How to install the A/C Accumulator (ACDelco P/N 151697) on Chevrolet Corvette?

The A/C Accumulator (ACDelco P/N 151697) requires installation with the recovery of refrigerant from your A/C system through the Halogen Leak Detector (J 39400-A). Before cutting the plastic insulation you must measure 420 mm (16.5 in) starting from the condenser end of the front evaporator tube. Stand beside a tubing cutter to cut the tube and after use, mark and cut it at 400 mm (15.7 in) and 450 mm (17.7 in) while keeping metal shavings out of the tube. Removing all burrs from cut ends you need to extract O-rings from the A/C accumulator. The evaporator tube receives the first flare nut along with the first ferrule with the tapered end pointing toward the flare nut, followed by installation of the A/C accumulator to the evaporator tube where the arrow should be facing the evaporator unit and must be fully seated. The flap nut requires tightening force of 15 N.m (11 lb ft). The A/C accumulator should next be removed from the second evaporator tube half before loosening its flare nuts. Apply lubrication to each end of the evaporator tube where O-rings will be installed and place the accumulator back onto its position by fully seating it before tightening flare nuts to 15 N.m (11 lb ft). After installing the front evaporator tube perform an A/C system evacuation and recharge before testing the fittings through Halogen Leak Detector (J 39400-A).

OEM Chevrolet Corvette A/C Accumulator

Accumulator

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

7 A/C Accumulators found

View related parts
Chevrolet Corvette Dehydrator Part Number: 2724802
$24.37 MSRP: $45.48
You Save: $21.11 (47%)
ADD TO CART
Product Specifications
- Other Name: Accumulator Dehydrator; Drier Desiccant Element; A/C Receiver Drier; A/C Accumulator; Drier; Accumulator; Accumulator, A/C Refrigerant
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1988-1992 Chevrolet Corvette | 35th Anniversary Edition, Base, ZR-1 | 8 Cyl 5.7 L GAS
View related parts
Chevrolet Corvette Drier Part Number: 1132765
$28.33 MSRP: $51.28
You Save: $22.95 (45%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Accumulator Assembly A/C; Drier Desiccant Element; A/C Receiver Drier; A/C Accumulator; Accumulator; Accumulator, A/C Refrigerant
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1997-2004 Chevrolet Corvette | 50th Anniversary Edition, 50th Anniversary Edition Pace Car, Base, Indianapolis 500 Pace Car, Z06 | 8 Cyl 5.7 L GAS
View related parts
Chevrolet Corvette Dehydrator Part Number: 13277638
$34.95 MSRP: $65.65
You Save: $30.70 (47%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Receiver & Dehydrato, Air Conditioner Refrigerant; Drier Desiccant Element; A/C Receiver Drier; A/C Accumulator; Drier; Receiver & Dehydrato, A/C Refrigerant
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2014-2019 Chevrolet Corvette | Grand Sport, Stingray, Z06, ZR1 | 8 Cyl 6.2 L GAS
View related parts
Chevrolet Corvette Drier Part Number: 19188505
$33.17 MSRP: $59.24
You Save: $26.07 (45%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Accumulator, Air Conditioner Refrigerant; Drier Desiccant Element; A/C Receiver Drier; A/C Accumulator; Accumulator
- Replaces: 2724830, 02724830
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1994-1996 Chevrolet Corvette | Base, Collector's Edition, Grand Sport, Indianapolis 500 Pace Car, ZR-1 | 8 Cyl 5.7 L GAS
View related parts
Chevrolet Corvette Dehydrator Part Number: 84789220
$15.93 MSRP: $28.44
You Save: $12.51 (44%)
ADD TO CART
Product Specifications
- Other Name: Receiver & Dehydrato, Air Conditioner Refrigerant; Drier Desiccant Element; A/C Receiver Drier; A/C Accumulator; Drier; Receiver & Dehydrato, A/C Refrigerant
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2020-2024 Chevrolet Corvette | E-Ray, Stingray, Z06 | 8 Cyl 5.5 L GAS, 8 Cyl 6.2 L FULL HYBRID EV-GAS (FHEV), 8 Cyl 6.2 L GAS
View related parts
Chevrolet Corvette Dehydrator Part Number: 2724809
Product Specifications
- Other Name: Accumulator; Drier Desiccant Element; A/C Receiver Drier; A/C Accumulator; Drier; Accumulator, A/C Refrigerant
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1984-1987 Chevrolet Corvette | Base, Indianapolis 500 Pace Car | 8 Cyl 5.7 L GAS
View related parts
Chevrolet Corvette Drier Part Number: 2724681
Product Specifications
- Other Name: Accumulator, A/C; Drier Desiccant Element; A/C Receiver Drier; A/C Accumulator; Accumulator; Accumulator, A/C Refrigerant
- Replaces: 2724835
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 1993 Chevrolet Corvette | 40th Anniversary Edition, Base, ZR-1 | 8 Cyl 5.7 L GAS

Chevrolet Corvette A/C Accumulator

Want to cut long-term maintenance and repair costs? Choose OEM A/C Accumulator. Those parts deliver top durability you can trust. On our site, you'll find a huge catalog of genuine Chevrolet Corvette parts. Prices are unbeatable, so you can keep more in your pocket. Every OEM Chevrolet Corvette A/C Accumulator includes a manufacturer's warranty. You can also get an easy return policy that keeps buying risk free. Fast delivery, get your car on the road quickly. It's simple to search, compare, and order. Stop guessing about quality or fit. Order today and save with parts that last.

A/C Accumulator in Chevrolet Corvette is an important part of vehicle's cooling system which enhances the efficiency of the cars cooling system. This kind of component is this cylinder-shaped and it is usually located between the evaporator and the compressor where it acts as a receiver-dryer to eliminate moisture, oil, and debris. Thus, filtering these contaminants, the A/C Accumulator protects the system from damages and maintains high efficiency. As can be seen from the above Corvette air conditioning images, over the years different styles of A/C Accumulators have been integrated into Corvettes to improve on the air conditioning systems. While specific differences between these types are not detailed, the primary function remains consistent: to protect the cooling system from other materials which are not wanted in the process. This necessary component is crucial to keeping the Corvette's A/C operating in the long term and without failure.

Chevrolet Corvette A/C Accumulator Parts Questions & Experts Answers

Drier
1132765
Q: How to install the A/C Accumulator (ACDelco P/N 151697) on Chevrolet Corvette?
A:
The A/C Accumulator (ACDelco P/N 151697) requires installation with the recovery of refrigerant from your A/C system through the Halogen Leak Detector (J 39400-A). Before cutting the plastic insulation you must measure 420 mm (16.5 in) starting from the condenser end of the front evaporator tube. Stand beside a tubing cutter to cut the tube and after use, mark and cut it at 400 mm (15.7 in) and 450 mm (17.7 in) while keeping metal shavings out of the tube. Removing all burrs from cut ends you need to extract O-rings from the A/C accumulator. The evaporator tube receives the first flare nut along with the first ferrule with the tapered end pointing toward the flare nut, followed by installation of the A/C accumulator to the evaporator tube where the arrow should be facing the evaporator unit and must be fully seated. The flap nut requires tightening force of 15 N.m (11 lb ft). The A/C accumulator should next be removed from the second evaporator tube half before loosening its flare nuts. Apply lubrication to each end of the evaporator tube where O-rings will be installed and place the accumulator back onto its position by fully seating it before tightening flare nuts to 15 N.m (11 lb ft). After installing the front evaporator tube perform an A/C system evacuation and recharge before testing the fittings through Halogen Leak Detector (J 39400-A).
