How to replace the A/C Condenser on Cadillac CTS?

Before replacing the condenser, refrigerant recovery should be the initial step. The vehicle needs to be lifted and stabilized with support. Begin by removing the front air deflector retainers followed by removing front air deflector bolts then pull out the front air deflector . Start by taking out the condenser lower mounting bolts and then follow with the condenser upper bracket bolts. To replace the condenser first remove the discharge line bolt and disconnect the discharge line from the condenser. Dispose of the O-ring before continuing with the replacement process. Remove the condenser tube bolt to disconnect the tube from the condenser before discarding both its O-ring components. When replacing the condenser you must directly add PAG oil according to specifications before installing the new condenser. Before joining the condenser tube to the condenser, install the new condenser and also install a new O-ring to the condenser tube. Tighten the condenser tube bolt to 9 N.m after installing it (80 lb in torque specification). Position a fresh O-ring onto the discharge line then attach the discharge line to the condenser before adding the discharge line bolt and tightening it to 9 N.m (80 lb in). You should first install the condenser lower mounting bolts at 5.4 N.m (48 lb in) torque then move to the upper bracket bolts at 5.4 N.m (48 lb in). Secure the front air deflector to the vehicle by tightening the front air deflector bolts along with the retainers . Install the power steering cooler mounting bolts then lower the vehicle before evacuating and charging the A/C system. Perform leak testing on component fittings through the use of the Halogen Leak Detector (J 39400-A).

OEM Cadillac CTS A/C Condenser

Air Conditioning Condenser

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

8 A/C Condensers found

View related parts
Cadillac CTS Oil Cooler Part Number: 22966150
$144.04 MSRP: $246.67
You Save: $102.63 (42%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser; Condenser, A/C Condenser
- Replaces: 22799461
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2014-2016 Cadillac CTS | Base, Luxury, Performance, Premium | 4 Cyl 2.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
View related parts
Cadillac CTS Condenser Part Number: 20929423
$146.11 MSRP: $250.21
You Save: $104.10 (42%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser A/C; Condenser, A/C Condenser
- Replaces: 15932849
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2008-2014 Cadillac CTS | Base, Luxury, Performance, Premium, V, Vsport, Vsport Premium | 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS, 8 Cyl 6.2 L GAS
View related parts
Cadillac CTS Condenser Part Number: 84947859
$150.08 MSRP: $257.00
You Save: $106.92 (42%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser, A/C Condenser
- Replaced by: 86551898
- Replaces: 23455461
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2016-2019 Cadillac CTS | V | 8 Cyl 6.2 L GAS
View related parts
Cadillac CTS Oil Cooler Part Number: 84947858
$197.67 MSRP: $338.51
You Save: $140.84 (42%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Condenser Assembly-A/C; Condenser; Condenser, A/C Condenser
- Replaced by: 86551897
- Replaces: 22966151, 22799449
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2014-2019 Cadillac CTS | Base, Luxury, Performance, Premium, Premium Luxury | 4 Cyl 2.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
View related parts
Cadillac CTS Oil Cooler Part Number: 84947857
$120.10 MSRP: $205.66
You Save: $85.56 (42%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Condenser Assembly-A/C; Condenser; Condenser, A/C Condenser
- Replaced by: 86551896
- Replaces: 23452331
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2016-2019 Cadillac CTS | Base, Luxury, Performance, Premium, Premium Luxury | 4 Cyl 2.0 L GAS, 6 Cyl 3.6 L GAS
View related parts
Cadillac CTS Condenser Part Number: 25876662
$242.13 MSRP: $361.92
You Save: $119.79 (34%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser, A/C Condenser
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2009-2015 Cadillac CTS | V | 8 Cyl 6.2 L GAS
View related parts
Cadillac CTS Condenser Part Number: 22990683
$180.91 MSRP: $270.42
You Save: $89.51 (34%)
ADD TO CART
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser, A/C Condenser
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2014-2019 Cadillac CTS | Vsport, Vsport Premium, Vsport Premium Luxury | 6 Cyl 3.6 L GAS
View related parts
Cadillac CTS Upper Hose Part Number: 19355727
Product Specifications
- Other Name: Condenser Assembly, A/C; Transmission Oil Cooler Hose; A/C Condenser; Condenser A/C; Condenser; Condenser, A/C Condenser
- Replaces: 25728392, 19129982
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2003-2007 Cadillac CTS | Base, Luxury, Luxury Sport, V | 6 Cyl 2.8 L GAS, 6 Cyl 3.2 L GAS, 6 Cyl 3.6 L GAS, 8 Cyl 5.7 L GAS, 8 Cyl 6.0 L GAS

Cadillac CTS A/C Condenser

Want to cut long-term maintenance and repair costs? Choose OEM A/C Condenser. Those parts deliver top durability you can trust. On our site, you'll find a huge catalog of genuine Cadillac CTS parts. Prices are unbeatable, so you can keep more in your pocket. Every OEM Cadillac CTS A/C Condenser includes a manufacturer's warranty. You can also get an easy return policy that keeps buying risk free. Fast delivery, get your car on the road quickly. It's simple to search, compare, and order. Stop guessing about quality or fit. Order today and save with parts that last.

The A/C Condenser in Cadillac CTS automobile acts as condenser which cools the gaseous refrigeration and changes into liquid refrigeration before entering into the accumulator. Usually located ahead of the radiator, it contains a system of tubes through which the cooling process takes place. Although the overview does not point out differences in the types or styles of A/C Condenser used for different CTS models, their basic structure and operations are the same; it is designed and used for effective cooling of refrigerant. A/C Condenser serves a very important function in the overall working of the automobile where air conditioning feature is available for the sake of providing the optimal comfort of the cabin.

Cadillac CTS A/C Condenser Parts and Q&A

Condenser
20929423
Q: How to replace the A/C Condenser on Cadillac CTS?
A:
Before replacing the condenser, refrigerant recovery should be the initial step. The vehicle needs to be lifted and stabilized with support. Begin by removing the front air deflector retainers followed by removing front air deflector bolts then pull out the front air deflector . Start by taking out the condenser lower mounting bolts and then follow with the condenser upper bracket bolts. To replace the condenser first remove the discharge line bolt and disconnect the discharge line from the condenser. Dispose of the O-ring before continuing with the replacement process. Remove the condenser tube bolt to disconnect the tube from the condenser before discarding both its O-ring components. When replacing the condenser you must directly add PAG oil according to specifications before installing the new condenser. Before joining the condenser tube to the condenser, install the new condenser and also install a new O-ring to the condenser tube. Tighten the condenser tube bolt to 9 N.m after installing it (80 lb in torque specification). Position a fresh O-ring onto the discharge line then attach the discharge line to the condenser before adding the discharge line bolt and tightening it to 9 N.m (80 lb in). You should first install the condenser lower mounting bolts at 5.4 N.m (48 lb in) torque then move to the upper bracket bolts at 5.4 N.m (48 lb in). Secure the front air deflector to the vehicle by tightening the front air deflector bolts along with the retainers . Install the power steering cooler mounting bolts then lower the vehicle before evacuating and charging the A/C system. Perform leak testing on component fittings through the use of the Halogen Leak Detector (J 39400-A).
