GM 23197714
Evaporator Core

2003-2024 GM

Customer Questions & Expert Answers (15)
GM 23197714 Evaporator Core
  • Part Description
    Evaporator Assembly-A/C; A/C Evaporator Core Repair Kit; A/C Evaporator Core; A/C Evaporator
  • Replaces
    89019018, 52494775
  • Manufacturer
    General Motors
Make sure this part fits
$365.20 MSRP: $750.48
You Save: $385.28 (52%)
Ships in 1-2 Business Days
1
ADD TO CART
  • Vehicle Fitment

    Year Make Model Trim Engine
    2003-2014 Chevrolet Express 1500Base, LS, LT6 Cyl 4.3 L GAS, 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS
    2003-2024 Chevrolet Express 2500Base, LS, LT4 Cyl 2.8 L DIESEL, 6 Cyl 4.3 L FLEX, 6 Cyl 4.3 L GAS, 8 Cyl 4.8 L FLEX, 8 Cyl 4.8 L GAS, 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L CNG, 8 Cyl 6.0 L FLEX, 8 Cyl 6.0 L GAS, 8 Cyl 6.6 L DIESEL, 8 Cyl 6.6 L GAS
    2003-2024 Chevrolet Express 3500Base, LS, LT4 Cyl 2.8 L DIESEL, 6 Cyl 4.3 L FLEX, 6 Cyl 4.3 L GAS, 8 Cyl 4.8 L FLEX, 8 Cyl 4.8 L GAS, 8 Cyl 6.0 L CNG, 8 Cyl 6.0 L FLEX, 8 Cyl 6.0 L GAS, 8 Cyl 6.6 L DIESEL, 8 Cyl 6.6 L GAS
    2003-2014 GMC Savana 1500Base, LS, LT, SLE6 Cyl 4.3 L GAS, 8 Cyl 5.3 L FLEX, 8 Cyl 5.3 L GAS
    2003-2024 GMC Savana 2500Base, LS, LT, SLE4 Cyl 2.8 L DIESEL, 6 Cyl 4.3 L FLEX, 6 Cyl 4.3 L GAS, 8 Cyl 4.8 L FLEX, 8 Cyl 4.8 L GAS, 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L CNG, 8 Cyl 6.0 L FLEX, 8 Cyl 6.0 L GAS, 8 Cyl 6.6 L DIESEL, 8 Cyl 6.6 L GAS
    2003-2024 GMC Savana 3500Base, LS, LT, SLE4 Cyl 2.8 L DIESEL, 6 Cyl 4.3 L FLEX, 6 Cyl 4.3 L GAS, 8 Cyl 4.8 L FLEX, 8 Cyl 4.8 L GAS, 8 Cyl 6.0 L CNG, 8 Cyl 6.0 L FLEX, 8 Cyl 6.0 L GAS, 8 Cyl 6.6 L DIESEL, 8 Cyl 6.6 L GAS
    Warning: California's Proposition 65
  • Customer Questions & Expert Answers

