How to replace the radiator on Cadillac STS?

Starting the Radiator replacement requires draining coolant while also removing electric cooling fan assemblies. Raise and support the vehicle before removing the lower mounting bolt using 5.4 n.m of torque and upper mounting bolt also at 5.4 n.m of torque. Reposition the condenser to gain access to Transmission Oil Cooler mounting bolts requiring a torque of 5 n.m. After disconnecting the lower retainer pins of the side air baffle from the Radiator, lower the vehicle then remove the Radiator support bracket bolts together with the support brackets. To separate the Radiator/condenser upper support you should use the door trim pad clip remover (J 38778) while using hose clamp pliers (J 38185) to disconnect the surge tank inlet hose from the Radiator before relocating the hose aside. Before Radiator removal the hose clamp pliers (J 38185) should be used to release tension on Radiator inlet and outlet hose clamps followed by hose disconnection from the Radiator. Also use the hose clamp pliers to remove upper retainer pins from the side air baffle before removing the Radiator. Place the new Radiator before securing the upper retainer pins from the side air baffle into position on the Radiator. Use hose clamp pliers (J 38185) to secure the outlet hose clamp and then proceed with connecting the inlet hose and surge tank inlet hose with an additional use of hose clamp pliers (J 38185). Fitting the Radiator/condenser upper support should be done with the support brackets installed and their bolts tightened to 9 n.m (80 lb in). Raise the vehicle for a second time while fitting the lower retainer pins of the side air baffle to the Radiator and tighten all Transmission Oil Cooler mounting bolts to 5 n.m. Continue with condenser mounting bolt installation starting with the upper bolts at 5.4 n.m then the lower bolts at 5.4 n.m. Completed procedures include lowering the vehicle before reinstallation of the electric cooling fan assembly and completing the cooling system fluid.

OEM Cadillac STS Radiator

Cooling Radiator

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

11 Radiators found

View related parts
Cadillac STS Intercooler Part Number: 25770419
Product Specifications
- Other Name: Radiator Assembly-Charging Air Cooler; Radiator, Turbocharger/Supercharger Cooling
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2006-2009 Cadillac STS | V | 8 Cyl 4.4 L GAS
View related parts
Cadillac STS Radiator Part Number: 19259459
Product Specifications
- Other Name: Radiator Assembly; Radiator, Radiator
- Replaces: 89022520, 19129971
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2005-2007 Cadillac STS | Base | 8 Cyl 4.6 L GAS
View related parts
Cadillac STS Radiator Part Number: 19259457
Product Specifications
- Other Name: Radiator Assembly; Radiator, Radiator
- Replaces: 19130224
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2007 Cadillac STS | Base | 6 Cyl 3.6 L GAS
View related parts
Cadillac STS Radiator Part Number: 19258626
Product Specifications
- Other Name: Radiator Assembly; Radiator, Radiator
- Replaces: 19129969
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2006-2009 Cadillac STS | V | 8 Cyl 4.4 L GAS
View related parts
Cadillac STS Radiator Part Number: 19130364
Product Specifications
- Other Name: Radiator Assembly; Radiator, Radiator
- Replaces: 19129973, 19130176, 89022519
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2005-2010 Cadillac STS | Base, Platinum | 6 Cyl 3.6 L GAS, 8 Cyl 4.6 L GAS
View related parts
Cadillac STS Radiator Part Number: 19259458
Product Specifications
- Other Name: Radiator Assembly; Radiator, Radiator
- Replaces: 19130225
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2007 Cadillac STS | Base | 6 Cyl 3.6 L GAS
View related parts
Cadillac STS Radiator Part Number: 19130399
Product Specifications
- Other Name: Radiator Assembly; Radiator, Radiator
- Replaces: 19129972, 88957419, 19130177
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2005-2007 Cadillac STS | Base | 6 Cyl 3.6 L GAS, 8 Cyl 4.6 L GAS
View related parts
Cadillac STS Radiator Part Number: 19130363
Product Specifications
- Other Name: Radiator Assembly; Radiator, Radiator
- Replaces: 19130175
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2007-2010 Cadillac STS | Base, Platinum | 6 Cyl 3.6 L GAS, 8 Cyl 4.6 L GAS
View related parts
Cadillac STS Radiator Part Number: 19130362
Product Specifications
- Other Name: Radiator Assembly; Radiator, Radiator
- Replaces: 19130226
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2008-2010 Cadillac STS | Base, Platinum | 6 Cyl 3.6 L GAS, 8 Cyl 4.6 L GAS
View related parts
Cadillac STS Radiator Part Number: 19130357
Product Specifications
- Other Name: Radiator Assembly; Radiator, Radiator
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2008-2011 Cadillac STS | Base, Platinum | 6 Cyl 3.6 L GAS
View related parts
Cadillac STS Radiator Part Number: 19130356
Product Specifications
- Other Name: Radiator Assembly; Radiator, Radiator
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2008-2011 Cadillac STS | Base, Platinum | 6 Cyl 3.6 L GAS

