OEM Cadillac Ride Height Sensor

Suspension Level Hight Sensor

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

92 Ride Height Sensors found

View related parts
Cadillac Rear Sensor, Driver Side
Part Number: 15128648
$175.98 MSRP: $315.66
You Save: $139.68 (45%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor, Air Suspension Leveling Or Level Control; Suspension Ride Height Sensor; Ride Height Sensor
- Position: Driver Side
Fits the following Cadillac Models:
- Escalade | 2004-2010 | Base, Hybrid, Hybrid Platinum, Platinum | 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L FULL HYBRID EV-FLEX (FHEV), 8 Cyl 6.0 L FULL HYBRID EV-GAS (FHEV), 8 Cyl 6.0 L GAS, 8 Cyl 6.2 L FLEX, 8 Cyl 6.2 L GAS
- Escalade ESV | 2004-2010 | Base, Platinum | 8 Cyl 6.0 L GAS, 8 Cyl 6.2 L FLEX, 8 Cyl 6.2 L GAS
- Escalade EXT | 2007-2011 | Base, Luxury, Premium | 8 Cyl 6.2 L FLEX, 8 Cyl 6.2 L GAS
View More
View related parts
Cadillac Rear Sensor, Driver Side
Part Number: 84365776
$40.34 MSRP: $72.05
You Save: $31.71 (45%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor Assembly-Rear Suspension Auto Forward Lighting Leveling; Ride Height Sensor; Height Sensor; Sensor, Air Suspension Leveling Or Level Control
- Position: Rear Driver Side
- Replaces: 23404136
Fits the following Cadillac Models:
- XT5 | 2017-2023 | Base, Livery, Luxury, Platinum, Premium Luxury, Sport | 4 Cyl 2.0 L GAS, 6 Cyl 3.6 L GAS
- XT6 | 2020 | Premium Luxury, Sport | 6 Cyl 3.6 L GAS
View related parts
Cadillac Level Sensor, Passenger Side
Part Number: 84460152
$57.67 MSRP: $102.99
You Save: $45.32 (44%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor, Air Suspension Leveling Or Level Control; Ride Height Sensor
- Position: Passenger Side
Fits the following Cadillac Models:
- XT4 | 2024 | Luxury, Premium Luxury, Sport | 4 Cyl 2.0 L GAS
View related parts
Cadillac Position Sensor, Rear Passenger Side
Part Number: 84364924
$34.92 MSRP: $62.37
You Save: $27.45 (45%)
ADD TO CART
Product Specifications
- Other Name: Sensor Assembly-Rear Suspension 2 Or 4 Corner Air Leveling; Ride Height Sensor; Rear Sensor; Sensor, Air Suspension Leveling Or Level Control
- Position: Rear Passenger Side
- Replaces: 23405525
Fits the following Cadillac Models:
- CT6 | 2016-2020 | Base, Luxury, Platinum, Plug-In, Premium Luxury, Sport, V | 4 Cyl 2.0 L GAS, 4 Cyl 2.0 L PLUG-IN HYBRID EV-GAS (PHEV), 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L GAS, 8 Cyl 4.2 L GAS
View related parts
Cadillac Front Sensor, Driver Side
Part Number: 15128630
$160.79 MSRP: $288.42
You Save: $127.63 (45%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor, Air Suspension Leveling Or Level Control; Suspension Ride Height Sensor
- Position: Driver Side
Fits the following Cadillac Models:
- Escalade | 2004-2006 | Base | 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
- Escalade ESV | 2004-2006 | Base | 8 Cyl 6.0 L GAS
View related parts
Cadillac Rear Sensor, Passenger Side
Part Number: 15128649
$182.06 MSRP: $326.56
You Save: $144.50 (45%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor, Air Suspension Leveling Or Level Control; Suspension Ride Height Sensor; Ride Height Sensor
- Position: Passenger Side
Fits the following Cadillac Models:
- Escalade | 2004-2010 | Base, Hybrid, Hybrid Platinum, Platinum | 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L FULL HYBRID EV-FLEX (FHEV), 8 Cyl 6.0 L FULL HYBRID EV-GAS (FHEV), 8 Cyl 6.0 L GAS, 8 Cyl 6.2 L FLEX, 8 Cyl 6.2 L GAS
- Escalade ESV | 2004-2010 | Base, Platinum | 8 Cyl 6.0 L GAS, 8 Cyl 6.2 L FLEX, 8 Cyl 6.2 L GAS
- Escalade EXT | 2007-2011 | Base, Luxury, Premium | 8 Cyl 6.2 L FLEX, 8 Cyl 6.2 L GAS
View More
View related parts
