GM 15221006
Inner Tie Rod

Start by removing the Rack and Pinion Boot and breather tube before continuing with inner Tie Rod replacement of a Rack And Pinion system on the vehicle. During inner Tie Rod mounting and unmounting processes you should always support the rack with your hands so it stays safe and undamaged. The first step involves taking out the shock dampener installed on the inner Tie Rod assembly which can be repositioned onto its place on the rack. The rack assembly requires both wrenches to separate the inner Tie Rod housing from the rack assembly by rotating counterclockwise after securing wrenches on their flat surfaces. Insert the shock dampener onto the rack while securing the inner Tie Rod to 100 nm (74 ft. Lbs.) torque. To join the inner Tie Rod with the rack you should position a wrench on the rack's flats and a torque wrench on the inner Tie Rod housing flats. Fix the inner Tie Rod assembly inside a vise for steadying purposes so you can stake both housing flats to the rack's surface. Insert a 0.25 mm gauge between the rack and housing stake to confirm both stakes pass inspection before allowing the feeler gauge through the gap. The shock dampener should now slide over the inner Tie Rod housing allowing the front lip of the dampener to rest against the housing before adding the Rack and Pinion Boot and breather tube.

Start the inner Tie Rod replacement by taking out both the Rack and Pinion Boot and breather tube before holding the rack securely to avoid damage during work. The shock dampener needs to come off the inner Tie Rod assembly so you can push it back along the rack. Insert two wrenches on the rack assembly flats and inner Tie Rod housing flats before counterclockwise rotation which frees the inner Tie Rod housing from the rack assembly. During assembly insert the shock dampener towards the front of the rack then secure the inner Tie Rod at 100 nm torque (74 ft. Lbs.). The attachment process requires a wrench on the rack assembly flats and a torque wrench on the inner Tie Rod housing flats. Lock the vise around the inner Tie Rod assembly before staking the assembly's two sides flat onto the rack surface. Both housing stakes need to be checked with a 0.25 mm gauge so that the feeler gauge cannot pass through the space between the rack and housing stake. Slide the shock dampener over the inner Tie Rod housing so that its front lip rests against the housing then reattach both Rack and Pinion Boot and breather tube.

Replacing the rack and pinion inner Tie Rod (Quiet Valve) off the vehicle begins with boot removal to secure the gear on a vise before adjusting the steering gear preload to avoid damage. Insert the outer portion of the inner Tie Rod assembly onto the rack before retaking the shock dampener. A pipe wrench on the rack should be placed adjacent to the inner Tie Rod housing. Then use a wrench with flats on both sides of the inner Tie Rod housing to rotate it clockwise for separation from the rack. Before installation slide the shock damper out of the inner Tie Rod housing and reinstall it onto the rack. Begin by placing a pipe wrench on the rack's surface next to the inner Tie Rod housing while using a wrench on its flats to turn it counterclockwise until the inner Tie Rod becomes detached from the rack. For installations where the rack features a female configuration and the inner Tie Rod has a male aspect users should eliminate all traces of previous loctite® from both components before installing new ones. Since this assembly employs male rack and female inner Tie Rod there will not be loctite® present. Slide the shock dampener to the rack's front position where threads are clear and then apply loctite® 262 or equivalent to male inner Tie Rod threads during assembly when using a female rack and male inner Tie Rod setup. A pipe wrench should mount to the inner Tie Rod housing while a torque wrench with j 34028 engages the flats of the inner Tie Rod housing for a final torque of 100 nm (74 ft. Lbs.). Apply loctite® 262 or equivalent to male inner Tie Rod threads when the configuration matches female rack to male inner Tie Rod before mount attachment onto the rack. From an inner Tie Rod housing perspective, apply a torque wrench with j 34028 and tighten components with a strength of 100 nm (74 ft. Lbs.). When working with configurations where the rack exists as a male component the inner Tie Rod assembly should rest in a vise while staking the female inner Tie Rod assembly housing to the male rack on both sides. A 0.25mm gauge should verify that no area on both stakes can fit through the rack-to-inner Tie Rod housing gap. After the shock dampener reaches its lowest position it should rest against the inner Tie Rod housing before installing the Rack and Pinion Boot.

In changing the inner Tie Rod, one should remove all the rack and pinion boots, ensuring the rack is held back to avoid it undergoing any damage in the process. Then, pull off the shock dampener from the inner Tie Rod assembly and slide it back over the rack. Remove the inner Tie Rod assembly from the rack assembly by engaging a wrench to the flats of the rack assembly and flats of the inner Tie Rod housing , in that order, so that it is counterclockwise until it becomes separated from the rack . Remove loctite(R) old material from threads of the rack and the inner Tie Rod. For assembly slide the shock dampener forward onto the rack and rub the threads are clean before the application loctite(R). Under the inner Tie Rod threads, use loctite(R)262 (or similar) and attach the maker Tie Rod to the rack by turning on wrench flats of the rack set up and torque wrench to flats of inner Tie Rod housing to 100 n. M (74ft. Lbs. ). Lastly, fit the shock dampener over the inner Tie Rod housing until the front lip of the shock dampener hits the inner Tie Rod housing and mount the Rack and Pinion Boot.

