OEM Cadillac XLR Ride Height Sensor

Cadillac XLR Ride Height Sensor Parts and Q&A

• Position Sensor
  89047643
  Q: How to replace the front Ride Height Sensor on Cadillac XLR?

  A:

  The first step to replace the Electronic Suspension Front Position Sensor requires vehicle users to turn OFF the ignition switch combined with safely raising the vehicle on a suitable stand. Starting with tire and wheel removal you should disconnect the electronic suspension control (ESC) position sensor harness connector. The first task requires removal of the position sensor link from the control arm link stud with subsequent disassembly of the sensor mounting bolts before pulling out the position sensor from the vehicle. Return the position sensor to its vehicle position during installation while installing bolts and tightening them to 3 N.m (26 lb in). Attach the position sensor link to the control arm link stud before connecting the ESC position sensor harness connector and reattaching the tire-wheel assembly and then lowering the vehicle.
• Position Sensor
  89047645
  Q: How to Service and Repair the Ride Height Sensor on Cadillac XLR?

  A:

  The first step to replace the Electronic Suspension Front Position Sensor requires users to turn OFF the ignition switch while using a suitable safety stand to lift the vehicle. Start by disconnecting the electronic suspension control (ESC) position sensor harness connector while the tire along with wheel assembly is removed from the vehicle. The position sensor link needs removing from the control arm link stud before the position sensor mounting bolts and finally extracting the position sensor from the vehicle. Install the new position sensor throughout the vehicle process while keeping in mind all fastener caution measures. Position sensor link mounting bolts should be tightened to 3 Nm (26 lb in) before installing the position sensor link onto the control arm link stud followed by reconnecting the ESC position sensor harness connector. After installation of the tire and wheel assembly users must lower their vehicle.
