Make sure this part fits

GM 16635395
Window Lock

1995-2005 GM

Customer Questions & Expert Answers (26)
GM 16635395 Window Lock
  • Part Description
    Latch, End Gate Lock
  • Replaces
    16634041, 16635396, 16631756
  • Manufacturer
    General Motors
  • Manufacturer's Notes
    This part is discontinued.
Make sure this part fits
  • Vehicle Fitment

    Year Make Model Trim Engine
    2004-2005 Buick RainierCXL, CXL Plus6 Cyl 4.2 L GAS, 8 Cyl 5.3 L GAS
    1995-2005 Chevrolet BlazerBase, LS, LT, Trailblazer, Xtreme, ZR26 Cyl 4.3 L GAS
    1995-2004 Chevrolet S10Base, LS, SS, Xtreme, ZR2, ZR54 Cyl 2.2 L FLEX, 4 Cyl 2.2 L GAS, 6 Cyl 4.3 L GAS
    2002-2005 Chevrolet TrailblazerLS, LT, LTZ, North Face6 Cyl 4.2 L GAS
    2002-2005 Chevrolet Trailblazer EXTLS, LT, North Face6 Cyl 4.2 L GAS, 8 Cyl 5.3 L GAS
    2002-2005 GMC EnvoyDenali, SLE, SLT6 Cyl 4.2 L GAS, 8 Cyl 5.3 L GAS
    2002-2005 GMC Envoy XLDenali, SLE, SLT6 Cyl 4.2 L GAS, 8 Cyl 5.3 L GAS
    2004-2005 GMC Envoy XUVSLE, SLT6 Cyl 4.2 L GAS, 8 Cyl 5.3 L GAS
    1995-2001 GMC JimmyBase, Diamond Edition, Envoy, SL, SLE, SLS, SLT6 Cyl 4.3 L GAS
    1995-2004 GMC SonomaSL, SLE, SLS4 Cyl 2.2 L FLEX, 4 Cyl 2.2 L GAS, 6 Cyl 4.3 L GAS
    View More
    Warning: California's Proposition 65
  • Customer Questions & Expert Answers