    Q:
    Can you help me check if this 23197714 is the right part for my car? Posted by ChevyPartsGiant Specialist
    A:
    Please Select Your Vehicle model to see if part number 23197714 is suitable before ordering.
    Posted by ChevyPartsGiant Specialist
    Q:
    What is the final step after reinstalling the auxiliary HVAC module for the 2008 Chevrolet Express 3500? Posted by Customer
    A:
    Conduct a leak test on the fittings using the Halogen Leak Detector (J 39400-A).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Evaporator
    Q:
    What is the next step after removing the accumulator for the 2006 Chevrolet Express 1500? Posted by Customer
    A:
    Proceed to remove the blower module assembly screws and the blower module assembly.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Evaporator
    Q:
    What should be added if replacing the evaporator core for the 2008 Chevrolet Express 2500? Posted by Customer
    A:
    Add the specified amount of PAG oil directly into the evaporator.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Evaporator
    Q:
    What is the next step after separating the lower case halves for the 2010 Chevrolet Express 2500? Posted by Customer
    A:
    Remove the screws from the auxiliary HVAC module and separate the case halves.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Evaporator
    Q:
    What is the next step after removing the accumulator for the 2007 Chevrolet Express 2500? Posted by Customer
    A:
    Proceed to remove the blower module assembly screws and the blower module assembly, followed by the evaporator core from the evaporator and blower module assembly.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Evaporator
    Q:
    What should be removed after recovering the refrigerant for the 2009 Chevrolet Express 3500? Posted by Customer
    A:
    Remove the coolant recovery reservoir.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Evaporator
    Q:
    What should be reconnected after installing the tubes for the 2003 Chevrolet Express 3500? Posted by Customer
    A:
    Reconnect the low pressure sensor electrical connector, the blower motor assembly electrical connector, and the blower motor resistor assembly electrical connector.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Evaporator
    Q:
    What is the first step to replace the auxiliary evaporator core for the 2003 GMC Savana 2500? Posted by Customer
    A:
    Remove the auxiliary HVAC module by taking out the screws and separating the case halves.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Evaporator
    Q:
    What should be done after separating the case halves for the 2007 GMC Savana 2500? Posted by Customer
    A:
    Take out the evaporator core seal and remove the evaporator core from the auxiliary HVAC module, inspecting the gaskets and seals for any damage, and replacing them as necessary.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Evaporator
    Q:
    What should be done after removing the auxiliary HVAC module for the 2009 GMC Savana 2500? Posted by Customer
    A:
    Take out the screws from the lower HVAC case and separate the lower case halves.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Evaporator
    Q:
    What should be done after removing the accumulator for the 2010 GMC Savana 1500? Posted by Customer
    A:
    Unscrew and remove the blower module assembly, followed by the evaporator core from the evaporator and blower module assembly.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Evaporator
    Q:
    How should the case halves be reassembled for the 2005 GMC Savana 2500? Posted by Customer
    A:
    Reassemble the case halves, ensuring to tighten the auxiliary HVAC module screws to 2 N.m (16 lb in).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Evaporator
    Q:
    What is the next step after inspecting the gaskets and seals for the 2006 GMC Savana 3500? Posted by Customer
    A:
    Add refrigerant to the evaporator.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Evaporator
    Q:
    What is the next step after disconnecting the electrical connectors for the 2005 GMC Savana 3500? Posted by Customer
    A:
    Remove the retaining nut from the evaporator inlet tube, followed by the evaporator inlet tube retaining screw, and then take out the evaporator inlet tube and O-ring seal.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Evaporator
    If you have any questions about this product, please don't hesitate to ask us. We will be happy to help you!

OEM GM Evaporator Core 23197714 Designed for Proper Fit and Performance

Original OEM GM parts deliver superior quality and meet all performance standards needed for optimal automotive operation. The authentic part identified by 23197714 Evaporator Core is available in the market under the name GM Evaporator. This genuine product has a full warranty coverage from the manufacturer available at all authorized GM dealers throughout the United States. This part 23197714 Evaporator Core fits certain Chevrolet Express 1500, Express 2500, Express 3500 models, as well as GMC Savana 2500, Savana 3500, Savana 1500 models.
The original GM component designated by manufacturer part number 23197714 maintains top performance when functioning as the Evaporator Assembly-A/C; A/C Evaporator Core Repair Kit; A/C Evaporator Core; A/C Evaporator unit. The component 23197714 is constructed from durable material and its dimensions span 21.4 x 17.9 x 13.1 inches while weighing 4.40 Pounds. The Direct Replacement component is ready in New condition to ensure full compatibility with your vehicle system. This component receives the designation of Evaporator, A/C Evaporator; Evaporator. The part 23197714 has available replacement options 89019018, 52494775. GM manufacturer provides a warranty that ensures reliable operation of this product. The Shipping Policy and Return Policy pages outline complete details regarding shipping procedures and return processes.
