Throttle Body

Cleaning the throttle body requires turning off the ignition initially before removing the air cleaner intake duct to prevent personal injury from throttle blade movement. Put away all tools before placing them inside the throttle body bore to preserve the throttle valve plate from harm. Check the throttle body bore along with the throttle plate for debris before opening the throttle plate to examine its complete surfaces. Fuel system components will suffer damage from applying Methyl Ethyl Ketone (MEK) among other solvents. Utilize GM Top Engine Cleaner (P/N 1052626) or AC-Delco Carburetor Tune-Up Conditioner (P/N X66-P) alongside a clean shop towel to clean the throttle body bore as well as the throttle plate. Reinstall the air cleaner intake duct as the final installation step.

When replacing the Throttle Body assembly, first also be careful when handling the electronic throttle control items, not to damage, using none small hand tools in order to not harm the internal wedge holding open the throttle plate. Start by partially draining the cooling system to disconnect the hose at the Throttle Body and taking off the air cleaner outlet duct and the engine sight shield. Detach the throttle actuator motor electrical connector, remove screw clamp for coolant air bleed hose, and remove the coolant air bleed hose from the Throttle Body. Then, after that, we'll need to remove the Throttle Body nuts and the Throttle Body itself and toss away the old Throttle Body Gasket. For installation, install a new Throttle Body Gasket and the Throttle Body and make sure that the nuts are fastened at the rate of 10 n.m (89 lb in). Reconnect the clamp and coolant air bleed hose, attach the throttle actuator motor electrical connector, and make sure to ensure a correct connector and seal, also check the connector for damage. Replace the engine sight shield and the air cleaner outlet duct, fill the cooling system and hook up a scan tool for testing throttle-opening and throttle-closing range. Move the accelerator pedal in a wide-open throttle condition (WOT), ensuring it is smooth from a closed throttle to wot condition, verify that the vehicle is not produced with its engine power-mode reduced, verify that the ignition is on, and verifies that the engine inscription before starting the engine and inspect for coolant leaks.

In order to replace the Throttle Body assembly, first approach the electronic throttle control parts with care not to damage it, as it may require avoiding dropping or using any cleaning solvents to wash them. The Throttle Body casting is marked with an 8 digit part identification number, which helps with servicing or replacement of parts. Start by unscrewing the intake air resonator and disconnecting throttle actuator motor electrical connector and removing Throttle Body nuts. It is very important to cover or plug any opening at this time to avoid contamination. Now clean the Throttle Body and take out the Throttle Body Gasket then dispose of it. To install, use new Throttle Body Gasket and install Throttle Body, and follow the fastener notice in service precautions. Tighten the Throttle Body nuts to 10 n.m (89 lb in), reconnect the throttle actuator motor electrical connector , and install the intake air resonator. Finally, plug-in a scan tool to test for proper throttle-opening and throttle-closing range, operate topic accelerator pedal to ensure it is free to move between a closed throttle to a wide-open throttle (WOT), and verify that the vehicle is not in a reduced engine power mode, on ignition is up and off.

To replace the Throttle Body assembly first we have to be careful with the electronic throttle control components, to avoid damaging it and do not use any min like small handtools to hold open the throttle plate as it might damage the wedge inside. Start with draining the cooling system partially to remove the hose at the Throttle Body. Then, take out the air cleaner outlet duct (lower down), as well as the engine sight shield. Drain the coolant air bleed hose using clamp, remove it from the Throttle Body, and reposition the throttle actuator motor electronic connector. Afterward, undo the Throttle Body nuts and follow these nuts to extract the Throttle Body and the gasket together but without the need to reuse the gasket. Install a new Throttle Body Gasket, the Throttle Body into place, and tighten the Throttle Body nuts to 10 n.m (89 lb in). Reattach the hose and its clamp for the coolant air bleed hose, connect the throttle actuator motor electrical connector, and check to make sure the connector and seal are in place and not damaged. Change engine sight shield and air cleaner outlet duct then top up the cooling system. Attach a scan tool to apply tests on throttle opening and throttle range closing to ensure that the accelerator pedal works properly from the closed to the wide open throttle (WOT). Check whether the vehicle is not in the reduced engine power mode, ignition is on, and engine is off just before starting the engine and checking for coolants leaks.

