How to replace the upper control arm bushings on Chevrolet Camaro?

First obtain these essential tools before upper Control Arm Bushing replacement: Control Arm Bushing receiver (J 21474-5), upper Control Arm nut (J 21474-18) along with upper Control Arm screw (J 21474-19) and half moon spacer (J 39872) and upper Control Arm Bushing receiver/installer (J 39930). The replacement of upper Control Arm bushings requires these components: Control Arm Bushing receiver (J 21474-5), upper Control Arm nut (J 21474-18), upper Control Arm screw (J 21474-19), half moon spacer (J 39872) along with upper Control Arm Bushing receiver/installer (J 39930). Start by uninstalling the upper Control Arm along with all its mounting bolts and screws and nuts until the front upper Control Arm becomes separate from the upper Control Arm support. Thread j 21474-19 through j 39930 so the three tangs of j 39930 sit opposite the screw head before passing it through the upper Control Arm Bushing. Position the thrust washer on j 21474-19 by placing its seams against j 21474-5 then attach j 21474-5 to j 21474-19. Before assembly position j 39872 around the bushing to protect the metal structure and ensure j 39930 and j 21474-5 align properly then install j 21474-18 on j 21474-19. Complete removal of the bushing occurs when you tighten j 21474-19 and j 21474-18. To begin assembly keep the Control Arm in a vise before threading j 21474-19 through j 39930 with tangs facing away. Install a new bushing onto j 21474-19 before insertion into the upper Control Arm through its outer opening. To keep j 21474-5 safe install it inside then secure thrust washer on j 21474-19 so its seam points at the bushing and stabilize with j 39872 to reduce distortion. Complete the installation by putting j 21474-18 onto j 21474-19 then tighten until both components reach flat surface. Thread the front upper Control Arm back to its support then lock it into position using bolts and screws and nuts before tightening all fasteners to 98 nm (72 ft. Lbs.). Follow by reinstalling the upper Control Arm.

OEM Chevrolet Camaro Control Arm Bushing

Suspension Arm Bushing

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

9 Control Arm Bushings found

View related parts
Chevrolet Camaro Upper Control Arm Bushing
Part Number: 92214163
$27.85 MSRP: $40.23
You Save: $12.38 (31%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Bushing, Rear Axle Control Arm; Control Arm Bushing; Axle Beam Mount
- Position: Rear Upper
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2010-2015 Chevrolet Camaro | LS, LT, SS, Z/28, ZL1 | 6 Cyl 3.6 L GAS, 8 Cyl 6.2 L GAS, 8 Cyl 7.0 L GAS
View related parts
Chevrolet Camaro Trailing Arm Bushing
Part Number: 92202986
$6.51 MSRP: $10.19
You Save: $3.68 (37%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Bushing Assembly-Rear Suspension Control Arm
- Position: Rear
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2010 Chevrolet Camaro | LS, LT, SS | 6 Cyl 3.6 L GAS, 8 Cyl 6.2 L GAS
View related parts
Chevrolet Camaro Upper Control Arm Bushing
Part Number: 92214164
$23.24 MSRP: $36.89
You Save: $13.65 (37%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Bushing, Rear Axle Control Arm; Control Arm Bushing; Axle Beam Mount
- Position: Rear Upper
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2010-2015 Chevrolet Camaro | LS, LT, SS, Z/28, ZL1 | 6 Cyl 3.6 L GAS, 8 Cyl 6.2 L GAS, 8 Cyl 7.0 L GAS
View related parts
Chevrolet Camaro Crossmember Bushing, Lower
Part Number: 23208474
$75.46 MSRP: $124.31
You Save: $48.85 (40%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Bushing, Steering Knuckle Lower Control Arm; Axle Support Bushing; Axle Pivot Bushing; Suspension Crossmember Lower Bushing; Suspension Crossmember Bushing; Bushings
- Position: Lower
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2016-2024 Chevrolet Camaro | LS, LT, LT1, SS, ZL1 | 4 Cyl 2.0 L GAS, 6 Cyl 3.6 L GAS, 8 Cyl 6.2 L GAS
View related parts
Chevrolet Camaro Lower Control Arm Rear Bushing
Part Number: 22156434
Product Specifications
- Other Name: Bushing, Steering Knuckle Lower Control Arm; Suspension Control Arm Bushing; Control Arm Bushing; Axle Pivot Bushing; Bushings
- Position: Lower
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1993-2002 Chevrolet Camaro | Base, Indianapolis 500 Pace Car, RS, Z28, Z28 SS | 6 Cyl 3.4 L GAS, 6 Cyl 3.8 L GAS, 8 Cyl 5.7 L GAS
View related parts
Chevrolet Camaro Lower Control Arm Front Bushing
Part Number: 22145392
Product Specifications
- Other Name: Bushing, Steering Knuckle Lower Control Arm; Control Arm Bushing; Axle Pivot Bushing; Bushings
- Position: Lower
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1993-2002 Chevrolet Camaro | Base, Indianapolis 500 Pace Car, RS, Z28, Z28 SS | 6 Cyl 3.4 L GAS, 6 Cyl 3.8 L GAS, 8 Cyl 5.7 L GAS
View related parts
Chevrolet Camaro Lower Control Arm Front Bushing
Part Number: 17999115
Product Specifications
- Other Name: Bushing, Steering Knuckle Lower Control Arm; Control Arm Bushing; Axle Pivot Bushing; Bushings
- Position: Lower
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1993-1997 Chevrolet Camaro | Base, Indianapolis 500 Pace Car, RS, Z28 | 6 Cyl 3.4 L GAS, 6 Cyl 3.8 L GAS, 8 Cyl 5.7 L GAS
View related parts
Chevrolet Camaro Lower Control Arm Rear Bushing
Part Number: 17999113
Product Specifications
- Other Name: Bushing, Steering Knuckle Lower Control Arm; Control Arm Bushing; Axle Pivot Bushing; Bushings
- Position: Lower
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1993-1999 Chevrolet Camaro | Base, Indianapolis 500 Pace Car, RS, Z28, Z28 SS | 6 Cyl 3.4 L GAS, 6 Cyl 3.8 L GAS, 8 Cyl 5.7 L GAS
View related parts
Chevrolet Camaro Lower Control Arm Rear Bushing
Part Number: 17999112
Product Specifications
- Other Name: Bushing, Steering Knuckle Lower Control Arm; Control Arm Bushing; Axle Pivot Bushing; Bushings
- Position: Lower
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1993-1999 Chevrolet Camaro | Base, Indianapolis 500 Pace Car, RS, Z28, Z28 SS | 6 Cyl 3.4 L GAS, 6 Cyl 3.8 L GAS, 8 Cyl 5.7 L GAS

