How to service the lower ball joint on GMC Jimmy?

Start servicing the lower Ball Joint by raising and supporting the vehicle before taking off its tire and wheel components. After taking off the Torsion Bar you should remove the wheel drive shaft from its position. Start with a 3.175mm (1/8 inch) drill to make a 6.35mm (1/4 inch) deep hole at the center of lower Ball Joint rivet. Shift to a 12.7mm (1/2 inch) drill to remove the rivet heads. Push the pin punch through each rivet to unfasten them before taking the lower Ball Joint out of the Control Arm. Slip the lower Ball Joint onto its position on the lower Control Arm while keeping to the fastener notice instructions. Connect the lower Ball Joint bolts and nuts then tighten them to 23 nm (17 ft. Lbs.) torque. Put the wheel drive shaft back and position the Torsion Bar before putting tire and wheel together. After putting the vehicle down end to end check the front wheel alignment.

OEM GMC Jimmy Ball Joint

Control Arm Joint

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

6 Ball Joints found

View related parts
GMC Jimmy Ball Joint, Front Upper Part Number: 88911387
$34.06 MSRP: $60.81
You Save: $26.75 (44%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Joint Kit, Front Upper Control Arm Ball; Suspension Ball Joint; Upper Ball Joint; Stud Kit, Steering Knuckle Control Arm; Ball Joint Kit
- Position: Front Upper
- Replaced by: 19460397
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1992-2001 GMC Jimmy | Base, Diamond Edition, Envoy, SL, SLE, SLS, SLT | 6 Cyl 4.3 L GAS
View related parts
GMC Jimmy Ball Joint, Front Lower Part Number: 19416895
$20.58 MSRP: $50.23
You Save: $29.65 (60%)
ADD TO CART
Product Specifications
- Other Name: Stud Kit, Front Lower Control Arm Ball; Ball Joints; Lower Ball Joint Kit for Steering Knuckle and Front Wheel Control Arm.
- Position: Front Lower
- Replaces: 09767281, 9767281, 19122185
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1992-2001 GMC Jimmy | Base, Diamond Edition, Envoy, SL, SLE, SLS, SLT | 6 Cyl 4.3 L GAS
View related parts
GMC Jimmy Lower Ball Joint Part Number: 88967425
$65.21 MSRP: $107.41
You Save: $42.20 (40%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Stud Kit, Front Lower Control Arm Ball; Suspension Ball Joint; Ball Joint; Stud Kit, Steering Knuckle Lower Control Arm Pivot; Stud, Steering Knuckle Lower Control Arm Pivot
- Position: Front Lower
- Replaces: 22156908, 17980954
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1992-2001 GMC Jimmy | Base, Diamond Edition, Envoy, SL, SLE, SLS, SLT | 6 Cyl 4.3 L GAS
View related parts
GMC Jimmy Ball Joint, Lower Part Number: 9766423
Product Specifications
- Other Name: Stud Assembly, Steering Knuckle Lower Control Arm Ball; Suspension Ball Joint; Lower Ball Joint; Ball Joint, Steering Knuckle Lower Control Arm Pivot; Stud, Steering Knuckle Lower Control Arm Pivot
- Position: Lower
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1990-1991, 1984 GMC Jimmy | Base, Sierra Classic | 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL
View related parts
GMC Jimmy Ball Joint Part Number: 9769576
Product Specifications
- Other Name: Ball Joint Kit, Steering Knuckle Upper; Upper Ball Joint; Kit for Steering Knuckle Upper Control Arm; Stud Kit
- Position: Upper
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1984 GMC Jimmy | Base | 8 Cyl 5.0 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.2 L DIESEL
View related parts
GMC Jimmy Upper Ball Joint, Front Part Number: 19133669
Product Specifications
- Other Name: Stud Kit, Front Upper Control Arm Ball; Suspension Ball Joint; Ball Joint; Upper Ball Joints; Steering Knuckle Upper Control Arm; Stud Kit.
- Position: Front Upper
- Replaces: 17980952
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1992-2001 GMC Jimmy | Base, Diamond Edition, Envoy, SL, SLE, SLS, SLT | 6 Cyl 4.3 L GAS

GMC Jimmy Ball Joint

Want to cut long-term maintenance and repair costs? Choose OEM Ball Joint. Those parts deliver top durability you can trust. On our site, you'll find a huge catalog of genuine GMC Jimmy parts. Prices are unbeatable, so you can keep more in your pocket. Every OEM GMC Jimmy Ball Joint includes a manufacturer's warranty. You can also get an easy return policy that keeps buying risk free. Fast delivery, get your car on the road quickly. It's simple to search, compare, and order. Stop guessing about quality or fit. Order today and save with parts that last.

GMC Jimmy vehicles Ball Joint is known to play the role of suspension and steering systems where it links the control arm to the steering knuckle. Thus, these ball joints allow to turn with no restrictions in two perpendicular planes while at the same time not allowing for the translation movement which together with the mentioned above characteristics improves vehicle handling, stability and ride comfort. GMC Jimmy cars mostly have upper and lower ball joints; the additional ball joints in the rear suspension depend on the model. A ball joint is made of steel with a bearing stud and a socket enclosed in a rubber-like boot to keep them from coming in contact with dirty resulting in limited lubrication. These components are crucial in the way through which tire contacts the road with the aim of enhancing the performance of the vehicle.

GMC Jimmy Ball Joint Parts Questions & Experts Answers

Lower Ball Joint
88967425
Q: How to service the lower ball joint on GMC Jimmy?
A:
Start servicing the lower Ball Joint by raising and supporting the vehicle before taking off its tire and wheel components. After taking off the Torsion Bar you should remove the wheel drive shaft from its position. Start with a 3.175mm (1/8 inch) drill to make a 6.35mm (1/4 inch) deep hole at the center of lower Ball Joint rivet. Shift to a 12.7mm (1/2 inch) drill to remove the rivet heads. Push the pin punch through each rivet to unfasten them before taking the lower Ball Joint out of the Control Arm. Slip the lower Ball Joint onto its position on the lower Control Arm while keeping to the fastener notice instructions. Connect the lower Ball Joint bolts and nuts then tighten them to 23 nm (17 ft. Lbs.) torque. Put the wheel drive shaft back and position the Torsion Bar before putting tire and wheel together. After putting the vehicle down end to end check the front wheel alignment.
