How to balance the engine mount, motor and transmission mount on Chevrolet HHR?

First you must lift the vehicle then put it on support before performing the balancing operation. Next proceed with dropping the vehicle after you have loosened the front transaxle mount through bolt and rear transaxle mount through bolt. Two floor jacks equipped with wood blocks should be placed under the engine and transaxle to maintain powertrain assembly suspension. You should start by creating a 1/8 inch gap between the mount and bracket using both floor jacks that are repositioned correctly. After that, tighten the transaxle mount to transaxle bolts and the engine mount to bracket bolts. The transaxle mount should be installed to transaxle bolts which require tightening to 45 n.m (33 lb ft) then proceed with engine mount bolt installation followed by a 50 n.m (37 lb ft) torque setting. Shake the powertrain whole unit from front to rear through vigorous motion then allow the assembly to settle before removing the jacks situated below the Oil Pan. The technician should lift the vehicle again before securing the rear transaxle mount through bolt to 100 n.m (74 lb ft) and finishing with the front transaxle mount through bolt at 100 n.m (74 lb ft) before putting the vehicle down.

OEM Chevrolet HHR Motor And Transmission Mount

Motor and Trans Mount

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

13 Motor And Transmission Mounts found

View related parts
Chevrolet HHR Transmission Mount
Part Number: 25973863
$91.30 MSRP: $155.42
You Save: $64.12 (42%)
ADD TO CART
Product Specifications
- Other Name: Mount, Transmission Mounting; Engine Mount Bracket; Transfer Case Mount; Motor Mount; Front Trans Mount; Mount
- Position: Front
- Replaces: 22693268
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2006-2011 Chevrolet HHR | LS, LS Panel, LT, LT Panel, SS, SS Panel | 4 Cyl 2.0 L GAS, 4 Cyl 2.2 L FLEX, 4 Cyl 2.2 L GAS, 4 Cyl 2.4 L FLEX, 4 Cyl 2.4 L GAS
View related parts
Chevrolet HHR Transmission Mount
Part Number: 25973870
$72.24 MSRP: $113.15
You Save: $40.91 (37%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Mount, Transmission Mounting; Engine Mount Bracket; Transfer Case Mount; Motor Mount; Rear Trans Mount; Mount
- Position: Rear
- Replaces: 15940092, 22731274
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2006-2011 Chevrolet HHR | LS, LS Panel, LT, LT Panel | 4 Cyl 2.2 L FLEX, 4 Cyl 2.2 L GAS, 4 Cyl 2.4 L FLEX, 4 Cyl 2.4 L GAS
View related parts
Chevrolet HHR Front Mount
Part Number: 25974059
Product Specifications
- Other Name: Mount; Engine Mount Bracket; Motor Mount; Mount, Engine Mounting
- Replaces: 15835311, 15939383, 15256691, 25827846
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2006-2011 Chevrolet HHR | LS, LS Panel, LT, LT Panel, SS, SS Panel | 4 Cyl 2.0 L GAS, 4 Cyl 2.2 L FLEX, 4 Cyl 2.2 L GAS, 4 Cyl 2.4 L FLEX, 4 Cyl 2.4 L GAS
View related parts
Chevrolet HHR Front Mount, Yellow
Part Number: 25974058
Product Specifications
- Other Name: Mount Assembly-Engine *Yellow; Engine Mount Bracket; Motor Mount; Mount; Mount, Engine Mounting
- Replaces: 15939382, 25827845, 15256690, 15835310
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2006-2011 Chevrolet HHR | LS, LS Panel, LT, LT Panel, SS, SS Panel | 4 Cyl 2.0 L GAS, 4 Cyl 2.2 L FLEX, 4 Cyl 2.2 L GAS, 4 Cyl 2.4 L FLEX, 4 Cyl 2.4 L GAS
View related parts
Chevrolet HHR Transmission Mount, Yellow, Rear
Part Number: 25973869
Product Specifications
- Other Name: Mount Assembly-Transmission Rear *Yellow; Engine Mount Bracket; Transfer Case Mount; Rear Trans Mount; Mount, Transmission Mounting
- Position: Rear
- Replaces: 15940090
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2006-2011 Chevrolet HHR | LS, LS Panel, LT, LT Panel, SS, SS Panel | 4 Cyl 2.0 L GAS, 4 Cyl 2.2 L FLEX, 4 Cyl 2.2 L GAS, 4 Cyl 2.4 L FLEX, 4 Cyl 2.4 L GAS
View related parts
Chevrolet HHR Transmission Mount, White, Front
Part Number: 20814994
Product Specifications
- Other Name: Mount Assembly-Transmission Front *White; Engine Mount Bracket; Transfer Case Mount; Front Trans Mount; Rear Trans Mount; Mount, Transmission Mounting
- Position: Front
- Replaces: 22731177, 25948444, 15945574
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2009-2010 Chevrolet HHR | SS, SS Panel | 4 Cyl 2.0 L GAS
View related parts
Chevrolet HHR Transmission Mount, Yellow
Part Number: 15835312
Product Specifications
- Other Name: Mount Assembly-Transmission *Yellow; Engine Mount Torque Strut; Transfer Case Mount; Motor Mount; Upper Trans Mount; Mount, Transmission Mounting
- Replaces: 15298137, 15877272, 22727937
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2006-2011 Chevrolet HHR | LS, LS Panel, LT, LT Panel, SS | 4 Cyl 2.0 L GAS, 4 Cyl 2.2 L FLEX, 4 Cyl 2.2 L GAS, 4 Cyl 2.4 L FLEX, 4 Cyl 2.4 L GAS
View related parts
Chevrolet HHR Transmission Mount
Part Number: 25973862
$63.69 MSRP: $99.78
You Save: $36.09 (37%)
Product Specifications
- Other Name: Mount, Transmission Mounting; Transfer Case Mount; Front Trans Mount
- Position: Front
- Replaces: 22693266
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2006-2011 Chevrolet HHR | LS, LS Panel, LT, LT Panel, SS | 4 Cyl 2.0 L GAS, 4 Cyl 2.2 L FLEX, 4 Cyl 2.2 L GAS, 4 Cyl 2.4 L FLEX, 4 Cyl 2.4 L GAS
View related parts
Chevrolet HHR Mounting Bracket
Part Number: 15854396
$81.92 MSRP: $128.33
You Save: $46.41 (37%)
Product Specifications
- Other Name: Adapter, Engine Mounting; Engine Mount Torque Strut; Engine Mount Bracket; Motor Mount; Mount Bracket; Front Mount Bracket; Adapter; Bracket, Engine Mounting
- Replaces: 22689529
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2006-2011 Chevrolet HHR | LS, LS Panel, LT, LT Panel, SS, SS Panel | 4 Cyl 2.0 L GAS, 4 Cyl 2.2 L FLEX, 4 Cyl 2.2 L GAS, 4 Cyl 2.4 L FLEX, 4 Cyl 2.4 L GAS
View related parts
Chevrolet HHR Front Mount
Part Number: 25974060
Product Specifications
- Other Name: Mount, Engine Mount Dampening; Engine Mount Bracket; Motor Mount; Mount; Mount, Engine Mounting
- Replaces: 25877466
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2008-2010 Chevrolet HHR | SS, SS Panel | 4 Cyl 2.0 L GAS
View related parts
Chevrolet HHR Rear Trans Mount, Blue
Part Number: 25892537
Product Specifications
- Other Name: Mount Assembly-Transmission Rear *Blue; Transfer Case Mount; Transmission Mount; Mount, Transmission Mounting
- Position: Rear
- Replaced by: 25998385
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2008-2010 Chevrolet HHR | SS, SS Panel | 4 Cyl 2.0 L GAS
View related parts
Chevrolet HHR Transmission Mount
Part Number: 25829028
Product Specifications
- Other Name: Mount, Transmission Mounting; Engine Mount Torque Strut; Transfer Case Mount; Motor Mount; Upper Trans Mount
- Replaces: 10359761
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2009-2010 Chevrolet HHR | SS, SS Panel | 4 Cyl 2.0 L GAS
View related parts
Chevrolet HHR Transmission Mount, Black; Blue
Part Number: 15835313
Product Specifications
- Other Name: Mount, Transmission Mounting; Engine Mount Torque Strut; Engine Mount Bracket; Transfer Case Mount; Motor Mount; Upper Trans Mount; Mount
- Warranty: This genuine part is guaranteed by GM's factory warranty.
Fits the following Vehicles:
- 2006-2011 Chevrolet HHR | LS, LS Panel, LT, LT Panel, SS, SS Panel | 4 Cyl 2.0 L GAS, 4 Cyl 2.2 L FLEX, 4 Cyl 2.2 L GAS, 4 Cyl 2.4 L FLEX, 4 Cyl 2.4 L GAS

