OEM Cadillac Throttle Position Sensor
TPS Switch- Select Vehicle by Model
- Select Vehicle by VIN
Select Vehicle by Model
orMake
Model
Year
Select Vehicle by VIN
For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).
16 Throttle Position Sensors found
Cadillac Throttle Position Sensor
Part Number: 19259452$96.31 MSRP: $195.60You Save: $99.29 (51%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Sensor Kit, Multi Portion Fuel Injection Throttle Position; Sensor; Sensor Kit, Computer Control Sensors
Cadillac Throttle Position Sensor
Part Number: 17106681$46.66 MSRP: $94.76You Save: $48.10 (51%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Sensor, Multi Portion Fuel Injection Throttle Position; Sensor Kit, Multi Portion Fuel Injection Throttle Position; Throttle Body Sensors; Computer Control Sensors
- Replaces: 17112404, 17112679, 17087653
Product Specifications- Other Name: Sensor Assembly, Carburetor Throttle Position
Cadillac Throttle Position Sensor
Part Number: 17111606$71.46 MSRP: $145.15You Save: $73.69 (51%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Sensor Kit, Multi Portion Fuel Injection Throttle Position
Cadillac Throttle Position Sensor
Part Number: 17111262$106.56 MSRP: $192.85You Save: $86.29 (45%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Sensor Assembly, Carburetor Throttle Position
Cadillac Throttle Position Sensor
Part Number: 17110352$66.67 MSRP: $125.18You Save: $58.51 (47%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Sensor Kit, Multi Portion Fuel Injection Throttle Position; Sensor Kit, Computer Control Sensors
Product Specifications- Other Name: Sensor, Multi Portion Fuel Injection Throttle Position
Product Specifications- Other Name: Sensor Kit, Multi Portion Fuel Injection Throttle Position; Sensor, Multi Portion Fuel Injection Throttle Position; Sensor Kit, Computer Control Sensors
- Replaces: 25180131
Product Specifications- Other Name: Sensor, Throttle Position; Sensor Kit, Multi Portion Fuel Injection Throttle Position; Sensor Kit, Computer Control Sensors
- Replaces: 17112609
- Product Specifications
- Other Name: Sensor Kit, Multi Portion Fuel Injection Throttle Position
- Replaced by: 17106684
Product Specifications- Other Name: Sensor, Multi Portion Fuel Injection Throttle Position; Throttle Sensor
Product Specifications- Other Name: Sensor Kit, Multi Portion Fuel Injection Throttle Position; Sensor Kit, Computer Control Sensors
Product Specifications- Other Name: Sensor, Multi Portion Fuel Injection Throttle Position; Sensor, Computer Control Sensors
- Replaces: 17087655, 17083333
Product Specifications- Other Name: Sensor Kit, Computer Control Sensors; Sensor Kit, Multi Portion Fuel Injection Throttle Position; Throttle Body Position Sensor.
- Replaces: 17087654, 17112677
Product Specifications- Other Name: Sensor Assembly, Throttle Position; Sensor, Multi Portion Fuel Injection Throttle Position
Cadillac Throttle Position Sensor Parts Questions & Experts Answers
- Q: How to service and repair the Throttle Position Sensor on Cadillac DeVille?A: The first step to service and repair the Throttle Position Sensor requires removal of three connectors: idle air control (IAC) from the iac sensor and manifold absolute pressure (MAP) from the MAP Sensor. The first step is to unscrew the tp sensor retaining screws while also disconnecting the electrical connector from the tp sensor. Following this remove the water pump belt cover before finally disconnecting the tp sensor electrical connector from the tp sensor. To install the new system, start by putting an o-ring on the tp sensor and connecting the tp sensor electrical connector to the tp sensor before mounting the tp sensor on the Throttle Body where the tp sensor screws require 2.3 n.m (20 lb in) torque. Resecure the iac electrical connector to the iac sensor while also reattaching the MAP Sensor electrical connector to the MAP Sensor. Then reinstall the water pump belt and tensioner cover. The tp sensor learn procedure requires a one-minute run/on ignition period followed by 15 seconds of lock/off ignition state.
- Q: How to service and repair the Throttle Position Sensor on Cadillac Eldorado?A: Start servicing the Throttle Position Sensor by disconnecting two electrical connectors: the idle air control (IAC) connector from the iac sensor and the manifold absolute pressure (MAP) connector from the MAP Sensor. First remove the water pump belt cover before removing the throttle position (TP) sensor retaining screws which allow you to disconnect the tp sensor electrical connector from the tp sensor. Install a new o-ring onto the tp sensor before attaching the tp sensor electrical connector to its location. The Throttle Body receives the tp sensor after fixation of the tp sensor screws to 2.3 n.m (20 lb in). After reattaching the iac electrical connector to the iac sensor and the MAP Sensor electrical connector to the MAP Sensor complete the process by reinstalling your water pump belt and tensioner cover. Conduct the tp sensor learn procedure by activating the run/on position through the ignition switch for one minute before returning to lock/off and waiting 15 seconds.
- Q: How to service and repair the Throttle Position Sensor on Cadillac Seville?A: Before repairing or servicing the Throttle Position Sensor begin by removing the idle air control (IAC) electrical connector from the iac sensor as well as the manifold absolute pressure (MAP) sensor electrical connector from the MAP Sensor. Begin by removing the water pump belt cover before disconnecting the tp sensor electrical connector and removing the tp sensor retaining screws electrical connector from the tp sensor . After installing a new o-ring onto the tp sensor connect the tp sensor electrical connector to the tp sensor . Secure the tp sensor to the Throttle Body using proper torque settings of 2.3 n.m (20 lb in). The iac sensor connection should be secured to the iac sensor through its own electrical connector while the MAP Sensor electrical connector gets restored to the MAP Sensor. Last steps include putting back the water pump belt and its tensioner cover followed by conducting the tp sensor learn procedure through ignition cycles embracing 1 minute on run position and 15 seconds on the lock position.
