How to remove and install the ABS Control Module on Buick LeSabre?

The first steps to remove the ABS Control Module (ABSCM) start with flipping off the ignition and raising the vehicle. Start by removing the left front wheel followed by the left front wheelhouse extension before extracting the air pump when it is present. Release the abscm connector tab to the unlocked position then pull the abscm connector position assurance out from the abscm electrical connector. You should set the ignition switch to off before you connect or disconnect any wiring harness to stop equipment damage. Proceed to detach both the abscm electrical connector which sits on the abscm as well as the bpmv electrical connector which also connects to the abscm. You need to detach the 6 abscm to bpmv screws while cleaning the abscm/bpmv assembly surface for future repair reference. Incidentally the abscm cannot be serviced with faulty components it must receive replacement. The procedure requires abscm to be apart from bpmv. The installation process requires sealing the bpmv surface and implementing the abscm onto the bpmv while tightening each screw to 3.2 nm (28 inch lbs.). Connect both the bpmv electrical connector to the abscm while ensuring the ignition switch stays off and connect the abscm electrical connector to its mating abscm. The abscm connector position assurance assembly needs to be attached to the abscm electrical connector and the abscm connector tab requires rotation into a locked position. Put back the air pump if installed along with the left front wheelhouse extension while reinstalling the left front wheel before lowering the vehicle. An unprogrammed abscm might cause drp/abs/tcs/vses/tim/ves to malfunction if these systems are equipped while setting dtc c1248 and c1255m3. Any new abscm unit should receive programming for the latest software which matches the vehicle specifications. Use the scan tool to perform both dtc clearing then initiate the abs diagnostic system check.

OEM Buick LeSabre ABS Control Module

Anti Lock Brake Control Module

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

16 ABS Control Modules found

View related parts
Buick LeSabre Pressure Valve
Part Number: 25731523
Product Specifications
- Other Name: Valve, Electronic Brake Control; ABS Pump And Motor Assembly; ABS Control Module; Modulator Valve; ABS Pump Assembly; Pressure Modulator Valve; ABS Regulator; Modulator
- Replaces: 25641265
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1996-1999 Buick LeSabre | Custom, Limited | 6 Cyl 3.8 L GAS
View related parts
Buick LeSabre Pressure Valve
Part Number: 25641263
Product Specifications
- Other Name: Valve Assembly, Brake Pressure Mode; ABS Pump And Motor Assembly; ABS Control Module; Modulator Valve; ABS Pump Assembly; Pressure Modulator Valve; Modulator; Valve, Electronic Brake Control
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1996-1999 Buick LeSabre | Custom, Limited | 6 Cyl 3.8 L GAS
View related parts
Buick LeSabre Control Module
Part Number: 12226954
Product Specifications
- Other Name: Module Assembly, Electronic Brake & Traction Control; ABS Control Module; Module, Electronic Brake Control
- Replaces: 09387966, 12200802, 9387966, 12217068
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2000-2005 Buick LeSabre | Custom, Limited | 6 Cyl 3.8 L GAS
View related parts
Buick LeSabre Control Module
Part Number: 12226953
Product Specifications
- Other Name: Module Assembly, Electronic Brake & Traction Control; ABS Control Module; Module, Electronic Brake Control
- Replaces: 9382095, 9387967, 09382095, 09387967, 12216560
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2000-2002 Buick LeSabre | Custom, Limited | 6 Cyl 3.8 L GAS
View related parts
Buick LeSabre Control Module
Part Number: 12226951
Product Specifications
- Other Name: Module Assembly, Electronic Brake & Traction Control; ABS Control Module; Module, Electronic Brake Control
- Replaces: 09387968, 09382093, 9382093, 12216557, 9387968
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2000-2005 Buick LeSabre | Custom, Limited | 6 Cyl 3.8 L GAS
View related parts
Buick LeSabre Control Module
Part Number: 19244929
Product Specifications
- Other Name: Module Remanufacture; ABS Control Module; ABS Control Unit; Module
- Replaces: 16255396, 16242860
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1996-1999 Buick LeSabre | Custom, Limited | 6 Cyl 3.8 L GAS
View related parts
Buick LeSabre Control Module
Part Number: 19244928
Product Specifications
- Other Name: Module Remanufacture; ABS Control Module; Module
- Replaces: 16233378, 16242859, 16255394
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1996-1999 Buick LeSabre | Custom, Limited | 6 Cyl 3.8 L GAS
View related parts
Buick LeSabre Control Module
Part Number: 19244927
Product Specifications
- Other Name: Module Remanufacture; ABS Control Module; ABS Control Unit; Module
- Replaces: 16255393, 16233377
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1996-1999 Buick LeSabre | Custom, Limited | 6 Cyl 3.8 L GAS
View related parts
Buick LeSabre Pressure Valve
Part Number: 25610980
$709.30 MSRP: $1044.44
You Save: $335.14 (33%)
Product Specifications
- Other Name: ABS Control Module; Modulator Valve; Modulator
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1992-1993 Buick LeSabre | Custom, Limited | 6 Cyl 3.8 L GAS
View related parts
Buick LeSabre Control Module
Part Number: 25625047
Product Specifications
- Other Name: Module, Electronic Brake Control; ABS Control Module; ABS Control Unit; Module
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1994-1995 Buick LeSabre | Custom, Limited | 6 Cyl 3.8 L GAS
View related parts
Buick LeSabre Control Module
Part Number: 25625046
Product Specifications
- Other Name: Module, Electronic Brake Control; ABS Control Module; ABS Control Unit; Module
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1994-1995 Buick LeSabre | Custom, Limited | 6 Cyl 3.8 L GAS
View related parts
Buick LeSabre Control Module
Part Number: 25615670
Product Specifications
- Other Name: Module, Electronic Brake Control; ABS Control Module; ABS Control Unit; Module
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1992-1993 Buick LeSabre | Custom, Limited | 6 Cyl 3.8 L GAS
View related parts
Buick LeSabre Control Module
Part Number: 25557529
Product Specifications
- Other Name: Module, Electronic Brake Control; ABS Control Unit; Module
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1991-1993 Buick LeSabre | Base, Custom, Limited | 6 Cyl 3.8 L GAS
View related parts
Buick LeSabre Control Module
Part Number: 25530504
Product Specifications
- Other Name: Module, Electronic Brake Control; ABS Control Module; Module
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1987-1990 Buick LeSabre | Base, Custom, Limited, T-Type | 6 Cyl 3.8 L GAS
View related parts
Buick LeSabre Control Module
Part Number: 12232961
Product Specifications
- Other Name: Module Assembly, Electronic Brake & Traction Control; ABS Control Module; Module, Electronic Brake Control
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2003-2005 Buick LeSabre | Custom, Limited | 6 Cyl 3.8 L GAS
View related parts
Buick LeSabre Control Module
Part Number: 12226952
Product Specifications
- Other Name: Module Assembly, Electronic Brake & Traction Control; ABS Control Module; Module, Electronic Brake Control
- Replaces: 09387969, 09382094, 12216558, 9382094, 9387969
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2000 Buick LeSabre | Custom, Limited | 6 Cyl 3.8 L GAS