Cadillac Level Sensor, Rear Driver Side
Part Number: 84460153
$42.58 MSRP: $76.05
You Save: $33.47 (45%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor Assembly-Rear Suspension Auto Forward Lighting Leveling; Sensor, Air Suspension Leveling Or Level Control
- Position: Rear Driver Side
Fits the following Cadillac Models:
- XT4 | 2024 | Luxury, Premium Luxury, Sport | 4 Cyl 2.0 L GAS
View related parts
Cadillac Level Sensor, Rear Driver Side
Part Number: 84391114
$35.53 MSRP: $63.43
You Save: $27.90 (44%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor Assembly-Rear Suspension Auto Forward Lighting Leveling; Ride Height Sensor; Height Sensor; Sensor, Air Suspension Leveling Or Level Control
- Position: Rear Driver Side
- Replaces: 84171606
Fits the following Cadillac Models:
- XT4 | 2019-2023 | Luxury, Premium Luxury, Sport | 4 Cyl 2.0 L GAS
View related parts
Cadillac Height Sensor, Front
Part Number: 85134832
$27.61 MSRP: $49.30
You Save: $21.69 (44%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor Assembly-Front Suspension Auto Forward Lighting Positive; Sensor, Air Suspension Leveling Or Level Control
- Position: Front
- Replaced by: 85627654
Fits the following Cadillac Models:
- LYRIQ | 2023 | Luxury | BATTERY EV (EV/BEV)
View related parts
Cadillac Position Sensor, Rear Passenger Side
Part Number: 23209128
$51.78 MSRP: $92.48
You Save: $40.70 (45%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor Assembly-Rear Suspension 2 Or 4 Corner Air Leveling; Ride Height Sensor; Rear Sensor; Sensor, Air Suspension Leveling Or Level Control
- Position: Rear Passenger Side
- Replaces: 23126644, 22820297
Fits the following Cadillac Models:
- ATS | 2013-2019 | Base, Luxury, Performance, Premium, Premium Luxury, Premium Performance, V | 4 Cyl 2.0 L GAS, 4 Cyl 2.5 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
- CTS | 2014-2019 | Base, Luxury, Performance, Premium, Premium Luxury, V, Vsport, Vsport Premium, Vsport Premium Luxury | 4 Cyl 2.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS, 8 Cyl 6.2 L GAS
View related parts
Cadillac Position Sensor, Passenger Side
Part Number: 84364926
$36.44 MSRP: $65.08
You Save: $28.64 (45%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor, Air Suspension Leveling Or Level Control; Ride Height Sensor; Front Sensor
- Position: Passenger Side
- Replaces: 23405527
Fits the following Cadillac Models:
- CT6 | 2016-2020 | Base, Luxury, Platinum, Plug-In, Premium Luxury, Sport, V | 4 Cyl 2.0 L GAS, 4 Cyl 2.0 L PLUG-IN HYBRID EV-GAS (PHEV), 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L GAS, 8 Cyl 4.2 L GAS
View related parts
Cadillac Position Sensor, Rear Driver Side
Part Number: 84364925
$34.91 MSRP: $62.33
You Save: $27.42 (44%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor Assembly-Rear Suspension Auto Forward Lighting Leveling; Ride Height Sensor; Rear Sensor; Sensor, Air Suspension Leveling Or Level Control
- Position: Rear Driver Side
- Replaces: 23405526
Fits the following Cadillac Models:
- CT6 | 2016-2020 | Base, Luxury, Platinum, Plug-In, Premium Luxury, Sport, V | 4 Cyl 2.0 L GAS, 4 Cyl 2.0 L PLUG-IN HYBRID EV-GAS (PHEV), 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L GAS, 8 Cyl 4.2 L GAS
View related parts
Cadillac Position Sensor, Passenger Side
Part Number: 23126646
$51.08 MSRP: $91.20
You Save: $40.12 (44%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor, Air Suspension Leveling Or Level Control; Ride Height Sensor; Front Sensor
- Position: Passenger Side
- Replaced by: 19540714
Fits the following Cadillac Models:
- ATS | 2014-2018 | Base, Luxury, Performance, Premium, Premium Luxury, Premium Performance, V | 4 Cyl 2.0 L GAS, 4 Cyl 2.5 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS
