How to service and repair the catalytic converter on Chevrolet Prizm?

To service and repair the Catalytic Converter, first, lift and hold the vehicle. Remove the heated Oxygen Sensor 2 (H02S2). Then you will pull out the one bolt and clamp that hold the front pipe to the three-way Catalytic Converter (TWC) and then proceed to pull out the two bolts that hold the twc to the muffler/tail pipe assembly. Remove the hangers from the rear of the twc and from the vehicle to remove the twc from the vehicle. Before reinstalling the three-way Catalytic Converter (TWC) to the vehicle, clean the gasket and mating surfaces of the seals. Clamp the twc from the front and fasten the first bolt, and connect the rear of the twc using two hangers. Screw in the two bolts to fasten the twc to the muffler/tailpipe assembly (finger tighten initially). Make sure all system components are correctly aligned to avoid noise or vibrations before tightening the fasteners. Tighten the front pipe-to-twc clamp bolt, 50 nm (37 ft. Lbs.), twc to-muffler/tail pipe assembly bolts, 50 nm (37 ft. Lbs.). Lastly, replace the heated Oxygen Sensor 2 (H02S2) and drive the vehicle down.

OEM Chevrolet Prizm Catalytic Converter

Cat. Converter

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

5 Catalytic Converters found

View related parts
Chevrolet Prizm Catalytic Converter Part Number: 94860066
$290.42 MSRP: $545.28
You Save: $254.86 (47%)
ADD TO CART
Product Specifications
- Other Name: Converter, Catalytic Converter
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1998-1999 Chevrolet Prizm | Base, LSi | 4 Cyl 1.8 L GAS
View related parts
Chevrolet Prizm Catalytic Converter Part Number: 94860091
Product Specifications
- Other Name: Converter, Catalytic Converter
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2000-2002 Chevrolet Prizm | Base, LSi | 4 Cyl 1.8 L GAS
View related parts
Chevrolet Prizm Catalytic Converter Part Number: 94860090
Product Specifications
- Other Name: Converter, Catalytic (W/Exhaust Pipe); Converter, Catalytic Converter; Converter, Exhaust Pipe
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2000-2002 Chevrolet Prizm | Base, LSi | 4 Cyl 1.8 L GAS
View related parts
Chevrolet Prizm Catalytic Converter Part Number: 94856617
Product Specifications
- Other Name: Converter, Catalytic (W/Exhaust Pipe); Converter, Catalytic Converter; Converter, Exhaust Pipe
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1998-1999 Chevrolet Prizm | Base, LSi | 4 Cyl 1.8 L GAS
View related parts
Chevrolet Prizm Catalytic Converter Part Number: 89027355
Product Specifications
- Other Name: Converter, Catalytic Converter
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1998-1999 Chevrolet Prizm | Base, LSi | 4 Cyl 1.8 L GAS

Chevrolet Prizm Catalytic Converter

Want to cut long-term maintenance and repair costs? Choose OEM Catalytic Converter. Those parts deliver top durability you can trust. On our site, you'll find a huge catalog of genuine Chevrolet Prizm parts. Prices are unbeatable, so you can keep more in your pocket. Every OEM Chevrolet Prizm Catalytic Converter includes a manufacturer's warranty. You can also get an easy return policy that keeps buying risk free. Fast delivery, get your car on the road quickly. It's simple to search, compare, and order. Stop guessing about quality or fit. Order today and save with parts that last.

The Chevrolet Prizm Catalytic Converter is an autos part that reflects the quality and power of the Chevrolet Prizm series that was built from 1989 to the year 2002. This integral element of the exhaust and emissions system properly changes dangerous gases resulted from combustion into much less hazardous forms, which adds to effectiveness and security simultaneously. The Chevrolet Prizm models have incorporated different types of catalytic converters such as the two-waying and three-waving systems with the three-way system diminishing the NOx discharge. Chevrolet Prizm Catalytic Converter's honeycomb substrate design is highly complex and enhances the gas flow while enhancing exposure of the catalyst to the gas. Its versatility is defined by the compatibility with different sorts of Prizm, including those, which are fitted with 1.6 L and 1.8 L engines. The Chevrolet Prizm Catalytic Converter is not only pollution friendly as it conforms to the required emission standards but also mirrors on the fuel economy conformity boasting off city and highway milkage rates of 28/32 mpg. Additional characteristics, for instance platinum, palladium, or rhodium increase its catalytic capability making it a nose ahead in the automotive industry. In sum, the Chevrolet Prizm Catalytic Converter captures the Chevrolet brand as a manufacturer with adequate focus on this key aspect; catalytic converters help maintain the comprehensive dependability of Chevrolet Prizm while enhancing the vehicle's performance to meet the needs of any driver in today's global society.

Chevrolet Prizm Catalytic Converter Parts Questions & Experts Answers

Catalytic Converter
94860091
Q: How to service and repair the catalytic converter on Chevrolet Prizm?
A:
To service and repair the Catalytic Converter, first, lift and hold the vehicle. Remove the heated Oxygen Sensor 2 (H02S2). Then you will pull out the one bolt and clamp that hold the front pipe to the three-way Catalytic Converter (TWC) and then proceed to pull out the two bolts that hold the twc to the muffler/tail pipe assembly. Remove the hangers from the rear of the twc and from the vehicle to remove the twc from the vehicle. Before reinstalling the three-way Catalytic Converter (TWC) to the vehicle, clean the gasket and mating surfaces of the seals. Clamp the twc from the front and fasten the first bolt, and connect the rear of the twc using two hangers. Screw in the two bolts to fasten the twc to the muffler/tailpipe assembly (finger tighten initially). Make sure all system components are correctly aligned to avoid noise or vibrations before tightening the fasteners. Tighten the front pipe-to-twc clamp bolt, 50 nm (37 ft. Lbs.), twc to-muffler/tail pipe assembly bolts, 50 nm (37 ft. Lbs.). Lastly, replace the heated Oxygen Sensor 2 (H02S2) and drive the vehicle down.
