How to replace the Upper Steering Column Bearing on Cadillac Escalade?

First, you need to remove the Steering Column to replace the upper part of the Steering Shaft bearing. Next, remove the inflatable restraint steering wheel module coil, as well as the turn signal multifunction switch and ignition lock cylinder case. Then take out the tilt spring and the auto transmission control as well. With the aid of compressor (J 23653-SIR) and adapter (J 42137), pull out and discard the Steering Shaft lock plate retaining ring. Remove the Turn Signal Switch cancel cam position plate , turn signal switch cancel cam , steering shaft upper bearing spring , steering shaft upper bearing inner race seat , and Steering Shaft upper bearing inner race from the Steering Column shaft assembly. Take out the two pivot pins from the Steering Column tilt head assembly using remover (J 21854-01). Install the tilt lever into the Steering Column tilt head assembly, pull back on the tilt lever, and pull the Steering Column tilt head assembly down and away from the Steering Column. Disassembly Steering Column tilt head replacing Steering Shaft upper bearing. Take out anti-rotation pin (J 42640) and the tilt lever, replace the Steering Shaft upper bearing from the Steering Column tilt head. During installation, capture the Steering Shaft upper bearing on the Steering Column tilt head assembly, and thereafter, install the Steering Column shaft assembly. Maneuver and push the Steering Column tilt head assembly in the direction of Steering Column to lock the steering wheel lock shoes. Lubricate the pivot pins with gm p/n 12346293 (Canadian P/N 992723), and firmly seat each pivot pin into the Steering Column tilt head assembly, staking the Steering Column at three locations around each pivot pin. Install anti rotation pin (J 42640) and then work the following components onto the Steering Column shaft assembly. Lubricate the Steering Shaft upper bearing inner race with gm p/n 12345718 (Canadian P/N 10953516), install Steering Shaft upper bearing inner race, inner race seat, spring, lubricate Turn Signal Switch cancel cam with gm p/n 12377900 (Canadian P/N 10953529), install Turn Signal Switch cancel cam, position plate. Last but not least, install the new Steering Shaft lock plate retaining ring onto the Steering Shaft using compressor (J 23653-SIR) and adapter (J 42137), then the automatic transmission control assembly, tilt spring, ignition lock cylinder case, turn signal multifunction switch, inflatable restraint steering wheel module coil, and the Steering Column.

