GM 26044380
Seal Kit

The toolset required for wheel drive shaft outer joint and boot replacement includes Snap Ring Pliers J 8059 and Eared Clamp Tool J 35910 and Small Swage Tool J 41048 as well as a breaker bar and torque wrench. You need Snap Ring Pliers (J 8059), Eared Clamp Tool (J 35910), Small Swage Tool (J 41048), a breaker bar alongside a torque wrench for this repair job. Start the replacement procedure by cutting off the large boot retaining clamp from the CV joint with a side cutter before discarding it. Next, use a side cutter to disconnect the small boot retaining clamp from the halfshaft bar. The outer race of the CV joint must be separated from the boot before sliding the boot at least one inch away from the bar direction. Before removing the CV joint assembly from the bar use the Snap Ring Pliers (J 8059) to open the retaining ring's ears after wiping grease off the CV joint inner race face. Tapping the CV joint cage with a brass drift and hammer helps remove the chrome alloy balls while you keep the boot away from the bar . Use cleaning solvent to cleanse the CV joint cage with balls as well as the inner and outer race assemblies until all older grease and contaminants disappear before the elements dry. After mounting the new swage ring on the small end of the joint boot you should position it onto the halfshaft bar. First set the boot into its boot groove then fix the Small Swage Tool (J 41048) inside a vise so that the halfshaft assembly's outer end points toward the tool. Begin bolt tightening with hand pressure until they reach normal resistance before alternating each bolt's tightening 180 degrees using a ratchet wrench. Using service kit grease, apply a very thin covering to the inner and outer race ball grooves. Next, insert the inner race into the cage making sure the retaining ring side points toward the halfshaft bar. Place the cage windows in exact alignment with the outer race's lands before combining cage and inner race components within the outer race assembly. High-precision installation requires the insertion of chrome balls followed by grease packing of the CV joint while carefully molding the outboard boot. Using a Eared Clamp Tool (J 35910), breaker bar, and torque wrench crimp the large boot retaining clamp to meet a 176 Nm (130 ft. lbs.) torque specification while verifying the clamp ear gap dimensional compliance.

Quality performance of wheel drive shaft inner joint and boot replacement starts with these essential tools: the required tools include snap ring pliers (J 8059) and earless clamp tool (J 35910) and small swage tool (J 41048). Snap ring pliers (J 8059), earless clamp tool (J 35910), and small swage tool (J 41048). You should inspect the transmission sealing surface of the halfshaft for corrosion and apply 320 grit cloth cleaning if needed. Cut through the swage ring with a hand grinder so you avoid damaging the tripot housing. You will need side cutters to remove and throw away the large boot retaining clamp which secures the tripot joint. Slide the inboard boot away from the trilobal tripot bushing by separating them from one another. Start by extracting the housing from both tripot joint spider and halfshaft bar before forcibly removing the trilobal tripot bushing from inside the housing. The procedure requires snap ring pliers (J 8059) to expand the spacer rings and while you separate the spider assembly . Follow this step with the spacer ring , next is the spider assembly and after that the second spacer ring before finally removing the inboard boot . Use a wire brush to clean the halfshaft bar before checking the spider assembly for damage or wear. Replace any damaged components found during inspection. To begin assembly fit the new swage ring to the small end of the joint boot before placing it onto the halfshaft bar. Guide the joint boot's small end portion into the groove formation on the halfshaft bar. Mount small swage tool (J 41048) in a vise to position the outboard end of the halfshaft assembly inside the tool with boot neck facing the bottom die. Begin hand-tightening the bolts until they become snug then switch the order of bolt tightening by 180 degrees until both sides reach their lowest position. Slot the spider assembly with both spacer rings onto the halfshaft bar using snap ring pliers (J 8059) until they expand to full depth. Squeeze half of the grease service kit contents into the inboard boot space before distributing remaining grease into the housing. Set the trilobal tripot bushing into the housing before adding the larger new boot retaining clamp to the boot surface. Guide the housing to fit over the spider assembly so that the boot maintains its correct shape. Align all components as you latch together the boot and tripot housing before using earless clamp tool (J 35910) to crimp the boot retaining clamp at 176 nm (130 ft. Lbs.) torque levels achieved by both a breaker bar and torque wrench . Complete tightening of the clamp ear begins when you verify its dimension and proceed until achieving the required measurement.

