyl 4.4 L GAS

2008 Cadillac XLR Shock Absorber

With a comprehensive array of OEM 2008 Cadillac XLR Shock Absorber, from fuel pumps to door handles, our website is a one-stop-shop for your needs. All our genuine 2008 Cadillac XLR Shock Absorber are backed by the manufacturer's warranty and are offered at competitive prices in the market. Rest assured, you can shop with complete confidence.

2008 Cadillac XLR Shock Absorber Parts and Q&A

Q: How to replace the shock absorber (W/F55) on 2008 Cadillac XLR?
A: The first step for Shock Absorber (W/F55) replacement involves vehicle elevation followed by support. The procedure begins by removing the tire and wheel assembly together with the elimination of the rear shock electronic suspension control (ESC) harness connector and its pigtail from the upper shock tower clip. The process begins by taking off the lower Shock Absorber to lower control arm retaining bolt and continuing with removal of upper Shock Absorber mounting bolts. Safely extract the Shock Absorber from the vehicle while following correct routing patterns of esc connector and pigtail through the upper shock tower. First separate the insulator retainer along with insulator from the Shock Absorber. Install the Shock Absorber by connecting its upper insulator retainer to its insulator while orienting the esc connector to face inwards and the white bottom bracket paint mark to face outwards at 180 degrees from the bracket to esc connector axis. The Shock Absorber installation requires placing it on both the shock tower and lower control arm while securing the upper Shock Absorber bolts to 30 n.m (22 lb ft) torque value but leave the lower control arm nut untorqued. Attach the lower Shock Absorber mounting bolt then tighten the lower Shock Absorber retaining nut to 145 n.m (107 lb ft). Return the suspension knuckle to the outer tie rod then fasten the upper shock tower clip to the harness pigtail and the rear shock esc harness connecter. After completing the tire-wheeled installation process, lower the vehicle.