OEM Cadillac Upper Steering Column Bearing

Upper Tilt Steering Column Bearing

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

12 Upper Steering Column Bearings found

View related parts
Cadillac Shaft Bearings, Lower Part Number: 7827111
$15.59 MSRP: $21.33
You Save: $5.74 (27%)
ADD TO CART
Product Specifications
- Other Name: Bearing, Bowl Lower; Lower Bowl; Lower Bearing; Bowl Bearing; Shroud Bearing; Bearing; Bearings; Bearing, Steering Column; Bearing, Steering
- Position: Lower
Fits the following Cadillac Models:
- Brougham | 1987 | Base, d'Elegance | 8 Cyl 5.0 L GAS
- DeVille | 1985-1987 | Base, Cabriolet, d'Elegance, Touring | 6 Cyl 4.3 L DIESEL, 8 Cyl 4.1 L GAS
- Fleetwood | 1985-1987 | 60 Special, 75, 75 Formal, Base, Brougham, Brougham d'Elegance, d'Elegance | 6 Cyl 4.3 L DIESEL, 8 Cyl 4.1 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L DIESEL
View More
View related parts
Cadillac Bearing Assembly Part Number: 88963617
$33.09 MSRP: $54.51
You Save: $21.42 (40%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Bearing, Steering Column; Bearing Kit; Lower Bearing; Lower Bearings
- Position: Lower
- Replaces: 26069723, 26056146
Fits the following Cadillac Models:
- Escalade | 2002-2006 | Base | 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
- Escalade ESV | 2003-2006 | Base | 8 Cyl 6.0 L GAS
- Escalade EXT | 2002-2006 | Base | 8 Cyl 6.0 L GAS
View More
View related parts
Cadillac Shaft Bearings Part Number: 26001827
$50.91 MSRP: $86.67
You Save: $35.76 (42%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Bearing Assembly, Steering Column; Bearing Assembly; Bearing Kit; Housing Bearing; Upper/Lower Bearings; Steering Column Bearings.
- Position: Upper
Fits the following Cadillac Models:
- Allante | 1991-1993 | Base, Indianapolis 500 Pace Car, Value Leader | 8 Cyl 4.5 L GAS, 8 Cyl 4.6 L GAS
- Cimarron | 1984-1988 | Base, d'Oro | 4 Cyl 2.0 L GAS, 6 Cyl 2.8 L GAS
- DTS | 2006-2011 | Base, Livery, Luxury, Platinum, Premium | 8 Cyl 4.6 L GAS
- DeVille | 2000-2005 | Base, DHS, DTS, Protection Series | 8 Cyl 4.6 L GAS
- Eldorado | 1998-2001 | ESC, ETC | 8 Cyl 4.6 L GAS
- Escalade | 2007-2014, 2002-2004, 1999-2000 | Base, Hybrid, Hybrid Platinum, Luxury, Platinum, Premium | 8 Cyl 5.3 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.0 L FULL HYBRID EV-FLEX (FHEV), 8 Cyl 6.0 L FULL HYBRID EV-GAS (FHEV), 8 Cyl 6.0 L GAS, 8 Cyl 6.2 L FLEX, 8 Cyl 6.2 L GAS
- Escalade ESV | 2007-2014 | Base, Luxury, Platinum, Premium | 8 Cyl 6.2 L FLEX, 8 Cyl 6.2 L GAS
- Escalade EXT | 2007-2013 | Base, Luxury, Premium | 8 Cyl 6.2 L FLEX, 8 Cyl 6.2 L GAS
- Fleetwood | 1984 | Formal | 8 Cyl 6.0 L GAS
- Seville | 1991 | Base, STS | 8 Cyl 4.9 L GAS
View More
View related parts
Cadillac Bearing Housing, Upper Part Number: 7819517
$41.29 MSRP: $74.96
You Save: $33.67 (45%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Bearing S; Shaft Bearings; Cover Bearing; Upper Housing; Lock Housing; Rack Package; Shroud; Steering Column
- Position: Upper
Fits the following Cadillac Models:
- Brougham | 1987 | Base, d'Elegance | 8 Cyl 5.0 L GAS
- Cimarron | 1984-1988 | Base, d'Oro | 4 Cyl 2.0 L GAS, 6 Cyl 2.8 L GAS
- DeVille | 1985-1987 | Base, Cabriolet, d'Elegance, Touring | 6 Cyl 4.3 L DIESEL, 8 Cyl 4.1 L GAS
- Escalade | 1999-2000 | Base | 8 Cyl 5.7 L GAS
- Fleetwood | 1985-1987 | 60 Special, 75, 75 Formal, Base, Brougham, Brougham d'Elegance, d'Elegance | 6 Cyl 4.3 L DIESEL, 8 Cyl 4.1 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L DIESEL
View More
View related parts
Cadillac Bearing Part Number: 26002086
$8.18 MSRP: $19.12
You Save: $10.94 (58%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Bearing, Steering Column
