How to replace the A/C Condenser on Chevrolet Corvette?

Replacement of the air conditioning condenser starts with refrigerant recovery from the a/c system. After removing the upper radiator support you should disconnect the a/c compressor hose assembly from the A/C Condenser fitting by removing the fitting bolt while using either caps or tape to prevent contaminants. First elevate the vehicle and disconnect the front evaporator inlet line by removing its bolt while discarding the seal washer and capping or taping the line. To access installation you need to remove lh and rh radiator air baffle upper retainer pins and tilt the air baffle forward with care. The A/C Condenser needs to be lifted into position so its tabs can disengage from radiator slots before vehicle removal. For a new condenser installation add pag oil following the specified quantity and then set the condenser in place before lowering the condenser to let its tabs fit into the radiator slots correctly. Before connecting the front evaporator inlet line to the A/C Condenser it is necessary to remove caps or tape and install a new seal washer before tightening the bolt to 16 nm (12 lb ft). The a/c compressor hose assembly requires removal of its cap or tape before installing the new seal washer and attaching the hose to the A/C Condenser with a tightened bolt to reach 16 nm (12 lb ft). The installation of upper radiator support should follow system evacuation and recharge and then conduct a/c fitting leak tests with j 39400-a - halogen leak detector.

OEM Chevrolet Corvette A/C Condenser

Air Conditioning Condenser

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

8 A/C Condensers found

View related parts
Chevrolet Corvette Condenser Part Number: 23237860
$178.47 MSRP: $305.63
You Save: $127.16 (42%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser, A/C Condenser
- Replaces: 20979403, 84524663
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2014-2019 Chevrolet Corvette | Grand Sport, Stingray, Z06, ZR1 | 8 Cyl 6.2 L GAS
View related parts
Chevrolet Corvette Condenser Part Number: 10442892
$239.65 MSRP: $410.04
You Save: $170.39 (42%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Condenser, A/C; A/C Condenser; Condenser A/C; Condenser, A/C Condenser
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2005-2013 Chevrolet Corvette | 427, 427 Limited Edition Z06, Base, Grand Sport, Z06, Z06 Carbon, ZR1 | 8 Cyl 6.0 L GAS, 8 Cyl 6.2 L GAS, 8 Cyl 7.0 L GAS
View related parts
Chevrolet Corvette Condenser, Passenger Side Part Number: 85601834
$127.18 MSRP: $190.10
You Save: $62.92 (34%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Condenser Assembly-A/C (Right-Hand Proc); Condenser, A/C Condenser
- Position: Passenger Side
- Replaces: 85106898, 84752395
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2020-2024 Chevrolet Corvette | E-Ray, Stingray, Z06 | 8 Cyl 5.5 L GAS, 8 Cyl 6.2 L FULL HYBRID EV-GAS (FHEV), 8 Cyl 6.2 L GAS
View related parts
Chevrolet Corvette Condenser, Driver Side Part Number: 85601833
$111.01 MSRP: $190.10
You Save: $79.09 (42%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Condenser Assembly-A/C; Condenser, A/C Condenser
- Position: Driver Side
- Replaces: 84752393, 85106897
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2020-2024 Chevrolet Corvette | E-Ray, Stingray, Z06 | 8 Cyl 5.5 L GAS, 8 Cyl 6.2 L FULL HYBRID EV-GAS (FHEV), 8 Cyl 6.2 L GAS
View related parts
Chevrolet Corvette Condenser Part Number: 52463706
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser, A/C Condenser
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1994-1996 Chevrolet Corvette | Base, Collector's Edition, Grand Sport, Indianapolis 500 Pace Car, ZR-1 | 8 Cyl 5.7 L GAS
View related parts
Chevrolet Corvette Condenser Part Number: 52456459
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser, A/C Condenser
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1990-1993 Chevrolet Corvette | 40th Anniversary Edition, Base, ZR-1 | 8 Cyl 5.7 L GAS
View related parts
Chevrolet Corvette Condenser Part Number: 3096179
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser, A/C Condenser
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1988 Chevrolet Corvette | 35th Anniversary Edition, Base | 8 Cyl 5.7 L GAS
View related parts
Chevrolet Corvette Condenser Part Number: 3056639
Product Specifications
- Other Name: Condenser Assembly-A/C; A/C Condenser; Condenser, A/C Condenser
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1989, 1984-1987 Chevrolet Corvette | Base, Indianapolis 500 Pace Car | 8 Cyl 5.7 L GAS

Chevrolet Corvette A/C Condenser

Want to cut long-term maintenance and repair costs? Choose OEM A/C Condenser. Those parts deliver top durability you can trust. On our site, you'll find a huge catalog of genuine Chevrolet Corvette parts. Prices are unbeatable, so you can keep more in your pocket. Every OEM Chevrolet Corvette A/C Condenser includes a manufacturer's warranty. You can also get an easy return policy that keeps buying risk free. Fast delivery, get your car on the road quickly. It's simple to search, compare, and order. Stop guessing about quality or fit. Order today and save with parts that last.

The A/C Condenser found on Chevrolet Corvette is necessary heat exchanger equipment, which performs the process of cooling down the gaseous refrigerant and the subsequent transition of the liquid form to the accumulator. Normally situated ahead of the radiator, it is a network of tubes helping to cool the setup generally known as the core. Different Corvette models could have had different styles of A/C Condenser due to developments of new designs and high efficiency over the years. Although to specific types, the development of the A/C Condenser in these vehicles might have added features such as; changes in material type, quality and methods of construction to increase effectiveness and durability of the vehicle part. In summary, the A/C Condenser is paramount in regulating the cabin comfort contributing to efficient refrigerant control.

Chevrolet Corvette A/C Condenser Parts Questions & Experts Answers

Condenser
10442892
Q: How to replace the A/C Condenser on Chevrolet Corvette?
A:
Replacement of the air conditioning condenser starts with refrigerant recovery from the a/c system. After removing the upper radiator support you should disconnect the a/c compressor hose assembly from the A/C Condenser fitting by removing the fitting bolt while using either caps or tape to prevent contaminants. First elevate the vehicle and disconnect the front evaporator inlet line by removing its bolt while discarding the seal washer and capping or taping the line. To access installation you need to remove lh and rh radiator air baffle upper retainer pins and tilt the air baffle forward with care. The A/C Condenser needs to be lifted into position so its tabs can disengage from radiator slots before vehicle removal. For a new condenser installation add pag oil following the specified quantity and then set the condenser in place before lowering the condenser to let its tabs fit into the radiator slots correctly. Before connecting the front evaporator inlet line to the A/C Condenser it is necessary to remove caps or tape and install a new seal washer before tightening the bolt to 16 nm (12 lb ft). The a/c compressor hose assembly requires removal of its cap or tape before installing the new seal washer and attaching the hose to the A/C Condenser with a tightened bolt to reach 16 nm (12 lb ft). The installation of upper radiator support should follow system evacuation and recharge and then conduct a/c fitting leak tests with j 39400-a - halogen leak detector.