Buick LeSabre ABS Control Module

Our website offers an extensive catalog of genuine Buick LeSabre ABS Control Module at unbeatable prices. Every OEM Buick LeSabre ABS Control Module comes with a manufacturer's warranty, an easy return policy, and rapid delivery service. Don't miss out on this great opportunity!

Buick LeSabre ABS Control Module Parts Questions & Experts Answers

Control Module
12226951
Q: How to remove and install the ABS Control Module on Buick LeSabre?
A: The first steps to remove the ABS Control Module (ABSCM) start with flipping off the ignition and raising the vehicle. Start by removing the left front wheel followed by the left front wheelhouse extension before extracting the air pump when it is present. Release the abscm connector tab to the unlocked position then pull the abscm connector position assurance out from the abscm electrical connector. You should set the ignition switch to off before you connect or disconnect any wiring harness to stop equipment damage. Proceed to detach both the abscm electrical connector which sits on the abscm as well as the bpmv electrical connector which also connects to the abscm. You need to detach the 6 abscm to bpmv screws while cleaning the abscm/bpmv assembly surface for future repair reference. Incidentally the abscm cannot be serviced with faulty components it must receive replacement. The procedure requires abscm to be apart from bpmv. The installation process requires sealing the bpmv surface and implementing the abscm onto the bpmv while tightening each screw to 3.2 nm (28 inch lbs.). Connect both the bpmv electrical connector to the abscm while ensuring the ignition switch stays off and connect the abscm electrical connector to its mating abscm. The abscm connector position assurance assembly needs to be attached to the abscm electrical connector and the abscm connector tab requires rotation into a locked position. Put back the air pump if installed along with the left front wheelhouse extension while reinstalling the left front wheel before lowering the vehicle. An unprogrammed abscm might cause drp/abs/tcs/vses/tim/ves to malfunction if these systems are equipped while setting dtc c1248 and c1255m3. Any new abscm unit should receive programming for the latest software which matches the vehicle specifications. Use the scan tool to perform both dtc clearing then initiate the abs diagnostic system check.