Chevrolet HHR Motor And Transmission Mount

Our website offers an extensive catalog of genuine Chevrolet HHR Motor And Transmission Mount at unbeatable prices. Every OEM Chevrolet HHR Motor And Transmission Mount comes with a manufacturer's warranty, an easy return policy, and rapid delivery service. Don't miss out on this great opportunity!

Chevrolet HHR Motor And Transmission Mount Parts Questions & Experts Answers

Mounting Bracket
15854396
Q: How to balance the engine mount, motor and transmission mount on Chevrolet HHR?
A: First you must lift the vehicle then put it on support before performing the balancing operation. Next proceed with dropping the vehicle after you have loosened the front transaxle mount through bolt and rear transaxle mount through bolt. Two floor jacks equipped with wood blocks should be placed under the engine and transaxle to maintain powertrain assembly suspension. You should start by creating a 1/8 inch gap between the mount and bracket using both floor jacks that are repositioned correctly. After that, tighten the transaxle mount to transaxle bolts and the engine mount to bracket bolts. The transaxle mount should be installed to transaxle bolts which require tightening to 45 n.m (33 lb ft) then proceed with engine mount bolt installation followed by a 50 n.m (37 lb ft) torque setting. Shake the powertrain whole unit from front to rear through vigorous motion then allow the assembly to settle before removing the jacks situated below the Oil Pan. The technician should lift the vehicle again before securing the rear transaxle mount through bolt to 100 n.m (74 lb ft) and finishing with the front transaxle mount through bolt at 100 n.m (74 lb ft) before putting the vehicle down.