Cadillac STS Radiator

Want to cut long-term maintenance and repair costs? Choose OEM Radiator. Those parts deliver top durability you can trust. On our site, you'll find a huge catalog of genuine Cadillac STS parts. Prices are unbeatable, so you can keep more in your pocket. Every OEM Cadillac STS Radiator includes a manufacturer's warranty. You can also get an easy return policy that keeps buying risk free. Fast delivery, get your car on the road quickly. It's simple to search, compare, and order. Stop guessing about quality or fit. Order today and save with parts that last.

The Radiator is a fundamental component of the STS car cooling system, being highly appreciated by users in STS models. Being an important part of an automobile, the Radiator takes the heat from the engine coolant and passes it out to the environment to help maintain the right internal combustion chamber temperature. Usually made of lightweight aluminum material, the Radiators contains a core of the fin and tubes, and this is usually located at the front part of the automobile to foster unrestricted air flow. This design effectively improves the cooling capabilities and also brings in a sense of safety to the Cadillac STS since the engine is tackled of overheating. There has been standard and performance radiators installed on Cadillac STS cars; the performance ones have larger sizes of tubes and higher fin density for better heat transferring. This way, the drivers can make a choice of Radiators they want depending on the type of vehicles they are going to use, be it for regular use or racing. Radiator can be used across the line thus every STS owner will be able to enjoy using this product. Also, they integrated some safety features that include lane departure and blind spots on Cadillac STS; a good radiator is crucial in enhancing the integrity of the vehicle. In conclusion, the Radiator is one of the best engineered car in the automotive market and plays a very important role in the efficiency and performance of the Cadillac STS not forgetting their safety.

Cadillac STS Radiator Parts Questions & Experts Answers

Intercooler
25770419
Q: How to replace the radiator on Cadillac STS?
A:
Starting the Radiator replacement requires draining coolant while also removing electric cooling fan assemblies. Raise and support the vehicle before removing the lower mounting bolt using 5.4 n.m of torque and upper mounting bolt also at 5.4 n.m of torque. Reposition the condenser to gain access to Transmission Oil Cooler mounting bolts requiring a torque of 5 n.m. After disconnecting the lower retainer pins of the side air baffle from the Radiator, lower the vehicle then remove the Radiator support bracket bolts together with the support brackets. To separate the Radiator/condenser upper support you should use the door trim pad clip remover (J 38778) while using hose clamp pliers (J 38185) to disconnect the surge tank inlet hose from the Radiator before relocating the hose aside. Before Radiator removal the hose clamp pliers (J 38185) should be used to release tension on Radiator inlet and outlet hose clamps followed by hose disconnection from the Radiator. Also use the hose clamp pliers to remove upper retainer pins from the side air baffle before removing the Radiator. Place the new Radiator before securing the upper retainer pins from the side air baffle into position on the Radiator. Use hose clamp pliers (J 38185) to secure the outlet hose clamp and then proceed with connecting the inlet hose and surge tank inlet hose with an additional use of hose clamp pliers (J 38185). Fitting the Radiator/condenser upper support should be done with the support brackets installed and their bolts tightened to 9 n.m (80 lb in). Raise the vehicle for a second time while fitting the lower retainer pins of the side air baffle to the Radiator and tighten all Transmission Oil Cooler mounting bolts to 5 n.m. Continue with condenser mounting bolt installation starting with the upper bolts at 5.4 n.m then the lower bolts at 5.4 n.m. Completed procedures include lowering the vehicle before reinstallation of the electric cooling fan assembly and completing the cooling system fluid.