- CTS | 2014-2019 | Base, Luxury, Performance, Premium, Premium Luxury, V, Vsport, Vsport Premium, Vsport Premium Luxury | 4 Cyl 2.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS, 8 Cyl 6.2 L GAS
View related parts
Cadillac Height Sensor, Rear
Part Number: 85134834
$31.98 MSRP: $57.10
You Save: $25.12 (44%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor Assembly-Rear Suspension Auto Forward Lighting Leveling; Sensor, Air Suspension Leveling Or Level Control
- Position: Rear
Fits the following Cadillac Models:
- LYRIQ | 2023 | Luxury | BATTERY EV (EV/BEV)
View related parts
Cadillac Position Sensor, Rear Passenger Side
Part Number: 84138218
$27.80 MSRP: $43.54
You Save: $15.74 (37%)
ADD TO CART
Product Specifications
- Other Name: Sensor Assembly-Rear Suspension 2 Or 4 Corner Air Leveling; Ride Height Sensor; Height Sensor; Sensor, Air Suspension Leveling Or Level Control
- Position: Rear Passenger Side
Fits the following Cadillac Models:
- Escalade | 2021-2023 | Luxury, Premium Luxury, Premium Luxury Platinum, Sport, Sport Platinum, V | 6 Cyl 3.0 L DIESEL, 8 Cyl 6.2 L GAS
- Escalade ESV | 2021-2023 | Luxury, Premium Luxury, Premium Luxury Platinum, Sport, Sport Platinum, V | 6 Cyl 3.0 L DIESEL, 8 Cyl 6.2 L GAS
View related parts
Cadillac Position Sensor, Front Passenger Side
Part Number: 20829005
$111.45 MSRP: $199.02
You Save: $87.57 (44%)
Product Specifications
- Other Name: Sensor Assembly-Electronic Suspension Front Position; Ride Height Sensor; Front Sensor; Sensor, Air Suspension Leveling Or Level Control
- Position: Front Passenger Side
- Replaces: 88957144
Fits the following Cadillac Models:
- CTS | 2008-2015 | Base, Luxury, Performance, Premium, V, Vsport, Vsport Premium | 4 Cyl 2.0 L GAS, 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS, 8 Cyl 6.2 L GAS
- SRX | 2004-2009 | Base | 6 Cyl 3.6 L GAS, 8 Cyl 4.6 L GAS
- STS | 2005-2011 | Base, Platinum, V | 6 Cyl 3.6 L GAS, 8 Cyl 4.4 L GAS, 8 Cyl 4.6 L GAS
View More
View related parts
Cadillac Front Sensor, Passenger Side
Part Number: 15128631
Product Specifications
- Other Name: Sensor, Air Suspension Leveling Or Level Control; Suspension Ride Height Sensor
- Position: Passenger Side
Fits the following Cadillac Models:
- Escalade | 2004-2006 | Base | 8 Cyl 5.3 L GAS, 8 Cyl 6.0 L GAS
- Escalade ESV | 2004-2006 | Base | 8 Cyl 6.0 L GAS
View related parts
Cadillac Position Sensor
Part Number: 22153656
Product Specifications
- Other Name: Sensor, Air Suspension Leveling Or Level Control; Ride Height Sensor; Height Sensor; Control Sensor; Sensor
Fits the following Cadillac Models:
- Seville | 1998-2004 | SLS, STS | 8 Cyl 4.6 L GAS
View related parts
Cadillac Rear Sensor, Driver Side
Part Number: 25863268
$103.12 MSRP: $184.13
You Save: $81.01 (44%)
Product Specifications
- Other Name: Sensor Assembly-Electronic Suspension Rear Position; Suspension Ride Height Sensor; Sensor, Air Suspension Leveling Or Level Control
- Position: Rear Driver Side
Fits the following Cadillac Models:
- CTS | 2008-2014 | Base, Luxury, Performance, Premium, V, Vsport, Vsport Premium | 4 Cyl 2.0 L GAS, 6 Cyl 3.0 L GAS, 6 Cyl 3.6 L FLEX, 6 Cyl 3.6 L GAS, 8 Cyl 6.2 L GAS
View related parts
Cadillac Front Sensor, Passenger Side
Part Number: 25767359
$195.39 MSRP: $350.49
You Save: $155.10 (45%)
Product Specifications
- Other Name: Sensor Assembly-Electronic Suspension Front Position; Suspension Ride Height Sensor; Ride Height Sensor; Sensor, Air Suspension Leveling Or Level Control
- Position: Front Passenger Side
Fits the following Cadillac Models:
- DTS | 2006-2011 | Base, Livery, Luxury, Platinum, Premium | 8 Cyl 4.6 L GAS

