How to replace the rear suspension sway bar link on Cadillac SRX?

Start by elevating and supporting the car before you uninstall the tire and wheel from the designated position. The use of a hex tool to hold the shaft link stud will protect the link seal when removing the Sway Bar Link retaining nuts. The next step requires you to remove the Sway Bar Link from its connections between the sway bar and lower Control Arm. The installation process demands initial attachment of the Sway Bar Link to the lower Control Arm before joining it to the sway bar. A hex tool should be used to hold the shaft link stud while installing Sway Bar Link retaining nuts so the link seal does not get damaged. Tighten these nuts to 90 nm (67 ft. Lbs.). Complete the process by putting back the tire then wheel before raising the vehicle.

OEM Cadillac SRX Sway Bar Link

Stabilizer Sway Bar Link

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

5 Sway Bar Links found

View related parts
Cadillac SRX Stabilizer Link Part Number: 20984481
$29.98 MSRP: $56.30
You Save: $26.32 (47%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Link, Stabilizer Shaft; Suspension Stabilizer Bar Link Kit; Control Arm; Sway Bar Link; Link
- Position: Front
- Replaces: 15870889
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2010-2016 Cadillac SRX | Base, Luxury, Performance, Premium | 6 Cyl 2.8 L GAS, 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
View related parts
Cadillac SRX Stabilizer Link, Rear Part Number: 20929893
$16.01 MSRP: $30.07
You Save: $14.06 (47%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Link Assembly-Rear Stabilizer Shaft; Suspension Stabilizer Bar Link Kit; Stabilizer Bar Link Kit; Sway Bar Link; Link; Link, Stabilizer Shaft
- Position: Rear
- Replaces: 20849995
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2010-2016 Cadillac SRX | Base, Luxury, Performance, Premium | 6 Cyl 2.8 L GAS, 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
View related parts
Cadillac SRX Stabilizer Link, Rear Passenger Side Part Number: 15895320
$16.69 MSRP: $31.35
You Save: $14.66 (47%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Link Assembly-Rear Stabilizer Shaft; Suspension Stabilizer Bar Link Kit; Stabilizer Bar Link Kit; Sway Bar Link; Link; Link, Stabilizer Shaft
- Position: Rear Passenger Side
- Replaces: 25768312, 15840472
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2004-2009 Cadillac SRX | Base | 6 Cyl 3.6 L GAS, 8 Cyl 4.6 L GAS
View related parts
Cadillac SRX Stabilizer Link Part Number: 15231140
$78.87 MSRP: $140.85
You Save: $61.98 (44%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Link, Stabilizer Shaft; Suspension Stabilizer Bar Link Kit; Stabilizer Bar Link Kit; Sway Bar Link; Link
- Position: Front
- Replaces: 25768143
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2004-2009 Cadillac SRX | Base | 6 Cyl 3.6 L GAS, 8 Cyl 4.6 L GAS
View related parts
Cadillac SRX Stabilizer Link, Rear Driver Side Part Number: 15895319
Product Specifications
- Other Name: Link Assembly-Rear Stabilizer Shaft; Suspension Stabilizer Bar Link Kit; Stabilizer Bar Link Kit; Sway Bar Link; Link; Link, Stabilizer Shaft
- Position: Rear Driver Side
- Replaces: 25768311, 15840471
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2004-2009 Cadillac SRX | Base | 6 Cyl 3.6 L GAS, 8 Cyl 4.6 L GAS

Cadillac SRX Sway Bar Link

Want to cut long-term maintenance and repair costs? Choose OEM Sway Bar Link. Those parts deliver top durability you can trust. On our site, you'll find a huge catalog of genuine Cadillac SRX parts. Prices are unbeatable, so you can keep more in your pocket. Every OEM Cadillac SRX Sway Bar Link includes a manufacturer's warranty. You can also get an easy return policy that keeps buying risk free. Fast delivery, get your car on the road quickly. It's simple to search, compare, and order. Stop guessing about quality or fit. Order today and save with parts that last.

This is a part with high complexity and importance in the Cadillac SRX which actually plays a big role in improving the performance and ability of Cadillac SRX automobiles. The Sway Bar Link links the sway bar with the control arm and has the function of controlling body roll during cornering to keep Mass being evenly distributed with excellent handling characteristic for the Cadillac SRX. It makes it possible for the sway bar to easily resist movement on the inside tire while compressing the opposite side, which is imperative for both efficiency as well as protection. The Sway Bar Link is responsible for the appropriate engagement of the sway bar and suspension parts and is applicable to all Cadillac SRX versions- both first and second generations. Specifically, the Sway Bar Link helps in achieving good control and comfort of the car; therefore, it cannot be overlooked in a Cadillac luxury SUV. As a reliable automobile product, the Sway Bar Link has all the factors that can make it distinct and outstanding among other products within the auto-marketplace since it is very strong always pull off several-enhancing characteristics. Italian for 'swing bar'; the Sway Bar Link proves to be especially valuable in Cadillac SRX, this model is characterized by its rather aggressive design and utilizing of a high number of innovative technologies the Sway Bar Link proves to be especially useful as it contributes to the delivery of the outstanding driving experience. In sum, the Sway Bar Link is one of Cadillac's great creations that speak about quality, safety, and excellence in performance in every trip that car owners in Cadillac SRX will experience.

Cadillac SRX Sway Bar Link Parts Questions & Experts Answers

Stabilizer Link, Rear Passenger Side
15895320
Q: How to replace the rear suspension sway bar link on Cadillac SRX?
A:
Start by elevating and supporting the car before you uninstall the tire and wheel from the designated position. The use of a hex tool to hold the shaft link stud will protect the link seal when removing the Sway Bar Link retaining nuts. The next step requires you to remove the Sway Bar Link from its connections between the sway bar and lower Control Arm. The installation process demands initial attachment of the Sway Bar Link to the lower Control Arm before joining it to the sway bar. A hex tool should be used to hold the shaft link stud while installing Sway Bar Link retaining nuts so the link seal does not get damaged. Tighten these nuts to 90 nm (67 ft. Lbs.). Complete the process by putting back the tire then wheel before raising the vehicle.
