Temperature Sensor, Driver Side

Before you replace the Ambient Air Temperature Sensor, remove the upper air deflector. Then, pull the retaining tabs to pull out the ambient air temperature sensor and remove the electrical connector from it. For installation connect the electrical connector to the ambient air temperature sensor, line the retaining tabs up on the bottom side of the sensor hole and push up to install the sensor into the vehicle. Finally, re-instate the upper air deflector.

Start by taking out the radio when you want to change the upper left Air Temperature Sensor. Then, rotate the upper left Air Temperature Sensor counter-clockwise to take it out of the center air duct and disconnect it from the heater outlet cover. Take off the electrical plug from the sensor. Put the upper left Air Temperature Sensor back into the center air duct and rotate it clockwise to lock it into place on the heater outlet cover. Connect the electrical connector to the sensor as the last step and install the radio.

In order to replace the lower left air temperature sensor, you have to extract the left closeout panel. Then remove the lower left air temperature sensor from the heater outlet cover with using counter-clockwise rotation to release it. Unplug the electrical connector that is attached to the sensor. To install, set the lower left air temperature sensor to the heater outlet cover that must be rotated clockwise to lock. This will be followed by reattaching the electrical connector to the sensor and re-attaching the left closeout panel.

For replacing the inside air temperature senor assembly, you begin by removing the upper piece of the left center piece of the trim pillar and make sure the driver seat reclines rearward for easier access. After that, take off the electrical connector and remove the retaining clips on the B pillar before removing the inside air temperature sensor assembly. For installation, plug the electrical connector to the inside air temperature sensor assembly and place it back on the B pillar. Lock up the assembly by installing the retaining clips and lastly re install the upper section of the left center trim pillar.

The first step to change the lower duct air temperature sensor involves pulling away the sensor and wiring harness assembly from the floor air outlet before removing the electrical connector from both parts. Install the new lower duct air temperature sensor after connecting its electrical connector then reinstall the complete sensor and wiring harness assembly to the floor air outlet .

It begins by disassembling the front grille for Ambient Temperature Sensor replacement. Remove the sensor from the panel assembly and disconnect the electrical connector which attaches to the sensor. Installation starts by placing the sensor onto the panel assembly before connecting the electrical connector to the sensor. After completing the installation of the sensor on the panel assembly, reinstall the front grille.

To replace the upper left air temperature sensor , first take out this part from the air distributor duct and disengage the electrical connector from that sensor. For the installation, mount the upper left air temperature sensor back to the air distributor duct and reattach the electrical connector to the sensor.

Begin the inside air temperature sensor overhead replacement by taking off the left windshield garnish molding followed by left center pillar assist handle while also stripping away the left center pillar garnish molding. To access the inside air temperature sensor you first need to remove the left sunshade and its retaining screws from the headliner while gently pulling down the headliner. Pull out the inside air temperature sensor from the headliner after disconnecting its electrical connector. Attach and wire the electrical connector to the new inside air temperature sensor once it is properly placed in the headliner. After headliner screw installation replace the left sunshade followed by the left center pillar garnish molding and left center assist handle before final installation of the left windshield garnish molding.

To remove the inner air temperature sensor assembly, recline the driver seat back in order to get access to the left center trim pillar. Retain in a location where a tunnel meets the floor by removing the upper part of the left center trim pillar, and disconnect the electrical connector. Then, take away the retaining clips from the B pillar and extract the inside air temperature sensor assembly from the B pillar. For installation, connect the electrical connector on the inside air temperature sensor assembly to it and place it back to the B pillar. Secure from the assembly by fixing the retaining clips and reinstall the top part of the left center trim pillar.

To replace the Ambient Temperature Sensor, start with removal of grille first. Next remove the Ambient Temperature Sensor from head lamp assembly followed by the one from the panel assembly. Disconnect the electrical connector coming from the Ambient Temperature Sensor. For installation, start by returning the headlamp assembly Ambient Temperature Sensor back into the headlamp assembly and re-joining the electrical connector. And finally, replace the grille.

The procedure for sensor replacement at the upper right starts by taking out the radio system first. The procedure starts with disconnecting connector from air temperature sensor-upper right and following with sensor removal by turning it clockwise while pulling it out. Follow these steps for replacement: first install the new air temperature sensor-upper right then connect its electrical connector and finally restore the radio.

You should start the replacement by taking out the air inlet grille. Following this, disconnect the electrical connector from the ambient air temperature sensor and remove the tabs retaining the sensor to the radiator support bracket. Take out the sensor from the radiator support bracket. Install the sensor onto the radiator support bracket with the retaining tabs secured. Connect the electrical connector to the ambient air temperature sensor and then put the air inlet grille back into place.

Disconnect the electrical connector from the ambient air temperature sensor and release the tabs on the sensor to remove it from the front fascia.

Reinstall the right closeout panel.

Remove the sensor from the cover and disconnect its electrical connector.

First, remove the radio.

Install the new air temperature sensor-lower right.

Turn it clockwise and pull it out.

First, remove the radio.

Connect the electrical connector to the upper air temperature sensor.

Connect the electrical connector to the ambient air temperature sensor.

Disconnect the electrical connector from the ambient air temperature sensor.

Remove the right side C-Pillar Trim Panel.

Position the new lower left air temperature sensor onto the HVAC module.

Position the new lower left air temperature sensor onto the HVAC module.

The electrical connector.

Connect the electrical connector to the ambient air temperature sensor.

Remove the left sunshade.

First, remove the I/P assembly.

Remove the right side C-pillar trim panel.

Disconnect the electrical connector from the air temperature sensor-lower left.

Install the upper air temperature sensor to the air duct.

Begin by removing the passenger side closeout panel and the IP lower closeout panel.

Remove the right side C-Pillar Trim Panel.

Install the air temperature sensor-lower left.

Take out the sensor from the panel assembly and disconnect the electrical connector from the sensor.

Attach the upper air temperature sensor to the air duct.

Install the air temperature sensor-lower right and connect the electrical connector to it.

After removing the panels, disconnect the electrical connector from the air temperature sensor-lower right.

Remove the radio and the HVAC control module.

Remove the radio and the HVAC control module.

Follow it by attaching the inside air temperature sensor and sensor grille.

Connect the electrical connector to the sensor.