Start by collecting these tools to replace the wheel drive shaft inner joint and boot: tool use includes snap ring pliers (J 8059) swage tool (J 41048) and seal clamp tool (J 35910). Snap ring pliers (J 8059), swage tool (J 41048), and seal clamp tool (J 35910). Use a hand grinder to disconnect the swage ring from the halfshaft bar while safeguarding the halfshaft bar's integrity. Cut the large boot retaining clamp with side cutters and pull the inboard boot off the trilobal tripot bushing before sliding it away from the joint. Use snap ring pliers (J 8059) to break the stock-ring free from its position between the halfshaft bar and housing. Place the spacer ring along with the tripot joint spider onto the halfshaft bar before removing the halfshaft bar retaining ring . Thorough cleaning procedures should include both the tripot joint spider assembly and housing to eliminate every trace of old grease and all contaminants. Examine the inboard boot and the tripot joint spider assembly and housing and trilobal tripot bushing for signs of damage or wear. When assembling replace the inboard boot with the new swage ring securely fastened to its neck followed by boot insertion on the halfshaft bar then proper positioning in the boot groove . Use swage tool j 41048 to properly align the swaged ring on the inboard boot while ensuring there are no pinch points on this boot. Position the spacer ring onto the halfshaft bar before advancing the tripot joint spider assembly towards its position. Snap ring pliers (J 8059) are used to place halfshaft bar retaining ring into the fitting of the halfshaft bar. Add grease to the housing before installing the trilobal tripot bushing at a level with the housing and clip the bigger new clamp onto the inboard boot. Apply the housing onto the tripot joint spider assembly while checking that the inboard boot maintains its proper shape. The seal clamp tool (J 35910) crimps the inboard boot with the housing and large boot retaining clamp to 174 nm (130 lbs.) while confirming the clamp ear dimensions.

Start by collecting these tools to replace the wheel drive shaft inner joint and boot: tool use includes snap ring pliers (J 8059) swage tool (J 41048) and seal clamp tool (J 35910). Snap ring pliers (J 8059), swage tool (J 41048), and seal clamp tool (J 35910). Use a hand grinder to disconnect the swage ring from the halfshaft bar while safeguarding the halfshaft bar's integrity. Cut the large boot retaining clamp with side cutters and pull the inboard boot off the trilobal tripot bushing before sliding it away from the joint. Use snap ring pliers (J 8059) to break the stock-ring free from its position between the halfshaft bar and housing. Place the spacer ring along with the tripot joint spider onto the halfshaft bar before removing the halfshaft bar retaining ring . Thorough cleaning procedures should include both the tripot joint spider assembly and housing to eliminate every trace of old grease and all contaminants. Examine the inboard boot and the tripot joint spider assembly and housing and trilobal tripot bushing for signs of damage or wear. When assembling replace the inboard boot with the new swage ring securely fastened to its neck followed by boot insertion on the halfshaft bar then proper positioning in the boot groove . Use swage tool j 41048 to properly align the swaged ring on the inboard boot while ensuring there are no pinch points on this boot. Position the spacer ring onto the halfshaft bar before advancing the tripot joint spider assembly towards its position. Snap ring pliers (J 8059) are used to place halfshaft bar retaining ring into the fitting of the halfshaft bar. Add grease to the housing before installing the trilobal tripot bushing at a level with the housing and clip the bigger new clamp onto the inboard boot. Apply the housing onto the tripot joint spider assembly while checking that the inboard boot maintains its proper shape. The seal clamp tool (J 35910) crimps the inboard boot with the housing and large boot retaining clamp to 174 nm (130 lbs.) while confirming the clamp ear dimensions.

To change the wheel drive shaft inner joint and boot, start with the searching for the following tools: the pacific international company has a range of tools that can be used for twisting meshes, metal pipes, sheet metal, and heavy-duty cables that include snap ring pliers (J 8059), earless clamp tool (J 35910) and small swage tool (J 41048). Commence with manually checking the transmission sealing surface of the halfshaft for its state of corrosion and proceed to clean it with cloth of grit number 320 if the case concerns corrosion. You should use a hand grinder to cut through the swage ring without damaging the tripot housing, remove the large boot retaining clamp from the tripot joint through use of side cutters and throw away. Carefully turn independent, the inboard boot from the trilobal tripot bushing and move it off the joint on the halfshaft bar. Take out the housing from the tripot joint spider and halfshaft bar, then take out the trilobal tripot bushing from the housing. Distribute the spacer rings and using snap ring pliers "j 8059") pulled off the spider assembly and then cleaned of the halfshaft bar with a wire brush. Check the spider assembly and if a part is damaged, replace it. The replacement swage ring should be mounted onto the small end of the joint boot and be used to slide onto the halfshaft bar. Place the small end of joint boot into the joint boot groove on the halfshaft bar. Mount mount small swage tool (J 41048) in a vise, place outboard of the end of the halfshaft assembly in the tool and position the boot neck on the bottom die. Hand-tighten the bolts and make sure no pinch points on the boot. By aligning the inboard boot and swage ring and using ratchet wrench to tighten the bolts of j41048 at an interval of 180°, one at a time. Install spacer ring and spider assembly onto halfshaft bar using snap ring pliers (J 8059) and other spacer ring in the groove at the end of halfshaft bar. Make sure that the trilobal tripot bushing is flush with the face of the housing and grease from the service kit into the inboard boot leaving the rest to service the housing. Mount the trilobal tripot bushing to the housing and attach the larger new boot retaining clamp on the boot. Push boot over the spider assembly and make sure boot sliding shows the required shape. Compensate the boot , tripot housing and large boot retaining clamp then crimp using earless clamp tool (J 35910) the boot retaining clamp at 176 dsnm (130 ft.ipping lbs) using a breaker bar and torque wrench if hat necessary. Finally, inspect the clamp ear for the gap dimension and carry on with tightening until the required gap dimension is achieved.

