Make sure this part fits

GM 19129781
Lower Hose

2004-2009 GM

Customer Questions & Expert Answers (11)
GM 19129781 Lower Hose
GM 19129781 Lower Hose
  • Part Description
    Hose, Transmission Oil Cooler
  • Position
    Lower
  • Replaces
    89022495
  • Manufacturer
    General Motors
  • Manufacturer's Notes
    This part is discontinued.
Make sure this part fits
  • Vehicle Fitment

    Year Make Model Trim Engine
    2009, 2004-2006 Cadillac SRXBase6 Cyl 3.6 L GAS
    2005-2007 Cadillac STSBase6 Cyl 3.6 L GAS
    Warning: California's Proposition 65
  • Customer Questions & Expert Answers

    Q:
    Is this 19129781 designed for my car? Posted by ChevyPartsGiant Specialist
    A:
    Please Select Your Vehicle model to see if part number 19129781 is suitable before ordering.
    Posted by ChevyPartsGiant Specialist
    Q:
    How do you disconnect the transmission oil cooler lines for the 2006 Cadillac SRX? Posted by Customer
    A:
    Disconnect the lines from the TOC and the TOC line from the TOC retainer clip.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Transmission Oil Cooler Hose
    Q:
    How do you remove the TOC retainer bracket for the 2004 Cadillac SRX? Posted by Customer
    A:
    Remove the TOC retainer bracket bolt, reposition the TOC lines to access the retainer bracket rivets, and drill out the rivets to take off the retainer bracket.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Transmission Oil Cooler Hose
    Q:
    How should the external hose/pipe be attached for the 2007 Cadillac STS? Posted by Customer
    A:
    Ensure the quick connect fitting is pushed on and pulled back to confirm proper engagement.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Oil Cooler Hose
    Q:
    What is the next step after connecting the rear TOC lines for the 2005 Cadillac SRX? Posted by Customer
    A:
    Install the rear TOC line to transmission retainer bolt, tightening it to 25 Nm (18 ft. lbs.).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Transmission Oil Cooler Hose
    Q:
    What is the next step after connecting the rear TOC lines for the 2007 Cadillac STS? Posted by Customer
    A:
    Install the rear TOC line to transmission retainer bolt, tightening it to 25 N.m (18 lb ft).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Transmission Oil Cooler Hose
    Q:
    How do you disconnect the front TOC lines from the rear TOC lines for the 2005 Cadillac STS? Posted by Customer
    A:
    Utilize the J44827 Transmission Cooler Quick Connect to disconnect the front TOC lines from the rear TOC lines, and then remove the front TOC lines.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Transmission Oil Cooler Hose
    Q:
    What is the torque specification for the TOC retainer bracket bolt for the 2009 Cadillac SRX? Posted by Customer
    A:
    Install the TOC retainer bracket bolt and tighten it to 25 Nm (18 lb ft).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Transmission Oil Cooler Hose
    Q:
    What is the next step after disconnecting the rear TOC lines for the 2006 Cadillac STS? Posted by Customer
    A:
    Remove the TOC retainer bracket bolt and reposition the TOC lines to access the retainer bracket rivets, ensuring the TOC lines are removed individually.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Transmission Oil Cooler Hose
    Q:
    What is the first step to replace the rear transmission fluid cooler pipe for the 2005 Cadillac STS? Posted by Customer
    A:
    Remove the engine oil filter and the left hand (LH) intermediate shaft bearing assembly.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Transmission Oil Cooler Hose
    Q:
    What should be reinstalled after connecting the TOC lines for the 2006 Cadillac STS? Posted by Customer
    A:
    Reinstall the LH front splash shield and its retainers, followed by the LH front wheel.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Transmission Oil Cooler Hose
    If you have any questions about this product, please don't hesitate to ask us. We will be happy to help you!

OEM GM Lower Hose 19129781 Designed for Proper Fit and Performance

Original OEM GM parts deliver superior quality and meet all performance standards needed for optimal automotive operation. The authentic part identified by 19129781 Lower Hose is available in the market under the name GM Cooling Hose, Oil Cooler Hose, Automatic Transmission Oil Cooler Line, Transmission Oil Cooler Hose. This genuine product has a full warranty coverage from the manufacturer available at all authorized GM dealers throughout the United States. This part 19129781 Lower Hose fits certain Cadillac SRX, STS models.
The original GM component designated by manufacturer part number 19129781 maintains top performance when functioning as the Hose, Transmission Oil Cooler unit at its Lower. The component 19129781 is constructed from durable material and its dimensions span 5.1 x 37.8 x 13.1 inches while weighing 1.30 Pounds. The Direct Replacement component is ready in New condition to ensure full compatibility with your vehicle system. The part 19129781 has available replacement options 89022495. GM manufacturer provides a warranty that ensures reliable operation of this product. The Shipping Policy and Return Policy pages outline complete details regarding shipping procedures and return processes.