The process to replace the Throttle Body begins by taking off the air cleaner outlet resonator with its stud before removing the cruise control cable from both the throttle pulley and engine bracket. Begin by disconnecting the accelerator control cable first from the accelerator control bracket then from the engine bracket afterward disconnect the accelerator control cable slug from the throttle pulley. Detach the cable bracket nuts from the accelerator control then remove the bracket including its cables from the Throttle Body while securing the bracket and cables aside. The technician disconnects the throttle position (TP) sensor and idle air control (IAC) valve electrical connectors subsequently removing the Throttle Body studs with the Throttle Body, discarding the Throttle Body seal. Put a fresh Throttle Body seal into place after you install the Throttle Body. Secure the Throttle Body studs before tightening them to 9 n.m (80 lb in). Attach electrical connectors to tp sensor and iac valve before placing the bracket and its attached cables. Place these cables onto the Throttle Body before tightening the bracket nuts to 10 n.m (89 lb in). Place the accelerator control cable slug on the throttle pulley before you attach it to engine bracket and accelerator control bracket. The installation process ends with attaching the cruise control cable to engine bracket then throttle pulley before installing the air cleaner outlet resonator stud and tightening it at 10 n.m (89 lb in torques). Then reinstall the air cleaner outlet resonator.

To get the work moving on replacing the Throttle Body assembly first, with all the electronic throttle control components to be handled with care, do not damage anything and leave out any small hand tools to hold the throttle plate open; doing so may damage the inner wedge. Start by half-draining the cooling system for removing the hose at the Throttle Body. After that remove the air cleaner outlet duct and the engine sight shield and disconnect throttle actuator motor electrical connector. Reposition the coolant air bleed hose clamp and unbolt the coolant air bleed hose from the Throttle Body. Then, take out the Throttle Body nuts and the Throttle Body itself and throw away the old Throttle Body Gasket. For installation, it is necessary to fit a new Throttle Body Gasket and fit Throttle Body protecting the latter nuts tightening to 10 n. M (89 lb. In.). Reattach the coolant air bleed hose and clamp as per position. Check that throttle actuator motor harness and seal is properly connected and not damaged before reconnecting throttle actuator motor electrical connector. Reinstall the engine sight shield and air cleaner outlet ducts and top off the cooling system. Connect a scan tool to check for throttle-opening and throttle-closing range to make sure the accelerator pedal moves freely between closed throttle to wide open throttle (WOT). Make sure the vehicle is not in reduced engine power mode, the in/on switch of the ignition switch is pressed, and the ignition is turned off as you scan the interval as the engine is cranked and inspected for outlined leaks of coolant.

First of all, remove air cleaner intake duct to clear the throttle body. Make sure there is no ignition on as fingers are inserted into the throttle bore, to avoid surprise of the throttle blade's movement, which may result in personal injury. Do not place any tool in the bore of the throttle body to avoid crushing the throttle valve plate. Examine the bore of the throttle body and the throttle plate for deposits and open completely the throttle plate for a thorough inspection. Avoid any solvents that have Methyl Ethyl Ketone (MEK) in it because they might harm the fuel system elements. Using a clean shop towel clean the bore of the throttle body and the throttle plate using GM Top Engine Cleaner (P/N 1052626) or AC - Delco Carburetor Tune-Up Conditioner (P/N X66 - P) or an equal product. Lastly, replace the air cleaner intake duct.

The throttle plate needs cleaning after 80450 km (50,000 mi) of use when deposits start building up on its back surface as this can affect pedal response and throttle valve movement. Start by disconnecting the air cleaner intake duct while ensuring ignition remains off to protect against accidental throttle blade movement resulting in injury. Using a tool open the throttle plate to examine the internal surfaces of both the throttle plate and bore as well as any deposits present. You should refrain from using cleaning products that contain Methyl Ethyl Ketone (MEK) because they may harm your vehicle's fuel system components. Spray GM Top Engine Cleaner (P/N 1052626) or the equivalent product AC-Delco Carburetor Tune-Up Conditioner (P/N X66-P) onto a clean shop towel to clean throttle body bore and plate surfaces. Reinstall the air cleaner intake duct as your final step.