- Position: Lower
Fits the following Cadillac Models:
- Catera | 1997-2001 | Base, Sport | 6 Cyl 3.0 L GAS
View related parts
Cadillac Lower Bearing Part Number: 26100500
Product Specifications
- Other Name: Bearing, Steering Shaft Lower (W/Adapter); Lower Bearings; Bearing; Bearings; Bearing, Steering Column
- Position: Lower
- Replaces: 26077389
Fits the following Cadillac Models:
- Seville | 1998-2004 | SLS, STS | 8 Cyl 4.6 L GAS
View related parts
Cadillac Lower Bearing Part Number: 7805700
$59.95 MSRP: $93.92
You Save: $33.97 (37%)
Product Specifications
- Other Name: Bearing, Steering Shaft Lower; Shift Tube Bearing; Lower Shaft Tube; Lower Bearings; Bearing; Bearings; Bearing, Steering Column
- Position: Lower
Fits the following Cadillac Models:
- Brougham | 1992 | Base, d'Elegance | 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS
- Fleetwood | 1993-1996 | Base, Brougham | 8 Cyl 5.7 L GAS
View related parts
Cadillac Shaft Bearings, Upper Part Number: 7845268
Product Specifications
- Other Name: Bearing, Steering Shaft Upper; Bearing; Bearings; Bearing Kit, Steering Column; Bearing, Steering Column
- Position: Upper
Fits the following Cadillac Models:
- Allante | 1987-1989 | Base | 8 Cyl 4.1 L GAS, 8 Cyl 4.5 L GAS
- Eldorado | 1986-1989 | Base, Biarritz | 8 Cyl 4.1 L GAS, 8 Cyl 4.5 L GAS
- SRX | 2004-2008 | Base | 6 Cyl 3.6 L GAS, 8 Cyl 4.6 L GAS
- Seville | 1986-1990 | Base, Elegante, STS | 8 Cyl 4.1 L GAS, 8 Cyl 4.5 L GAS
View More
View related parts
Cadillac Lower Bearing Part Number: 26081301
Product Specifications
- Other Name: Bearing, Steering Column; Bearing
- Position: Lower
- Replaces: 26037395
Fits the following Cadillac Models:
- Escalade | 1999-2000 | Base | 8 Cyl 5.7 L GAS
View related parts
Cadillac Shaft Bearings Part Number: 26078225
Product Specifications
- Other Name: Bearing, Steering Column; Lock Housing Bearing; Bearing
Fits the following Cadillac Models:
- DeVille | 2000-2004 | Base, DHS, DTS, Protection Series | 8 Cyl 4.6 L GAS
- STS | 2005-2011 | Base, Platinum, V | 6 Cyl 3.6 L GAS, 8 Cyl 4.4 L GAS, 8 Cyl 4.6 L GAS
- XLR | 2004-2009 | Base, Platinum, V | 8 Cyl 4.4 L GAS, 8 Cyl 4.6 L GAS
View More
View related parts
Cadillac Lower Bearing Part Number: 26052238
Product Specifications
- Other Name: Bearing, Steering Column; Bearing; Bearings
- Position: Lower
Fits the following Cadillac Models:
- Escalade | 1999-2000 | Base | 8 Cyl 5.7 L GAS
View related parts
Cadillac Shaft Bearings Part Number: 26006244
Product Specifications
- Other Name: Bearing, Steering Column; Bearing Assembly; Lower Bearing; Shift Tube Bearing; Jacket Bearing; Lower Bearings; Bearing; Bearings
- Position: Lower
Fits the following Cadillac Models:
- 60 Special | 1993 | Base | 8 Cyl 4.9 L GAS
- Allante | 1990-1993 | Base, Indianapolis 500 Pace Car, Value Leader | 8 Cyl 4.5 L GAS, 8 Cyl 4.6 L GAS
- Brougham | 1987-1991 | Base, d'Elegance | 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS
- DeVille | 1985-1999 | Base, Cabriolet, Concours, d'Elegance, Spring Edition, Touring | 6 Cyl 4.3 L DIESEL, 8 Cyl 4.1 L GAS, 8 Cyl 4.5 L GAS, 8 Cyl 4.6 L GAS, 8 Cyl 4.9 L GAS
- Eldorado | 1986-2002 | Base, Biarritz, ESC, ETC, Sport, Spring Edition, Touring | 8 Cyl 4.1 L GAS, 8 Cyl 4.5 L GAS, 8 Cyl 4.6 L GAS, 8 Cyl 4.9 L GAS
- Fleetwood | 1985-1993 | 60 Special, 75, 75 Formal, Base, Brougham, Brougham d'Elegance, d'Elegance | 6 Cyl 4.3 L DIESEL, 8 Cyl 4.1 L GAS, 8 Cyl 4.5 L GAS, 8 Cyl 4.9 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L DIESEL, 8 Cyl 5.7 L GAS
- Seville | 1986-1997 | Base, Elegante, SLS, STS | 8 Cyl 4.1 L GAS, 8 Cyl 4.5 L GAS, 8 Cyl 4.6 L GAS, 8 Cyl 4.9 L GAS
View More