    Q:
    Is this 16635395 designed for my car? Posted by ChevyPartsGiant Specialist
    A:
    Please Select Your Vehicle model to see if part number 16635395 is suitable before ordering.
    Posted by ChevyPartsGiant Specialist
    Q:
    How should the latch assembly be secured to the bracket for the 2004 Buick Rainier? Posted by Customer
    A:
    Secure the latch assembly to the bracket with screws, tightening them to 12 N.m (106 lb in).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Tailgate Latch
    Q:
    What is the next step after disconnecting the electrical connector for the 2004 Buick Rainier? Posted by Customer
    A:
    Remove the latch from the end gate.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Tailgate Latch
    Q:
    What is the next step after removing the screws for the 2004 Buick Rainier? Posted by Customer
    A:
    Carefully lift and rotate the actuator to disengage the rubber bumper from the latch, then remove the actuator from the latch.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Door Lock Actuator
    Q:
    How do you detach the lock actuator from the latch for the 2005 Chevrolet Blazer? Posted by Customer
    A:
    Take out the 2 screws that secure the lock actuator to the latch.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Door Lock Actuator
    Q:
    What is the final step in the installation process for the 2005 Chevrolet Blazer? Posted by Customer
    A:
    Reconnect the endgate latch rod to the endgate latch and reinstall the endgate trim panel.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Tailgate Latch
    Q:
    What should be removed after the door trim panel for the 2002 Chevrolet S10? Posted by Customer
    A:
    Remove the water deflector and the door latch assembly.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Door Lock Actuator
    Q:
    How do you secure the actuator to the latch for the 2002 Chevrolet S10? Posted by Customer
    A:
    Install the 2 screws to secure the actuator to the latch, tightening them to 0.75 N.m (6 lb in).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Door Lock Actuator
    Q:
    What is the first step to replace the endgate latch for the 2002 Chevrolet S10? Posted by Customer
    A:
    Open the endgate and remove the endgate trim panel.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Tailgate Latch
    Q:
    What is the first step to replace the power door lock actuator for the 2003 Chevrolet S10? Posted by Customer
    A:
    Begin by removing the door trim panel.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Door Lock Actuator
    Q:
    What is the first step to replace the endgate left upper latch for the 2005 Chevrolet Trailblazer? Posted by Customer
    A:
    Swing the endgate open and remove the endgate trim panel followed by the endgate inner reinforcement panel.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Tailgate Latch
    Q:
    What are the final steps after installing the latch for the 2004 Chevrolet Trailblazer? Posted by Customer
    A:
    Reinstall the end gate inner reinforcement panel and the end gate trim panel.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Tailgate Latch
    Q:
    What should be removed after the door trim panel for the 2003 GMC Envoy? Posted by Customer
    A:
    Remove the water deflector and the door latch assembly.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Door Lock Actuator
    Q:
    What should be removed after the door trim panel for the 2002 Chevrolet Trailblazer? Posted by Customer
    A:
    Remove the water deflector and the door latch assembly.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Door Lock Actuator
    Q:
    What should be removed after opening the endgate for the 2005 Chevrolet Trailblazer? Posted by Customer
    A:
    Remove the bolts that secure the latch bracket assembly to the endgate and take out the latch bracket assembly.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Tailgate Latch
    Q:
    What should be done after removing the endgate trim panel for the 2000 GMC Jimmy? Posted by Customer
    A:
    Detach the endgate latch rod from the endgate latch and remove the bolts that secure the endgate latch to the endgate.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Tailgate Latch
    Q:
    What is the first step in the installation process for the 2005 Chevrolet Trailblazer? Posted by Customer
    A:
    Attach the rubber bumper to the latch.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Door Lock Actuator
    Q:
    What is the first step to replace the rear side door lock actuator for the 2000 GMC Jimmy? Posted by Customer
    A:
    Raise the window to the closed position and disconnect the battery negative cable, ensuring to follow the battery disconnect caution.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Door Lock Actuator
    Q:
    What rods need to be installed to the lock assembly for the 2000 GMC Jimmy? Posted by Customer
    A:
    Install the outside door handle rod, outside lock rod, inside door handle rod, and inside door lock rod.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Door Lock Actuator
    Q:
    How do you install the new latch for the 2005 GMC Envoy? Posted by Customer
    A:
    Position the latch onto the endgate and connect the electrical connector to the latch assembly.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Tailgate Latch
    Q:
    How do you secure the latch assembly during installation for the 2004 GMC Envoy? Posted by Customer
    A:
    Install the bolts to secure the latch assembly, tightening them to 25 N.m (18 lb ft).
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Tailgate Latch
    Q:
    What should be done after securing the lock assembly for the 2001 GMC Jimmy? Posted by Customer
    A:
    Reconnect the power actuator wiring connector if applicable, then install the outside door handle rod, outside lock rod, inside door handle rod, and inside door lock rod to the lock assembly.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Door Lock Actuator
    Q:
    How do you detach the lock actuator from the latch for the 2004 GMC Sonoma? Posted by Customer
    A:
    Take out the 2 screws that secure the lock actuator to the latch.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Door Lock Actuator
    Q:
    What should be removed after the door trim panel for the 2004 GMC Sonoma? Posted by Customer
    A:
    Remove the water deflector and the door latch assembly.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Door Lock Actuator
    Q:
    What should be done after installing the new latch for the 2003 GMC Sonoma? Posted by Customer
    A:
    Reconnect the electrical connectors as needed and finally, reinstall the endgate cover.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Tailgate Latch
    Q:
    What should be done after aligning the actuator for the 2003 GMC Sonoma? Posted by Customer
    A:
    Rotate the actuator toward the latch to fully engage the rubber bumper, then position the actuator at the top of the latch.
    Posted by ChevyPartsGiant Specialist
    See expert answers on similar Door Lock Actuator
    If you have any questions about this product, please don't hesitate to ask us. We will be happy to help you!

OEM GM Window Lock 16635395 Designed for Proper Fit and Performance

Original OEM GM parts deliver superior quality and meet all performance standards needed for optimal automotive operation. The authentic part identified by 16635395 Window Lock is available in the market under the name GM Door Lock, Door Lock Actuator, Tailgate Latch, Tailgate Lock, Trunk Latch. This genuine product has a full warranty coverage from the manufacturer available at all authorized GM dealers throughout the United States. This part 16635395 Window Lock fits certain Chevrolet S10, Blazer, Trailblazer models, as well as GMC Envoy, Sonoma, Envoy XL. Additionally, it is compatible with Buick Rainier and Oldsmobile Bravada models.
The original GM component designated by manufacturer part number 16635395 maintains top performance when functioning as the Latch, End Gate Lock unit. The component 16635395 is constructed from durable material and its dimensions span 5.6 x 7.5 x 2.0 inches while weighing 1.10 Pounds. The Direct Replacement component is ready in New condition to ensure full compatibility with your vehicle system. This component receives the designation of Latch. The part 16635395 has available replacement options 16634041, 16635396, 16631756. GM manufacturer provides a warranty that ensures reliable operation of this product. The Shipping Policy and Return Policy pages outline complete details regarding shipping procedures and return processes.
If you want to save money in the long run on maintenance and repairs, you should choose OEM products because they're of the top level of durability. Are you on the quest of finding GM parts, our site is worth a visit. We stock an endless selection of high-quality GM components including things like ignition coils all the way through to fan shrouds and all at prices that can not be matched. You have nothing to worry about because all our OEM parts are covered with a manufacturer warranty, which guarantees superior quality and value.