The following tools are necessary for inner joint and boot replacement of the Axle Shaft assembly: snap ring pliers (J8059) and earless clamp tool (J35910) and small swage tool (J41048). The necessary tools for the replacement project are snap ring pliers (J8059), earless clamp tool (J35910), and small swage tool (J41048). Check the transmission sealing surface of the halfshaft for corrosion before cleaning it with 320 grit cloth depending on need. The hand grinder should slice through the swage ring but avoid causing any damage to the tripot housing while you remove and dispose of the large boot retaining clamp. Slowly extract the inboard boot from the trilobal tripot bushing by moving it off the joint. Start by taking off the housing that contains the tripot joint spider and halfshaft bar and then detach the trilobal tripot bushing . Use snap ring pliers (J8059) to open up spacer rings and then take out the spider assembly with its attached parts which include the spacer ring , spider assembly , second spacer ring , and inboard boot . Use a wire brush to clean the halfshaft bar before checking the spider assembly for signs of wear or damage. Assemble the system only after you replace all failed components. Fit the new swage ring onto the joint boot's small end before sliding the unit on to the halfshaft bar. Install the joint boot in the halfshaft bar groove then fix in position its outboard end in the small swage tool (J41048). Check that the boot neck placement is correct before tightening the bolts with appropriate torque. Use a ratchet wrench to torque the bolts of the small swage tool (J41048) by rotating them 180 degrees at a time starting from the inboard boot and swage ring position. Use snap ring pliers (J8059) to position the spacer ring and spider assembly onto the halfshaft bar before setting the next spacer ring to achieve complete seating. Stuff the inboard boot with half of the service kit grease before you repack the housing with remaining grease. Insert the trilobal tripot bushing onto the housing before attaching its larger new boot retaining clamp onto the boot. The housing needs to slide over the spider assembly while inspecting the formed shape of the boot. Place the joint assembly to its correct vehicle size while keeping the boot and tripot housing and large boot retaining clamp properly aligned. Discipline the boot retaining clamp using an earless clamp tool (J35910) to compress it to 176 nm (130 ft. Lbs.). Either use a breaker bar coupled with a torque wrench or repeat this process until the clamp ear gap measurement is tight.

The toolset for wheel drive shaft outer joint and boot replacement consists of Snap Ring Pliers (J 8059), Earred Clamp Tool (J 35910), Small Swage Tool (J 41048), breaker bar and torque wrench. Effective repair of the wheel drive shaft outer joint and boot requires Snap Ring Pliers (J 8059), Earred Clamp Tool (J 35910), Small Swage Tool (J 41048) and a breaker bar , as well as a torque wrench . The process begins with cutting both the large and small boot retaining clamps using a side cutter tool until they can be discarded. Use the bar to gently pull the outboard boot off the CV joint outer race until it moves away from the CV joint. Use the Snap Ring Pliers (J 8059) to open the retaining ring's ear portion before using the CV joint assembly bar removal. With a brass drift and hammer tap the CV joint cage in the bar to eliminate all six chrome alloy balls . Clean all components of the inner and outer race assemblies, CV joint cage, and balls using cleaning solvent until all previous grease and contaminants are removed before drying the cleaned parts. First place a new swage ring on the joint boot's small end before sliding both pieces onto the bar. The Small Swage Tool (J 41048) should be used to fasten the boot while checking for pinch areas. Start by tightening the Small Swage Tool (J 41048) bolts in an alternating pattern to get a secure fit. Afterward, adjust each bolt to a 180-degree position for final tightening. Add a thin layer of grease from the service kit to the ball grooves on both inner and outer races before putting the inner race into place with the cage next to the outer race. Insert chrome balls into the assembly then grease the CV joint while maintaining proper boot shape during the process. Use the Earred Clamp Tool (J 35910) along with a breaker bar to apply torque at 176 Nm (130 ft.lbs) while sliding the large boot diameter over the CV joint and crimping the boot retaining clamp. Verify the clamp ear fits correctly for proper installation.

Spread the ears on the race retaining ring with the J 8059 and remove the assembly.

Ensure there are no pinch points on the halfshaft inboard seal, insert the bolts, and tighten them by hand until snug.

Insert the chrome balls and pack the CV joint with grease.

Reseat the spacer ring in the groove, ensuring the trilobal tripot bushing is flush with the face of the housing.

Place the new small seal clamp onto the small end of the joint seal and slide both onto the wheel drive shaft bar, positioning the small end of the joint seal into the joint seal groove.