Chevrolet Camaro Control Arm Bushing

Our website offers an extensive catalog of genuine Chevrolet Camaro Control Arm Bushing at unbeatable prices. Every OEM Chevrolet Camaro Control Arm Bushing comes with a manufacturer's warranty, an easy return policy, and rapid delivery service. Don't miss out on this great opportunity!

Chevrolet Camaro Control Arm Bushing Parts Questions & Experts Answers

Lower Control Arm Rear Bushing
22156434
Q: How to replace the upper control arm bushings on Chevrolet Camaro?
A: First obtain these essential tools before upper Control Arm Bushing replacement: Control Arm Bushing receiver (J 21474-5), upper Control Arm nut (J 21474-18) along with upper Control Arm screw (J 21474-19) and half moon spacer (J 39872) and upper Control Arm Bushing receiver/installer (J 39930). The replacement of upper Control Arm bushings requires these components: Control Arm Bushing receiver (J 21474-5), upper Control Arm nut (J 21474-18), upper Control Arm screw (J 21474-19), half moon spacer (J 39872) along with upper Control Arm Bushing receiver/installer (J 39930). Start by uninstalling the upper Control Arm along with all its mounting bolts and screws and nuts until the front upper Control Arm becomes separate from the upper Control Arm support. Thread j 21474-19 through j 39930 so the three tangs of j 39930 sit opposite the screw head before passing it through the upper Control Arm Bushing. Position the thrust washer on j 21474-19 by placing its seams against j 21474-5 then attach j 21474-5 to j 21474-19. Before assembly position j 39872 around the bushing to protect the metal structure and ensure j 39930 and j 21474-5 align properly then install j 21474-18 on j 21474-19. Complete removal of the bushing occurs when you tighten j 21474-19 and j 21474-18. To begin assembly keep the Control Arm in a vise before threading j 21474-19 through j 39930 with tangs facing away. Install a new bushing onto j 21474-19 before insertion into the upper Control Arm through its outer opening. To keep j 21474-5 safe install it inside then secure thrust washer on j 21474-19 so its seam points at the bushing and stabilize with j 39872 to reduce distortion. Complete the installation by putting j 21474-18 onto j 21474-19 then tighten until both components reach flat surface. Thread the front upper Control Arm back to its support then lock it into position using bolts and screws and nuts before tightening all fasteners to 98 nm (72 ft. Lbs.). Follow by reinstalling the upper Control Arm.