To change the Throttle Body assembly, handle the electronic throttle control components with care not to damage, avoid dropping it or slap them around, do not immerse it in any cleaning solvents. The electronic throttle control (ETC) means throttle position (TP) sensor is not serviceable individually; there is the need to service both components as one assembly unit. Start by identifying the 8 digit part identification stamp on the Throttle Body casting for future reference in the event of replacement. Remove the air induction assembly and make sure that in doing so, any openings are covered or plugged to prevent contamination. Pull off the throttle actuator motor harness connector and the tp sensor harness connector, and the Throttle Body attaching nuts after cautioning against reusing the Throttle Body Gasket, which should also be discarded. Replace a new Throttle Body Gasket and the Throttle Body assembly, wherein the Throttle Body nuts would be tightened using a torque wrench to a point of 10 n.m (89 lb in). Make sure the electrical connector to the Throttle Body motor and the connector seal are in good condition. Reconnect the tp sensor harness connector, and the throttle actuator motor harness; reconnect and reinstall the air induction assembly. With the vehicle not in reduced engine power, turn the ignition with the engine off to check the throttle complete positions for open and closure by the use of a scan tool which will check the throttle angles as you operate the accelerator pedal to ensure that it is operating free of binding in between closed throttle to full open throttle (WOT). Finally, start the engine.

To remove the Throttle Body assembly (W/O ETC) to remove air intake duct then remove the accelerator control cable and cruise control cable from the Throttle Body after disconnecting then remove the vacuum hose, throttle position (TP) sensor and idle air control (IAC) valve harness connectors. Next, unscrew the Throttle Body attaching nuts and remove the Throttle Body with the gasket and dispose of the gasket by disconnecting the coolant hose and the vapor vent pipe. Carefully clean off the old gasket from the aluminum surfaces using sharp tools to avoid destroying the sealing surfaces. It is important that one does not submerge the Throttle Body simply into a cold type cleaner that works by immersion; the reason being there are certain sealing compounds applied by the factory to the throttle plate and can easily be damaged by rough solvents or brushing; instead, try a spray type cleaner, such as gm x-66a or p/n gm1052626 and a shop towel for heavy deposits. Make sure no solvent or cleaner touches the tp sensor and iac valve. Clean the gasket sealing surfaces before assembly. Mount the Throttle Body by using a new gasket, while adhering to the fastener notice in service precautions, and tighten the attaching nuts to 10 n.m (89 lb in). Connect the coolant hose to the Throttle Body and the vapor vent pipe, accelerator control cable and cruise control cable, tp sensor and iac valve electrical connectors, and the vacuum hose to the Throttle Body. Reinstall the air intake duct and with the engine off, check the accelerator pedal movement to the floor by pressing and releasing. To reset iac valve, turn on the ignition for 10 seconds followed by turning it off for 5 seconds, then start the engine to test for the idle speed.

In removing the Throttle Body assembly, handle the items of electronic throttle control carefully in avoiding to cause damage; do not use any small hand tools when keeping the throttle plate open, there is a chance of damaging the internal wedge. First, partially drain the cooling system to remove the hose at the Throttle Body. Second, dismantle the air cleaner outlet duct, as well as the engine sight shield. Remove the throttle actuator motor electrical connector; move the coolant air bleed hose clamp; remove the coolant air bleed hose from Throttle Body. Next, unfasten the Throttle Body head nuts and Throttle Body, and then throw the old Throttle Body Gasket away. For installation, there is need to install a new Throttle Body Gasket, and install the Throttle Body with tightening nuts to 10 n.m (89 lb in). Reattach the coolant air bleed hose & its clamp, thn connect throttle actuator motor electrical connector check for the connection and seal of the connector and it is not damaged. Replace the engine sight shield and the air cleaner outlet duct, fill the cooling system, and then remove the engine oil. Use a scan tool to check the throttle-opening range and throttle-closing range to ensure the accelerator pedal functions freely from closed throttle to wide open throttle (WOT). Make sure that the vehicle is not in reduced engine power mode, the ignition is on, but the engine is off before the engine has been started up and inspected for coolant leaks.

Begin Throttle Body replacement by removing the air cleaner outlet resonator with its stud followed by detaching the cruise control cable from the throttle pulley and engine bracket. Starting with either accelerator control bracket or engine bracket you should remove the accelerator control cable. Then disconnect the accelerator control cable slug from the throttle pulley. Secure the accelerator control cables first before you remove their bracket with its attached nuts. Begin by detaching electrical cables from tp sensor and iac valve and next detach Throttle Body studs before completely removing the Throttle Body while discarding the Throttle Body seal. After installing the new Throttle Body seal, fit the Throttle Body into place before securing the Throttle Body studs at 9 n.m (80 lb in torque). Reattach accelerator control cable bracket with both cables to Throttle Body while maintaining 10 n.m (89 lb in) torque on its assembly nuts. The first step is to reinstall the accelerator control cable slug to the throttle pulley before putting the accelerator control cable onto the engine bracket and accelerator control bracket. Following the throttle pulley and engine bracket installation, reattach the cruise control cable before installing and torquing the air cleaner outlet resonator stud to 10 n.m (89 lb in). Finally, install the air cleaner outlet resonator.