Cadillac Upper Steering Column Bearing

Choose OEM Upper Steering Column Bearing, you're making the optimal decision for superior quality and perfect performance. You can feel confident because each component goes through stringent quality checks. Every part is carefully built to comply with Cadillac's factory specifications. You'll enjoy a smooth, worry-free installation that fits just right. At ChevyPartsGiant.com, you'll find it easy to get top-quality OEM Cadillac Upper Steering Column Bearing. You can shop at highly competitive prices and protect your budget. All our genuine Cadillac parts include a dependable manufacturer's warranty. You'll also appreciate our straightforward return policy and swift delivery services for extra convenience.

Cadillac Upper Steering Column Bearing Parts and Q&A

Shaft Bearings
26001827
Q: How to replace the Upper Steering Column Bearing on Cadillac Escalade?
A:
First, you need to remove the Steering Column to replace the upper part of the Steering Shaft bearing. Next, remove the inflatable restraint steering wheel module coil, as well as the turn signal multifunction switch and ignition lock cylinder case. Then take out the tilt spring and the auto transmission control as well. With the aid of compressor (J 23653-SIR) and adapter (J 42137), pull out and discard the Steering Shaft lock plate retaining ring. Remove the Turn Signal Switch cancel cam position plate , turn signal switch cancel cam , steering shaft upper bearing spring , steering shaft upper bearing inner race seat , and Steering Shaft upper bearing inner race from the Steering Column shaft assembly. Take out the two pivot pins from the Steering Column tilt head assembly using remover (J 21854-01). Install the tilt lever into the Steering Column tilt head assembly, pull back on the tilt lever, and pull the Steering Column tilt head assembly down and away from the Steering Column. Disassembly Steering Column tilt head replacing Steering Shaft upper bearing. Take out anti-rotation pin (J 42640) and the tilt lever, replace the Steering Shaft upper bearing from the Steering Column tilt head. During installation, capture the Steering Shaft upper bearing on the Steering Column tilt head assembly, and thereafter, install the Steering Column shaft assembly. Maneuver and push the Steering Column tilt head assembly in the direction of Steering Column to lock the steering wheel lock shoes. Lubricate the pivot pins with gm p/n 12346293 (Canadian P/N 992723), and firmly seat each pivot pin into the Steering Column tilt head assembly, staking the Steering Column at three locations around each pivot pin. Install anti rotation pin (J 42640) and then work the following components onto the Steering Column shaft assembly. Lubricate the Steering Shaft upper bearing inner race with gm p/n 12345718 (Canadian P/N 10953516), install Steering Shaft upper bearing inner race, inner race seat, spring, lubricate Turn Signal Switch cancel cam with gm p/n 12377900 (Canadian P/N 10953529), install Turn Signal Switch cancel cam, position plate. Last but not least, install the new Steering Shaft lock plate retaining ring onto the Steering Shaft using compressor (J 23653-SIR) and adapter (J 42137), then the automatic transmission control assembly, tilt spring, ignition lock cylinder case, turn signal multifunction switch, inflatable restraint steering wheel module coil, and the Steering Column.