| Page 1 of 5 |Next >

1-20 of 92 Results

Cadillac Ride Height Sensor Parts Questions & Experts Answers

Rear Sensor
22126143
Q: How to replace the Ride Height Sensor and Bracket on Cadillac Eldorado?
A: The first step to replace the Ride Height Sensor and bracket is to lift the vehicle. The procedure to replace the Ride Height Sensor requires first removing the suspension Control Arm link and height sensor actuating arm link then removing the height sensor connector from the vehicle harness. Detach the four nuts along with the bracket which secures the height sensor. Operating fastener safety procedures is necessary before installation. Secure the height sensor bracket using four nuts that should be tightened to 3 nm (26 inch lbs.). Secure the height sensor with its bracket on the vehicle by applying two bolts and tightening them to 6 nm (54 inch lbs.). Install the suspension Control Arm while lowering the vehicle then connect the link between the height sensor actuating arm and Control Arm before adjusting the height sensor position.
Position Sensor
88957143
Q: How to replace the Rear Ride Height Sensor on Cadillac SRX?
A: The correct first step to replace Electronic Suspension Rear Position Sensors involves lifting the vehicle using proper lifting equipment. The first step involves removing both tire and wheel followed by disconnecting the ride sensor link from the ball stud adjusted on the upper control arm and the ride sensor harness connector. Twist the rear ride sensor retaining nut then apply gentle taps to the retaining stud to break its binding with the frame surface. Extract the rear ride sensor through a series of steps from the automobile. Put the new sensor into place by letting the captured stud reach the keyhole base and turning the sensor and bracket until the bracket tab inserts properly into the slot. Adjust the sensor bracket until the sensor reaches level position by letting the captured stud rise above the keyhole. Secure the rear ride height sensor retaining nut at 9 Nm (80 lb in) and then attach the ride sensor link to the control arm ball stud together with the ride sensor harness connector. Complete the procedure by placing back the tire and wheel while lowering the vehicle.
Position Sensor
89047645
Q: How to Service and Repair the Ride Height Sensor on Cadillac XLR?
A: The first step to replace the Electronic Suspension Front Position Sensor requires users to turn OFF the ignition switch while using a suitable safety stand to lift the vehicle. Start by disconnecting the electronic suspension control (ESC) position sensor harness connector while the tire along with wheel assembly is removed from the vehicle. The position sensor link needs removing from the control arm link stud before the position sensor mounting bolts and finally extracting the position sensor from the vehicle. Install the new position sensor throughout the vehicle process while keeping in mind all fastener caution measures. Position sensor link mounting bolts should be tightened to 3 Nm (26 lb in) before installing the position sensor link onto the control arm link stud followed by reconnecting the ESC position sensor harness connector. After installation of the tire and wheel assembly users must lower their vehicle.