To pull the Throttle Body assembly (W/ ETC), temporarily increase height of the vehicle and partially drain the cooling system to make it easy to take hoses from the Throttle Body off. Drop the vehicle, and make sure you cover or plug any entry points to avoid contamination. Detach the air intake duct, then disconnect the throttle actuator motor harness connector, throttle position (TP) and intake air control (IAC) sensor harness connectors, and the crankcase ventilation hose on the Throttle Body. Second, unbolt Throttle Body and detaching coolant hoses, then pull out Throttle Body along with gasket, while abstaining from the reuse of the gasket. Check the crankcase ventilation hose and tube, changing any damaged parts. For installation, install a new Throttle Body Gasket, join the coolant hoses, and install the Throttle Body assembly and tighten the Throttle Body bolts to the 10 n.m (89 lb in) using a torque wrench. Reconnect the tp, iac sensor harness connectors, the crankcase ventilation hose and throttle actuator motor's harness connector, then install the air intake duct and connect the intake air temperature sensor's harness connector. Recycle the cooling system and check whether the vehicle is not reduced in engine power, ignition is on, and the engine is off. With a scan tool, the throttle-opening and the throttle-closing range should be tested using the device, making sure the accelerator pedal moves freely from closed throttle to wide open throttle (WOT). Lastly, fire the engine and look for coolant leaks.

To remove the Throttle Body assembly, first, be gentle with the electronic throttle control pieces to avoid any damage and refrain from using any small hand tool to keep the throttle plate open, because of the threat of internal wedge damage. Start by partially draining the cooling system in order to remove the hose at the Throttle Body; next, remove the air cleaner outlet duct and the engine sight shield. Remove the Throttle Body cool air bleed hose and reposition the coolant air bleed hose clamp. Disconnect the throttle actuator motor connecter. Next, unbolt the Throttle Body nuts and the Throttle Body and throw away the old Throttle Body Gasket. For installments, put a new Throttle Body Gasket, install Throttle Body, and torque the Throttle Body nuts to 10 n.m (89 lb in). Reconnect the coolant air bleed hose and its clamp, confirming that the throttle actuator motor harness connector and seal slide in and are in good condition. Connect the throttle actuator motor electrical connection , re-install the engine sight shield , and the air cleaner outlet duct. Refill the cooling system, and scan it with a scan tool to identify whether there is a throttle-opening and throttle-closing variation. Operation of the accelerator pedal such that it is free between closed throttle and wide open throttle (WOT), verifying it is not operating in reduced engine power mode, ignition is on and the engine is off prior to starting the engine and checking for coolant leaks.

To remove the Throttle Body assembly, be gentle to the electronic throttle control parts to avoid damaging them, keep them from falling off or submerging them in any solvent during the cleaning process. There are 8 digit part identification number stamped on the Throttle Body casting important while service or part replacement. First, remove the intake air resonator, and then unplug the throttle actuator motor from the connector and remove the Throttle Body nuts. It is very essential to seal or plug openings in the process so that contamination is avoided. Then, take out the Throttle Body and throw the Throttle Body Gasket into the bin. For installation, install a new Throttle Body Gasket and installing Throttle Body, while adhering to the fastener notice in service precautions. Tighten Throttle Body nuts to 10 n.m (89 lb in), reconnect throttle actuator motor electrical connector and install intake air resonator. Lastly, perform a scan tool check for proper throttle-opening as well as throttle-closing range, and press accelerator pedal to confirm its ability to move freely between closed and wide open throttle (WOT) (minimum the ignition OFF) as well as verify that the vehicle is not in a reduced engine power mode with ignition on and off.