The first step to change the tie rod on front-wheel-drive vehicles involves raising the vehicle and implementing proper support. The automatic level control sensor maintains its link connection to the sensor arm while the technician disconnects the electrical connector of the sensor. The height sensor link should be removed from the rear axle tie rod. Begin the replacement by unscrewing the rear axle tie rod bolts before extracting the rear axle tie rod. Start front-wheel-drive vehicle installation by connecting the rear axle tie rod to the vehicle while carefully following the Fastener Notice in Service Precautions. Afterward, proceed with tightening the rear axle tie rod bolts and nuts to 125 Nm (92 ft. lbs.). Serving the automatic level control sensor link requires special attention to prevent damage to the sensor link and sensor arm while making sure both components are correctly oriented to protect the automatic level control system. The height sensor link installation for vehicles with automatic level control should proceed with a connection to the rear axle tie rod followed by electric connector reconnection before vehicle height lowering takes place.

In order to replace the inner Tie Rod (Quiet Valve), one can use the inner Tie Rod wrench (J 34028). Remove the Rack and Pinion Boot and the breather tube, and fixate the gear in a vise, then. Do not alter the steering gear preload before removing the inner Tie Rod to avoid damage. Move the shock dampener from the inner Tie Rod housing and slide it back onto the rack. Attach a pipe wrench at the rack near the inner Tie Rod housing and a wrench on the flats of the inner Tie Rod housing and rotate the latter counter clockwise till it frees from the rack. Do this process for the inner Tie Rod housing and the inner Tie Rod. Clean off the threads on the inner Tie Rod and apply loctite 262, or equivalent, as necessary when installing the inner Tie Rod to the rack. Apply full brake force with the brakes degaussed and check that the pad wear returns to approximately 25mm within thirty (30) seconds, and that the pedal does not return until the engine is started, indicating that the pads are working properly. Stake the inner Tie Rod assembly as required and make sure that the feeler gauge (0.010) inch) doesn't fit between the rack and the housing stake. Lastly, align the shock dampener over the inner Tie Rod housing and guide it as far as it will fit, placing it in a seat position.

Begin inner Tie Rod (Quiet Valve) replacement by detaching the steering gear from the vehicle while removing the Rack and Pinion Boot and securing the gear for vise mounting. Steering gear preload adjustment should never be altered before removing the inner Tie Rod because it could damage the pinion and steering gear. Put the shock dampener aside from the inner Tie Rod assembly before sliding it back onto the rack. Secure a pipe wrench onto the rack next to the inner Tie Rod housing and apply a wrench to the flats of the housing to twist it counterclockwise and separate it from the rack. Perform the same sequence for inner Tie Rod housing and inner Tie Rod while cleaning threads and applying loctite 262 or equivalent when needed. To secure the inner Tie Rod on the rack use a pipe wrench alongside a torque wrench equipped with j 34028 which should be set to 100 nm (74 ft. Lbs.) torque value. If necessary stake the female inner Tie Rod assembly housing to the male rack ensuring correct staking through the use of a 0.25 mm gage. The shock dampener slides over the inner Tie Rod housing as part of reassembling the Rack and Pinion Boot before installing the steering gear.

Begin Rack And Pinion inner Tie Rod replacement by taking off the Rack and Pinion Boot from the vehicle. Another technician should support the rack throughout the operation of removing or putting in the inner Tie Rod. After removing the shock dampener from the inner Tie Rod assembly you can position it on the rack. Separate the inner Tie Rod assembly from the rack assembly by applying two wrenches to their respective flats before twisting the housing counterclockwise to create separation. Use a brush to clean off existing loctite (R) residues from the rack's threads as well as inner Tie Rod threads. Place the shock dampener in front position on the rack after cleaning threads before applying loctite r262 (or equivalent) to inner Tie Rod threads. To attach the inner Tie Rod to the rack assembly users must first torque it to 100 nm (74 ft. Lbs.) while placing a torque wrench on the flats of the rack assembly and a wrench on the flats of the inner Tie Rod housing . Complete Rack And Pinion assembly by sliding the shock dampener forward while guiding it to rest on the inner Tie Rod housing front lip.

To replace the inner Tie Rod of the Rack And Pinion off the vehicle, first, make sure the rack is fixated so that it could not suffer a loss in the process. Start by taking out the shock dampener from inner Tie Rod assembly and then push it back on the rack. Then unbolt the inner Tie Rod assembly from the rack assembly by grabbing a wrench and placing it on the flats of the rack assembly and another wrench on the flats of the inner Tie Rod housing (unbolt and rotate the assembly CCW, separate from the rack ); first unbolt the 18 studs. Clean off the old loctite from the threads of the rack, and the internal Tie Rod. Mount by sliding the shock dampener forward onto the rack to be sure that the threads are clean before applying loctite(R) 262 (or equivalent) to the inner Tie Rod threads, using only enough to coat them evenly. Install the inner Tie Rod to the rack by inserting a wrench on the flats of the rack assembly and using a torque wrench on the flats of the inner Tie Rod housing then torque them to 100 nm ( 74 ft. Lbs.) finally, slip the shock dampener over the inner Tie Rod housing to the point at which the front lip bottoms on the inner Tie Rod housing and install the Rack and Pinion Boot.

To uninstall Rack And Pinion inner Tie Rod off the vehicle first remove Rack And Pinion boot. While installing the inner Tie Rod and trying to remove it, it is extremely important to keep the rack in hands to avoid damage. Start by removing the shock dampener from the inner Tie Rod assembly and slide it back on the rack. Then take the inner Tie Rod assembly out of the rack assembly by starting with putting one wrench on the flats of the rack assembly and another wrench on the flats of the inner Tie Rod housing then you turn the inner tying rod housing clockwise until it detaches from the rack. Clean old loctite off the threads of the rack and the inner Tie Rod. To perform this procedure, use the inner Tie Rod wrench (J34028). In the event of an assembly, position the shock dampener so that it stabilises on the rack, also ensuring to keep the threads intervals clear before applying the loctite (R) 262 (equal with other). Mount the inner Tie Rod to the rack with a wrench on the flats of rack assembly and with a torque wrench on the inner Tie Rod wrench (J34028) on the flats of the inner Tie Rod housing while tightening it to 100 nm (74 ft. Lbs). Last of all slide the shock dampener over the inner Tie Rod housing until the front of the shock dampener hits against the inner Tie Rod housing.

Begin inner Tie Rod of the steering gear (Quiet Valve) replacement by removing the Rack and Pinion Boot then examining the inner Tie Rod for corrosion and contamination; continue only if no issues appear. Start the repair process if you find no damage to the inner Tie Rod. Put the gear into a vise while maintaining its current steering gear preload adjustment setting to protect it from damage. Mirror orientation and safety by sliding the shock dampener onto the rack then away from the inner Tie Rod assembly. A pipe wrench on the rack's inner Tie Rod housing flats plus an additional wrench on the rack's inner Tie Rod housing can be used to turn the rack counterclockwise for its separation from the rack. The shock dampener must be detached from the inner Tie Rod housing before the inner Tie Rod removal process can begin again. Before you reattach the inner Tie Rod to the rack, clean both components' threaded parts and apply either loctite(R) 262 or a similar thread sealer to the threads. Use a pipe wrench on the rack together with a torque wrench j 34028 on the inner Tie Rod housing to fasten the components to 100 n.m (74 lb ft). Perform the same steps again on the inner Tie Rod before securing the female inner Tie Rod assembly housing to the male rack by staking both sides. Examine the stake diameter by inserting a 0.25 mm gage to confirm it does not fit between the housing and rack . Shove the shock dampener over the inner Tie Rod housing completely before final assembly of the Rack and Pinion Boot.

Clean the threads of the inner tie rod and the rack if applicable, and apply LOCTITE® 262 or equivalent as needed.

Ensure proper staking of the inner tie rod assembly housing to the male rack and check the stakes with a 0.25 mm gage.

Slide it back onto the rack.

Slide the shock dampener over the inner tie rod housing until it is properly seated.

Tighten the tie rod bolt to 85 Nm (63 ft. lbs.).

Repeat for the inner tie rod and ensure proper staking of the inner tie rod assembly housing to the male rack.

Slide the shock dampener over the inner tie rod housing until it is properly seated.

Tighten it to 100 Nm (74 ft. lbs.) using a torque wrench with the Inner Tie Rod Wrench (J 34028).

Check the stakes with a 0.25 mm gage to ensure they are secure.

Clean the old LOCTITE(R) from the threads of the inner tie rod and the rack.

First, remove the rack and pinion boot.

Use a 0.25 mm gage to check the stakes, ensuring it does not pass between the rack and housing stake.

Remove the shock dampener from the inner tie rod assembly and slide it back onto the rack. Use a pipe wrench on the rack next to the inner tie rod housing and a wrench on the flats of the inner tie rod housing to rotate it counterclockwise until it separates from the rack.

Check both stakes with a 0.25 mm gage to ensure it does not pass between the rack and the housing stake.

Clean the old Loctite from the threads of the rack and the inner tie rod.

Remove the rack and pinion boot, ensuring the rack is held to prevent damage during the process.

Slide the shock dampener over the inner tie rod housing until the front lip of the shock dampener bottoms against the inner tie rod housing and assemble the rack and pinion boot.