To dismantle the Throttle Body assembly, first, take away some of the cooling system liquid to enable removal of the hose at the Throttle Body. Remove the air cleaner outlet duct and the engine sight shield and disconnect the throttle actuator motor electrical connector. Move the coolant air bleed hose clamp and take out the coolant air bleed hose from the Throttle Body. Following that, remove Throttle Body nuts and remove the Throttle Body as well since the old Throttle Body Gasket should be removed. For installation, fit a new Throttle Body Gasket, and have the Throttle Body in the place, making sure to tighten the Throttle Body nuts to 10 n.m (89 lb in). Replace the coolant air bleed hose and position the clamp and connect the throttle actuator motor electrical connector, check the harness connector and seal and to make sure it is installed properly without any damage. Install the engine sight shield and air cleaner outlet duct back, and top up the cooling system. Use a scan tool to confirm the throttle-opening range and the throttle-closing range, so that the accelerator pedal is free to move and there's no restriction between closed throttle and wide open throttle (WOT). Be sure that the vehicle is not in low engine power, ignition is on, and engine is off before starting the engine and examine the coolant leaks.

Cleaning the throttle body requires turning off the ignition initially before removing the air cleaner intake duct to prevent personal injury from throttle blade movement. Put away all tools before placing them inside the throttle body bore to preserve the throttle valve plate from harm. Check the throttle body bore along with the throttle plate for debris before opening the throttle plate to examine its complete surfaces. Fuel system components will suffer damage from applying Methyl Ethyl Ketone (MEK) among other solvents. Utilize GM Top Engine Cleaner (P/N 1052626) or AC-Delco Carburetor Tune-Up Conditioner (P/N X66-P) alongside a clean shop towel to clean the throttle body bore as well as the throttle plate. Reinstall the air cleaner intake duct as the final installation step.

First, remove the air cleaner outlet duct as well as the air inlet screen if it is present, when cleaning the throttle body. Inspect the throttle body bore and throttle valve plate for deposits while ensuring the throttle valve is opened for a full inspection. Do not use immersion cleaners or solvents which are too strong for throttle body assemblies with sealed throttle shaft bearings, for fear of causing damage to the electric parts, sensors and seals or O-rings; they can also wash the grease from non-serviceable throttle shaft bearings. Do not use a wire brush or scraper to avoid damaging components and also use cleaners not containing MEK to prevent harm to components. Clean the throttle body bore and throttle valve plate using a clean shop towel with the GM Top Engine Cleaner, P/N 1052626 (Cdn P/N 993026) or an equivalent product. If the amounts of deposits are large, then disassemble the throttle body and clean it using a parts cleaning brush without submerging it in any cleaning solvent. Reassemble and install the throttle body; install the air inlet screen if applicable, then install the air cleaner outlet duct.

Begin Throttle Body replacement by removing the air cleaner outlet resonator with its stud followed by detaching the cruise control cable from the throttle pulley and engine bracket. Starting with either accelerator control bracket or engine bracket you should remove the accelerator control cable. Then disconnect the accelerator control cable slug from the throttle pulley. Secure the accelerator control cables first before you remove their bracket with its attached nuts. Begin by detaching electrical cables from tp sensor and iac valve and next detach Throttle Body studs before completely removing the Throttle Body while discarding the Throttle Body seal. After installing the new Throttle Body seal, fit the Throttle Body into place before securing the Throttle Body studs at 9 n.m (80 lb in torque). Reattach accelerator control cable bracket with both cables to Throttle Body while maintaining 10 n.m (89 lb in) torque on its assembly nuts. The first step is to reinstall the accelerator control cable slug to the throttle pulley before putting the accelerator control cable onto the engine bracket and accelerator control bracket. Following the throttle pulley and engine bracket installation, reattach the cruise control cable before installing and torquing the air cleaner outlet resonator stud to 10 n.m (89 lb in). Finally, install the air cleaner outlet resonator.

Use a clean shop towel with GM top engine cleaner (P/N 1052626) or AC Delco Carburetor Tune-up Conditioner (P/N X66P) or an equivalent product.

The throttle position (TP) sensor and idle air control (IAC) valve harness connectors.

Clean the gasket surface.

Inspect the throttle body bore and throttle plate for deposits by opening the throttle plate to access all surfaces.

Do not use a wire brush or scraper, as these can harm the throttle body components.

Clean the throttle body bore and throttle plate with a clean shop towel and top engine cleaner, GM P/N 1052626 (Canadian P/N 993026), or an equivalent.

Remove the air cleaner outlet duct and the engine sight shield.

Remove the accelerator control cable from both the accelerator control bracket and engine bracket.

Clean the throttle body bore and the throttle plate with a clean shop towel using GM top engine cleaner (P/N 1052626) or AC Delco Carburetor Tune-up Conditioner (P/N X66P) or an equivalent product.

Remove the air cleaner outlet duct.
